- Page 1 INSTALLATION, MIRUS International Inc. OPERATION AND MAINTENANCE GUIDE LINEATOR™ AUTOTRANS AUTOTRANSFORMER AND UNIVERSAL HARMONIC FILTER ATL-M001-A2...
-
Page 2: Important Safety Instruction
LINEATOR™ AUTOTRANS IMPORTANT SAFETY INSTRUCTION SAVE THESE INSTRUCTIONS - This manual contains important instructions for the AutoTransLineator that must be followed during installation, operation, and maintenance of the AutoTransLineator and its auxiliary equipment. WARNING OPENING ENCLOSURES EXPOSES HAZARDOUS VOLTAGES. ALWAYS REFER SERVICE TO QUALIFIED PERSONNEL ONLY. - Page 3 MAINTENANCE GUIDE ATL-M001-A2 3-Feb-2010 MIRUS International Inc. 31 Sun Pac Blvd. Brampton, Ontario Canada L6S 5P6 1 - 888 - TO – MIRUS (1 - 888 - 866 – 4787) Tel: (905) 494-1120 Fax: (905) 494-1140 E-Mail: mirus@mirusinternational.com Website: www.mirusinternational.com ATL-M001-A2...
- Page 4 (an “RMA”) from MIRUS. The Customer must return the defective unit to MIRUS, freight prepaid, within sixty (60) days of receipt of the RMA and must include a copy of MIRUS’ paid invoice for the defective unit and a description of the defective unit’s failure to conform.
- Page 5 Operation & Maintenance Manual Contents Section Description Page Installation ……………………………………………. Location ………………………………………………. Inspection …………………………………………….. Handling ………………………………………………. Grounding …………………………………………….. Storage ………………………………………………… Maintenance …………………………………………... Periodic Inspection and Maintenance ……………… Cleaning ……………………………………………….. Drying of Core and Coil Assembly ………………….. Operation ………………………………………………. Effect of Humidity ……………………………………… 3 Loading ………………………………………………….
- Page 6 LINEATOR™ AUTOTRANS ATL-M001-A2...
-
Page 7: Installation
Operation & Maintenance Manual 1.0 Installation 1.2 Inspection Upon receipt shipment WARNING ™ should be inspected for any INEATOR AUTOTRANS damage incurred during shipment. Before energization an internal inspection should be Danger! There is the potential of conducted with emphasis on loose or broken electric shock whenever working connections, damaged or displaced parts, cracked in or around electrical equipment... -
Page 8: Maintenance
LINEATOR™ AUTOTRANS 3.0 Maintenance 3.2 Cleaning WARNING Excessive accumulations of dirt on the transformer windings or insulators and capacitor terminals should be removed to permit free circulation of air Internal maintenance must and to guard against the possibility of insulation performed with a transformer de- breakdown. -
Page 9: Operation
Operation & Maintenance Manual 4.0 Operation WARNING Internal maintenance must performed with a transformer de- energized, isolated and with the terminals grounded. Caution: Do not remove covers, panels, or any ™ is INEATOR enclosure parts while the AUTOTRANS energized. 4.1 Effect of Humidity ™... - Page 10 LINEATOR™ AUTOTRANS NOTES ATL-M001-A2...
- Page 11 Operation & Maintenance Manual ATL-M001-A2...
- Page 12 MIRUS International Inc. 31 Sun Pac Blvd. Brampton, Ontario Canada L6S 5P6 1 - 888 - TO – MIRUS (1 - 888 - 866 – 4787) Tel: (905) 494-1120 Fax: (905) 494-1140 E-Mail: mirus@mirusinternational.com Website: www.mirusinternational.com...
