Brulin Victory Innovations VP200ESK Use Directions

Victory Sprayer
Use Directions - Handheld Unit
1

Charge Battery

This side is fully
illuminated when
charged.
(2 hour charge time)
Note: If wet, the battery will not work or charge. Keep
liquids from touching battery and charger contacts. Wipe
battery and charger contacts with dry cloth immediately if
they come into contact with liquids.
2

Remove Tank

3

Fill Tank

BruTab 6S:
If using pre-diluted BruTab
6S solution, fill the tank with
disinfectant solution.
For Disinfectant Solution use
3.3g tablet as follows:
1. Fill reservoir with 1 quart (32
oz) clean water.
2. For minimum 5382 ppm (4
minute TB) add 5 tablets.
3. For minimum 4306 ppm (4
minute C. diff, 1 minute Norovirus
and Bloodborne pathogens) add
4 tablets.
4. For a minimum 1076 ppm (10
minute Hospital Use) add 1 tablet.
Allow to completely dissolve
before using.
BruTab 6S
Product No. 161021-8G
317.923.3211
BHC
WWW.BHCINC.COM
ISO 9001:2008 CERTIFIED
Rotate collar to unlock
icon position.
Pull locking ring to
remove.
Lift unit off the tank.
Performex: Performex
RTU:
Fill tank
with diluted
Fill tank with
solution from
solution from
the dispenser.
the bottle.
Performex Performex RTU
Product No. 161052-33 Product No. 161051-Q6
4

Connect Tank

5

Adjust Nozzle

Medium
6

Spray

Turn on the unit and squeeze the
trigger. Optimum sprayer distance is 2
feet (24 inches).
7

Clean Up

CLEANPOINT
point by point training
Align tank grooves
into slide rail,
lower machine
onto tank. (Listen
for a "click")
Rotate collar to
lock icon position.
Rotate the nozzle
to select the
medium (80
micron) or large
Large
(110 micron)
setting.
BHC recommends
80 and 110
Small
micron nozzles
for use with our
disinfectants.
Remove tank,
Refer to product label for
proper disposal of unused
solution.
Rinse tank with water.
For preventative
maintenance: Rinse nozzle
with hot water after every
couple of uses. (Instructions
for nozzle removal and
wrench included in case.)
