Brulin Victory VSHAND Use Directions

Use Directions - Handheld Unit
1 1
Charge Battery
This side is fully
illuminated when charged.
(90 minute charge time)
Note: If wet, the battery will not work or charge. Keep
liquids from touching battery and charger contacts.
Wipe battery and charger contacts with dry cloth
immediately if they come into contact with liquids.
2 2
Remove Cap/Tank
Rotate collar to unlock
icon position.
Pull locking ring to
remove.
Lift unit off the tank.
3 3
Fill Tank
Performex RTU:
Fill tank with solution from the
bottle.
This is a ready-to-use product. Do
not mix with water or any other
chemicals. Do not use on glass,
plexiglass or floors.
See product label for full
directions for use.
317.923.3211
BHC
WWW.BHCINC.COM
ISO 9001:2015 CERTIFIED
Performex RTU
Product No.
161051-04
4 4
Connect Tank
5 5
Adjust Nozzle
Large
(110)
6 6
Spray
7 7
Clean Up
Performex RTU
Product No. 161051-04
For equipment questions and
service contact:
Victory Innovations Tech Support
800.741.7788
Align tank grooves into
slide rail, lower machine
onto tank. (Listen for a
"click")
Rotate collar to lock icon
position.
Rotate the nozzle to select
the GREEN (80 micron)
Medium
setting.
(80)
BHC recommends 80
micron nozzles for use with
our disinfectants.
Small
(40)
Turn on the unit and squeeze the trigger.
Optimum sprayer distance is 2 feet (24 inches).
Remove tank. Refer to product
label for proper disposal of unused
solution.
It is important to rinse the tank
and spray clean water through the
sprayer at the end of each day to
prevent buildup.
For preventative maintenance:
Rinse nozzle with hot soapy
water 1-2x per week. (Instructions
for nozzle removal and wrench
included in case.)
CLEANPOINT
Victory
Handheld Unit
Product No.
VSHAND
point by point training
