Summary of Contents for CO Guardian 452-201
- Page 1 Document No. 03-452-201 1951 E. AIRPORT DRIVE Date: 8-20-2004 TUCSON, AZ. 85706 REV F CO Guardian LLC 1951 E. Airport Dr. Tucson, AZ 85706 OWNERS MANUAL CARBON MONOXIDE DETECTOR MODEL 452-201 REMOTE UNIT MODEL 452-201 OWNERS MANUAL Page 1 of 22...
- Page 2 CO Guardian LLC Document No. 03-452-201 1951 E. AIRPORT DRIVE Date: 8/20/2006 TUCSON, AZ. 85706 REV F INTENTIONALLY LEFT BLANK MODEL 452-201 OWNERS MANUAL Page 2 of 22...
-
Page 3: Log Of Revisions
ASH VIJ 21, 22 and 23 1 thru 20 5/4/05 Revised pages 7, 8 and ASH VIJ 1 thru 20 8/20/06 Revised pages 7, 8, 12, ASH VIJ 13, 14, 5 and 21 MODEL 452-201 OWNERS MANUAL Page 3 of 22... - Page 4 CO Guardian LLC Document No. 03-452-201 1951 E. AIRPORT DRIVE Date: 8/20/2006 TUCSON, AZ. 85706 REV F INTENTIONALLY LEFT BLANK MODEL 452-201 OWNERS MANUAL Page 4 of 22...
-
Page 5: Table Of Contents
FIGURE 1 - TYPICAL RIGHT INSTRUMENT PANEL..................12 FIGURE 2 - TYPICAL PILOT INSTALLATION SHOWN .................. 12 INSTALLATION INSTRUCTIONS ......................13 6.2.1 INSTALLATION INSTRUCTIONS (PART NUMBERS 452-201-001 through -004) ......13 6.2.2 INSTALLATION CHECKS (PART NUMBERS 452-201-001 through -004)........... 14 6.2.3 INSTALLATION INSTRUCTIONS (PART NUMBERS 452-201-005 through -008)....... - Page 6 When reporting a specific problem, please describe it briefly and include the document number, the paragraph/figure/table number, and the page number. Send your comments to the address above. MODEL 452-201 OWNERS MANUAL Page 6 of 22...
-
Page 7: Description
RS-232 Data Buss TABLE 1 - Part Numbers The Detector must be returned to CO Guardian at the end of Service Life for replacement and calibration of the CO sensor to maintain airworthiness of the unit. *Pressure relay is designed for information purpose. The relay is activated at 10,000 feet for 5 seconds and remains on after 12,500 feet using the pressure sensor built in the 452 models. -
Page 8: Leading Particulars
Document No. 03-452-201 1951 E. AIRPORT DRIVE Date: 8/20/2006 TUCSON, AZ. 85706 REV F LEADING PARTICULARS Table 2 lists the CO Detector leading particulars. Model 452-201 Series CO Detectors are approved to TSO C48A. MODEL 452-201 OWNERS MANUAL Page 8 of 22... - Page 9 14 and 28 vdc models <1 watt Dissipation (maximum) 9 watts 14 vdc models (heater ON) 28 vdc models (heater ON) 10 watts Keep Alive circuit Power < 8 MA TABLE 2 - Leading Particulars MODEL 452-201 OWNERS MANUAL Page 9 of 22...
-
Page 10: Scope
CO levels. SERVICE FACILITIES With the exception of the Model 452-201-* CO Detectors, the operator can service all other components of the installation at an FAA certified Repair Station. CO Detectors must me returned to CO Guardian for repair or overhaul. - Page 11 TUCSON, AZ. 85706 REV F INSTALLATION The following documents the installation criteria of the Model 452-201 Remote Carbon Monoxide Detector Installation: a. Choose a location behind the instrument panel for the installation of the CO Detector. Choose a location with space available that also meets the following criteria. A typical installation is shown in drawing 01-2510-02 rev.
-
Page 12: Recommended Installation Areas
• Typical installation areas are depicted below in Figurers 1 and 2. CO Detector FIGURE 1 - TYPICAL RIGHT HAND INSTRUMENT PANEL SHOWN Test /Reset Switch Amber Alert Annunciator 2 AMP CIRCUIT BREAKER FIGURE 2 - TYPICAL PILOT INSTALLATION SHOWN MODEL 452-201 OWNERS MANUAL Page 12 of 22... -
Page 13: Installation Instructions
REV F INSTALLATION INSTRUCTIONS 6.2.1 INSTALLATION INSTRUCTIONS (PART NUMBERS 452-201-001 through -004) a. Install the CO Detector in accordance with drawing 01-2510 Rev. C or later. Note the 'salt-shaker' and 'open' air intake hole pattern option on drawing. Placards above and below the air intake hole/s/, in accordance with Flag Note 11, as shown drawing. -
Page 14: Installation Checks (Part Numbers 452-201-001 Through -004)
Date: 8/20/2006 TUCSON, AZ. 85706 REV F 6.2.2 INSTALLATION CHECKS (PART NUMBERS 452-201-001 through -004) a. With the CO Detector disconnected from the aircraft harness, conduct a continuity check of the added aircraft wiring. b. Turn ON the aircraft Battery Switch. Close the CO DETECT circuit breaker and measure aircraft voltage between pins 1 and 2 of the CO Detector connector. -
Page 15: 6.2.4 Installation Checks
Switch ON. Close CO DETECT circuit breaker. e. Operational check the unit by depressing the CO Test/Reset switch and verifying the remote alert light operation. Remote Amber Alert light should flash twice. MODEL 452-201 OWNERS MANUAL Page 15 of 22... -
Page 16: Maintenance Instructions
At every power up the system will go through a self-diagnostic check. WARNING: If the Model 452-201 unit shows a flashing remote Amber light every 4 seconds, return the unit to CO Guardian for repair or replacement. -
Page 17: Carbon Monoxide Detector Scheduled Maintenance
NO FIELD SERVICE OR OVERHAUL OF MODEL 452 IS AUTHORIZED. WEIGHT AND BALANCE / EQUIPMENT LIST The Aero 452-201 CO Detector installation weighs 0.109 lbs. Reference the aircraft weight and balance manual for moment arm. MODEL 452-201 OWNERS MANUAL... -
Page 18: Limitations
11.0 NORMAL PROCEDURES When the airplane master battery switch is selected ON, the Aero 452-201 Remote CO Detector goes through a self-test routine. The self-test checks for functionality of critical components such as the CO sensor, temperature sensor, pressure sensor, and integrity of the system. -
Page 19: Emergency Procedures
“ALERT” display is integrated with the Manufacturers MFD. DO not recycle the unit through the circuit breaker. A three-minute delay is required for the CO sensor to stabilize after each power-up in the -001 through -004 P/N units. MODEL 452-201 OWNERS MANUAL Page 19 of 22... -
Page 20: Unit Failure Indication
Detector status information to electronic display systems with RS-232 input capability. The unit transmits CO Level, Cabin Temperature, Cabin pressure and is remotely reset able via RS232. See Multi-Function display manufacturers Installation Manual for interface guidance. MODEL 452-201 OWNERS MANUAL Page 20 of 22... -
Page 21: Warranty
Warranty Performance: During the above warranty period, your product will be replaced with a comparable product if the defective product is returned, postage prepaid, to CO Guardian, Customer Service Department, 1951 East Airport Drive, Tucson, AZ 85706, together with proof of purchase date.
