ESP-12F User Manual
•
Supports antenna diversity
•
Wi-Fi 2.4 GHz, support WPA/WPA2
•
Support STA/AP/STA+AP operation modes
•
Support Smart Link Function for both Android and iOS devices
•
SDIO 2.0, (H) SPI, UART, I2C, I2S, IRDA, PWM, GPIO
•
STBC, 1x1 MIMO, 2x1 MIMO
•
A-MPDU & A-MSDU aggregation and 0.4s guard interval
•
Deep sleep power <10uA, Power down leakage current < 5uA
•
Wake up and transmit packets in < 2ms
•
Standby power consumption of < 1.0mW (DTIM3)
•
+20dBm output power in 802.11b mode
•
Operating temperature range -40C ~ 85C

Parameters

1.2.
Table 1 below describes the major parameters.
Categories
WiFi Paramters
Hardware
Paramaters
Shenzhen Ai-Thinker Technology Co., Ltd
Items
WiFi Protocles
Frequency Range
Peripheral Bus
Table 1 Parameters
802.11 b/g/n
2.4GHz-2.5GHz (2400M-2483.5M)
UART/HSPI/I2C/I2S/Ir Remote Contorl
GPIO/PWM
http://www.ai-thinker.com
Values
