  • Page 1 VOLVO S60 Owner's Manual Web Edition...
  • Page 3 Welcome to the world-wide family of Volvo owners. We trust that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. We encourage you to familiarize yourself with the equipment descriptions and operating instructions in this manual.

  • Page 4: Table Of Contents

    Contents 00 Introduction General information... 10 Volvo and the environment... 11 Important warnings... 13 01 Safety Occupant safety... 16 Seat belts... 18 Supplemental Restraint System... 20 Front airbags... 21 Occupant Weight Sensor (OWS)... 25 Side impact (SIPS) airbag... 28 Volvo Inflatable Curtain (VIC)... 29 Whiplash Protection System (WHIPS)...
  • Page 5 03 Climate Climate control systems - general infor- mation... 86 Air distribution... 88 Electronic climate control, ECC... 89 04 Interior Front seats... 94 Interior lighting... 97 Storage compartments... 99 Rear seat and trunk... 102 Spare wheel, tools and jack... 105 Contents 05 Locks and alarm Keys...
  • Page 6 Contents 06 Starting and driving General information... 120 Fuel requirements... 121 Refueling... 122 Starting the vehicle... 124 Economical driving... 127 Handling and road holding... 128 Manual transmission... 129 Automatic transmission (option)... 130 All Wheel Drive (option)... 134 Brake system... 135 Stability system...
  • Page 7 09 Maintenance and servicing Volvo service... 184 Maintaining your vehicle... 185 Emission inspection readiness... 186 Working on your vehicle... 187 Hood and engine compartment... 189 Engine oil... 190 Fluids... 192 Wiper blades... 194 Battery... 195 Replacing bulbs... 198 Fuses... 206 10 Audio Introduction...
  • Page 8 Contents 12 Index Index... 248...
  • Page 9 Contents...

  • Page 10: Introduction

    For this reason, it should be kept in the vehicle for ready access. • Do not export your Volvo to another coun- try before investigating that country's applicable safety and exhaust emission requirements. In some cases it may be dif- ficult or impossible to comply with these requirements.

  • Page 11: Volvo And The Environment

    State of Cali- fornia to cause cancer, and birth defects or other reproductive harm. Volvo is committed to the well being of its cus- tomers. As a natural part of this commitment, we care about the environment in which we all live.
  • Page 12 Introduction Volvo and the environment WARNING Certain components of this vehicle such as air bag modules, seat belt pretensioners, adaptive steering columns, and button cell batteries may contain Perchlorate material. Special handling may apply for service or vehicle end of life disposal.

  • Page 13: Important Warnings

    Additionally, a trained and qualified Volvo service technician knows where accessories may and may not be safely installed in your Volvo. In all cases, please consult a trained and qualified Volvo serv- ice technician before installing any acces- sory in or on your vehicle.
  • Page 14 Seat belts... 18 Supplemental Restraint System... 20 Front airbags... 21 Occupant Weight Sensor (OWS)... 25 Side impact (SIPS) airbag... 28 Volvo Inflatable Curtain (VIC)... 29 Whiplash Protection System (WHIPS)... 30 Child safety... 32 Child restraint systems... 34 Infant seats... 36 Convertible seats...
  • Page 15 S A F E T Y...

  • Page 16: 01 Safety

    Occupant safety Volvo's concern for safety Safety is the Volvo cornerstone. Our concern dates back to 1927 when the first Volvo rolled off the production line. Three-point seat belts (a Volvo invention), safety cages, and energy- absorbing impact zones were designed into Volvo vehicles long before it was fashionable or required by government regulation.
  • Page 17 If you believe your vehicle has a defect that could cause a crash or could cause injury or death, you should immediately inform Trans- port Canada in addition to notifying Volvo Cars of Canada Corp. To contact Transport Canada, call (800) 333-0510, or (613) 993-9851 if you are calling from the Ottawa region.

  • Page 18: Seat Belts

    Children should be prop- erly restrained, using an infant, car, or booster seat determined by age, weight and height. Volvo also believes that no child should sit in the front seat of a vehicle. Most states and provinces make it mandatory for occupants of a vehicle to use seat belts.
  • Page 19 • Never repair the belt yourself; have this work done by an authorized Volvo serv- ice technician only. • Any device used to induce slack into the...

  • Page 20: Supplemental Restraint System

    Supplemental Restraint System (SRS) SRS warning light As an enhancement to the three-point seat belts, your Volvo is equipped with a Supple- mental Restraint System (SRS). Volvo's SRS consists of seat belt pretensioners, front air- bags, side impact airbags, the occupant weight sensor, and inflatable curtains.

  • Page 21: Front Airbags

    The front airbag system The front airbags supplement the three-point seat belts. For these airbags to provide the protection intended, seat belts must be worn at all times. The front airbag system includes gas genera- tors surrounded by the airbags, and decelera- tion sensors that activate the gas generators, causing the airbags to be inflated with nitrogen gas.
  • Page 22 This is a normal characteristic and does not indicate fire. • Volvo's front airbags use special sen- sors that are integrated with the front seat buckles. The point at which the air- bag deploys is determined by whether or not the seat belt is being used, as well as the severity of the collision.
  • Page 23 Customer Care Center P.O. Box 914 Rockleigh, New Jersey 07647-0914 1-800-458-1552 www.volvocars.us In Canada Volvo Cars of Canada Corp. National Customer Service 175 Gordon Baker Road North York, Ontario M2H 2N7 1-800-663-8255 www.volvocanada.com See also the Occupant Weight Sensor information on page 25.
  • Page 24 Never try to open the airbag cover on the steering wheel or the passenger's side dashboard. This should only be done by a trained and qualified Volvo service technician. Failure to follow these instructions can result in injury to the vehicle occupants.

  • Page 25: Occupant Weight Sensor (Ows)

    Disabling the passenger's side front airbag Occupant Weight Sensor (OWS) indicator light Volvo recommends that ALL occupants (adults and children) shorter than 4 feet 7 inches (140 cm) be seated in the rear seat of any vehi- cle with a passenger's side front airbag, and be properly restrained.

  • Page 26: Occupant Weight Sensor (Ows)

    In this case, the safety systems and Occu- pant Weight Sensor should be inspected by a trained and qualified Volvo service tech- nician as soon as possible. WARNING •...
  • Page 27 Volvo at: In the USA Volvo Cars of North America, LLC Customer Care Center P.O. Box 914 Rockleigh, New Jersey 07647-0914 1-800-458-1552 In Canada Volvo Cars of Canada Corp.

  • Page 28: Side Impact (Sips) Airbag

    Never try to open or repair any compo- nents of the SIPS airbag system. This should be done only by a trained and qualified Volvo service technician. • In order for the SIPS airbag to provide its best protection, both front seat occupants should sit in an upright posi- tion with the seat belt properly fastened.

  • Page 29: Volvo Inflatable Curtain (Vic)

    Never hang heavy items from the ceiling handles. This could impede deployment of the Inflatable curtain. 01 Safety Volvo Inflatable Curtain (VIC) WARNING In order for the VIC to provide its best pro- tection, both front seat occupants and both...

  • Page 30: Whiplash Protection System (Whips)

    01 Safety Whiplash Protection System (WHIPS) Whiplash Protection System (WHIPS) – front seats only The WHIPS system consists of specially designed hinges and brackets on the front seat backrests designed to help absorb some of the energy generated in a collision from the rear (when the vehicle is "rearended").
  • Page 31 If your vehicle has been involved in a rear-end collision, the front seat backr- ests must be inspected by a trained and qualified Volvo service technician, even if the seats appear to be undamaged. Certain components in the WHIPS sys- tem may need to be replaced.

  • Page 32: Child Safety

    01 Safety Child safety Children should be seated safely Volvo recommends the proper use of restraint systems for all occupants including children. Remember that, regardless of age and size, a child should always be properly restrained in a vehicle. Your vehicle is also equipped with ISOFIX/ LATCH attachments, which make it more con- venient to install child seats.
  • Page 33 Volvo's recommendations Why does Volvo believe that no child should sit in the front seat of a vehicle? It's quite simple really. A front airbag is a very powerful device designed, by law, to help protect an adult.

  • Page 34: Child Restraint Systems

    01 Safety Child restraint systems Child restraints Infant seat There are three main types of child restraint systems: infant seats, convertible seats, and booster cushions. They are classified accord- ing to the child's age and size. The following section provides general infor- mation on securing a child restraint using a three-point seat belt.
  • Page 35 • A small child's head represents a con- siderable part of its total weight and its neck is still very weak. Volvo recom- mends that children up to age 4 travel, properly restrained, facing rearward. In addition, Volvo recommends that chil- dren should ride rearward facing, prop- erly restrained, as long as possible.

  • Page 36: Infant Seats

    01 Safety Infant seats Securing an infant seat with a seat belt Do not place the infant seat in the front passeng- er's seat NOTE Refer to 41 for information on securing a child restraint using ISOFIX lower anchors and/or top tether anchorages. 1.
  • Page 37 Fasten the seat belt Pull out the shoulder section of the seat belt 4. Pull the shoulder section of the seat belt out as far as possible to activate the belt's automatic locking function. NOTE The locking retractor will automatically release when the seat belt is unbuckled and allowed to retract fully.

  • Page 38: Convertible Seats

    • A small child's head represents a con- siderable part of its total weight and its neck is still very weak. Volvo recom- mends that children up to age 4 travel, properly restrained, facing rearward. In addition, Volvo recommends that chil- dren should ride rearward facing, prop- erly restrained, as long as possible.
  • Page 39 Fasten the seat belt 3. Fasten the seat belt by inserting the latch plate into the buckle (lock) until a distinct click is audible. 4. Pull the shoulder section of the seat belt out as far as possible to activate the belt's automatic locking function.

  • Page 40: Booster Cushions

    01 Safety Booster cushions Securing a booster cushion Position the child correctly on the booster cushion and positioning the seat belt Booster cushions are recommended for chil- dren who have outgrown convertible seats. 1. Place the booster cushion in the rear seat of the vehicle.

  • Page 41: Isofix Lower Anchors

    Using the ISOFIX lower child seat anchors ISOFIX lower child restraint anchors Lower anchors for ISOFIX-equipped child seats are located in the rear, outboard seats, hidden below the backrest cushions. Symbols on the seat back upholstery mark the anchor positions (see the illustration). To access the anchors: 1.
  • Page 42 01 Safety ISOFIX lower anchors WARNING • Be sure to fasten the attachment cor- rectly to the anchor (see the illustration). If the attachment is not correctly fas- tened, the child restraint may not be properly secured in the event of a colli- sion.

  • Page 43: Top Tether Anchors

    Top tether anchors Top tether anchorage points Your Volvo is equipped with child restraint top tether anchorages in all rear seat positions. Using the top tether anchorages 1. Place the child restraint on the rear seat. WARNING Be sure to fasten the child tether attachment correctly to the anchor.

  • Page 44: Child Restraint Registration And Recalls

    01 Safety Child restraint registration and recalls Registering a child restraint Child restraints could be recalled for safety reasons. You must register your child restraint to be reached in a recall. To stay informed about child safety seat recalls, be sure to fill out and return the registration card that comes with new child restraints.
  • Page 45 01 Safety...
  • Page 46 Instrument overview... 48 Instrument panel... 50 Indicator and warning symbols... 52 Buttons in the center console... 56 Steering wheel adjustment... 58 Lighting panel... 59 Fuel filler door–unlocking manually... 61 Left-side steering wheel lever... 62 Right-side steering wheel lever... 64 Hazard warning flashers, door mirror defroster... 66 Trip computer...
  • Page 47 I N S T R U M E N T S A N D C O N T R O L S...

  • Page 48: 02 Instruments And Controls

    02 Instruments and controls Instrument overview...
  • Page 49 Front fog lights Headlights/Parking lights/ switch for unlocking fuel filler door Rear fog light Turn signals/High/low beams Cruise control Horn Instrument panel Audio controls in steering wheel 02 Instruments and controls Windshield wipers Parking brake (hand brake) Center console buttons Climate control Audio system 12-V socket...

  • Page 50: Instrument Panel

    02 Instruments and controls Instrument panel Instrument panel Turn signal indicators – right/left Text window – The text window displays information and warning messages. Temperature gauge – The pointer should be approximately midway on the gauge when driving. Do not drive the vehicle if the warning light is on.
  • Page 51 02 Instruments and controls Instrument panel Gear and driving mode indicator – The cur- rently selected driving mode is displayed here. If you use the Geartronic function on the automatic transmission, the currently selected gear will be displayed. Ambient temperature gauge – This display indicates the air temperature outside your vehicle.

  • Page 52: Indicator And Warning Symbols

    Have the system(s) inspected by a trained and qualified Volvo service technician as soon as possible. BRAKE - Brake failure warning light If the light comes on while driving or braking,...
  • Page 53 " message is displayed in the text window: DO NOT DRIVE. Have the vehicle towed to a trained and qualified Volvo serv- ice technician and have the brake system inspected. On certain engines, the symbol for low oil pressure is not used. Instead, a text warning is provided in the information display.
  • Page 54 ABS system (the standard braking system will still function). The vehicle should be driven to a trained and qualified Volvo service technician for inspection. For additional information, see page 135. Dynamic Stability Traction Control (DSTC) system...
  • Page 55 Refer to your owner's manual. For additional information, please contact your Volvo retailer. Take your vehicle to a trained and qualified Volvo service technician for inspection at your convenience (but preferably before the next scheduled maintenance service). Have the system affected inspected at the next scheduled maintenance service.

  • Page 56: Buttons In The Center Console

    02 Instruments and controls Buttons in the center console The positions of these button may vary, depending on the specifications of the vehicle. Folding head restraints This button is used to fold down the outboard rear head restraints. The ignition key must be in position I or II or the engine must be running.
  • Page 57 1 (or higher) for the auxiliary socket to function. NOTE The auxiliary sockets can also be used for cigarette lighters, which are available at your Volvo retailer. 02 Instruments and controls Front/rear park assist (option/ accessory) See page 150 for more infor- mation on this function.

  • Page 58: Steering Wheel Adjustment

    02 Instruments and controls Steering wheel adjustment Both the height and the reach of the steering wheel can be adjusted to a comfortable posi- tion for the driver. Pull down the lever on the left of the steering column. Adjust the steering wheel to a suitable position and press the lever back into place to lock the steering wheel in the new position.

  • Page 59: Lighting Panel

    3501866m Headlight/parking light switch Front fog lights Rear fog light Instrument panel lighting Fuel filler door unlock button On Canadian models, the daytime running lights will remain on with the light switch in this position. 02 Instruments and controls Parking lights The front and rear parking lights can be turned on even when the ignition is switched off.
  • Page 60 02 Instruments and controls Lighting panel Fog lights Front fog lights (option) The front fog lights can be used in combination with either the headlights or the parking lights. • Turn the ignition key to position II. • Press button 2 to turn on the front fog lights.

  • Page 61: Fuel Filler Door-Unlocking Manually

    Manually unlocking the fuel filler door The electric motor that controls the fuel filler door locking mechanism is located on the inside of the rear fender on the passenger side of the vehicle, just behind the fuel filler door. To unlock this door manually: 1.

  • Page 62: Left-Side Steering Wheel Lever

    02 Instruments and controls Left-side steering wheel lever Lever positions Turn signals, lane change position Turn signals, position for normal turns High beam flash Toggle between high and low beams, Home Safe lighting Turn signals When changing lanes The driver can automatically flash the turn sig- nals 3 times by moving the turn signal lever up or down to position 1 and releasing it.
  • Page 63 > The headlights and parking lights will illuminate and remain on for 30 , 60 or 90 seconds. The time interval can be changed by a trained and qualified Volvo service technician. Factory setting 02 Instruments and controls Left-side steering wheel lever...

  • Page 64: Right-Side Steering Wheel Lever

    02 Instruments and controls Right-side steering wheel lever Windshield wipers Thumb wheel Rain sensor on/off Windshield wipers off Single sweep function If the lever is in the 0 position and you move it upwards, the wipers will sweep one stroke at a time for as long as you hold the lever up.
  • Page 65 Move the windshield wiper lever down to another position. > Moving the lever up will not deactivate the rain sensor. Doing so will cause the wipers to sweep the windshield until the lever is released, at which time the wip- ers return to rain sensor mode.

  • Page 66: Hazard Warning Flashers, Door Mirror Defroster

    02 Instruments and controls Hazard warning flashers, door mirror defroster Hazard warning flashers The four-way flasher should be used to indi- cate that the vehicle has become a traffic haz- ard. To activate the flashers, press the triangu- lar button in the center dash. Press the button again to turn off the flashers.

  • Page 67: Trip Computer

    READ (press to acknowledge/confirm/ erase a message) Thumb wheel (used to scroll among the trip computer menus) RESET The trip computer stores information gathered from several systems in your vehicle and has four menus that can be displayed in the text window.
  • Page 68 02 Instruments and controls Trip computer 5. Current speed in miles per hour (Canadian models only) This function provides the driver with an instan- taneous conversion of the vehicle's current speed from km/h to mph. NOTE Trip computer readings may vary slightly depending on the circumference of the tires on the vehicle and driving style.

  • Page 69: Cruise Control

    The cruise control panel is located on the left side of the steering wheel hub and may differ in appearance, depending on the model. Engaging cruise control Press the CRUISE button. > CRUISE will be displayed in the infor- mation window in the instrument panel. NOTE This does not set the vehicle's speed.
  • Page 70 02 Instruments and controls Cruise control NOTE Cruise control is automatically disengaged • the engine is switched off • the gear selector is placed in (N)eutral • the wheels start to spin or lock • if an increase in speed is maintained for more than one minute •...

  • Page 71: Parking Brake

    The parking brake lever is located between the front seats. NOTE The indicator light will light up even if the parking brake has only been partiallyap- plied. When applying the parking brake 1. Press firmly on the brake pedal. 2. Pull the parking brake lever up firmly to its full extent.

  • Page 72: 12-Volt Socket

    The auxiliary sockets can also be used for cig- arette lighters, which are available at your Volvo retailer. Volvo vehicles in North America do not have an ashtray in the front seat as standard equip- ment. If you want to have an ashtray in the front...

  • Page 73: Power Windows

    A. Front windows. B. Rear windows. The power windows are controlled by buttons in the arm rests. The ignition switch must be (ignition key in position I, II or the engine running) for the electrically operated windows to function. To lower: Press down the front edge of the but- ton to the first detent ("stop").
  • Page 74 02 Instruments and controls Power windows If the LED in the switch is OFF The rear door windows can be raised or low- ered with the buttons on the rear door armrests or with the buttons on the driver's door arm- rest.

  • Page 75: Mirrors

    Rearview mirror To reduce glare from the headlights of follow- ing vehicles, use the control to switch between the normal and night-driving positions. A. Normal position B. Night position, reduces glare from follow- ing headlights Autodim function (option) The autodim function reacts to headlights from following traffic and automatically reduces glare.
  • Page 76 02 Instruments and controls Mirrors To do so: 1. Switch the ignition to position II. 2. Press the button on the rear side of the mirror with straightened paperclip or simi- lar object for approximately 3 seconds until ZONE is displayed. >...
  • Page 77 After you have adjusted the mirror(s), press the L or R switch again (the LED will go out) to deactivate the adjustment control. WARNING The mirrors should always be adjusted prior to driving. Objects seen in the passenger's side wide-angle door mirror are closer than they appear to be.

  • Page 78: Power Moonroof (Option)

    02 Instruments and controls Power moonroof (option) To operate the moonroof, turn the ignition key to position I or II, or start the engine. The moon- roof can be operated in two ways: Tilt position Sliding moonroof Tilt position Open: With the moonroof closed, push up the rear edge of the switch (position 5 in the illus- tration in the center column).
  • Page 79 Sun visor The optional moonroof also features a sliding sun visor. The visor slides open automatically when the moonroof is opened. The visor must be closed manually. WARNING The moonroof must never be obstructed in any way when in operation. 02 Instruments and controls Power moonroof (option)

  • Page 80: Homelink® Wireless Control System (Option)

    02 Instruments and controls HomeLink® Wireless Control System (option) Introduction The HomeLink Wireless Control System pro- vides a convenient way to replace up to three hand-held radio-frequency (RF) transmitters used to activate devices such as gate opera- tors, garage door openers, entry door locks, security systems, even home lighting.
  • Page 81 NOTE Some devices may require you to replace this Programming Step 2 with procedures noted in the “Gate Operator / Canadian Pro- gramming” section. If the HomeLink indica- tor light does not change to a rapidly blinking light after performing these steps, contact HomeLink at www.homelink.com.
  • Page 82 02 Instruments and controls HomeLink® Wireless Control System (option) Erasing HomeLink Buttons To erase programming from the three Home- Link buttons (individual buttons cannot be erased but can be “reprogrammed” as outlined below), follow the step noted: • Press and hold the two outer HomeLink buttons until the indicator light begins to flash-after 10 seconds.
  • Page 83 02 Instruments and controls...
  • Page 84 Climate control systems - general information... 86 Air distribution... 88 Electronic climate control, ECC... 89...
  • Page 85 C L I M A T E...

  • Page 86: 03 Climate

    Special tools and equipment are required to maintain and carry out repairs on the climate system. Work of this type should only be done by a trained and qualified Volvo service tech- nician. Refrigerant Volvo cares about the environment. The air conditioning system in your vehicle contains a CFC-free refrigerant - R134a (HFC134a).
  • Page 87 03 Climate Climate control systems - general information Passenger compartment blower The passenger compartment blower may start automatically during a period of up to approx- imately 50 minutes after the ignition has been turned off to remove condensation in the A/C evaporator.

  • Page 88: Air Distribution

    03 Climate Air distribution Air distribution The incoming air is distributed through 14 ven- tilation points in the passenger compartment. Air vents in the dash Open Closed Horizontal air flow Vertical air flow • Direct the outer air vents toward the side windows to defrost.

  • Page 89: Electronic Climate Control, Ecc

    A/C off/on Recirculation/Multifilter with sensor Recirculation AUTO Air distribution Passenger compartment temperature sen- Defroster - windshield and side windows Rear window and door mirrors defroster Heated front seats (option) Temperature passenger´s side Temperature driver´s side Blower AUTO This function automatically reg- ulates the Electronic Climate Control system so that the selected temperatures are...
  • Page 90 03 Climate Electronic climate control, ECC Blower control Turn the control clockwise to increase or counterclockwise to decrease the blower speed. Pressing the AUTO switch will automatically reg- ulate blower speed and over- ride manual adjustment. Turning the blower control counterclockwise until an orange LED comes on will turn both the blower and the air conditioning off.
  • Page 91 • Timer mode activation: (vehicles with the Interior Air Quality system have no timer mode) Press and hold the recirculation but- ton for at least 3 seconds to activate a recirculation timer mode. The amber LED in the recirculation button will flash 5 times to show that the timer mode is being acti- vated.
  • Page 92 Front seats... 94 Interior lighting... 97 Storage compartments... 99 Rear seat and trunk... 102 Spare wheel, tools and jack... 105...
  • Page 93 I N T E R I O R...

  • Page 94: 04 Interior

    04 Interior Front seats Manually adjusted front seats 1. Front-rear adjustment: lift the bar and move the seat to the position of your choice. 2. Raise/lower the front edge of the seat cushion (option): use the control to pump the front edge of the cushion up or down. 3.
  • Page 95 Front - rear Rear edge of seat (raise/lower) Backrest tilt Seat adjustment If your Volvo is equipped with power seats, the following may be adjusted with the two switches at the side of the seat: NOTE The power seats have an overload protector that activates if a seat is blocked by any object.
  • Page 96 04 Interior Front seats WARNING • Because the driver's seat can be adjusted with the ignition off, children should never be left unattended in the vehicle. • Movement of the seat can be STOPPED at any time by pressing any button on the power seat control panel.

  • Page 97: Interior Lighting

    The automatic function can be disconnected by pressing button 2 for more than 3 seconds. Briefly pressing the button again automatically reconnects the function. The courtesy light timer periods can be changed. Contact a trained and qualified Volvo service technician.
  • Page 98 04 Interior Interior lighting Vanity mirror The light comes on when you open the cover. Glove compartment lighting The lighting in the glove compartment switches on or off when its door is opened or closed.

  • Page 99: Storage Compartments

    04 Interior Storage compartments...
  • Page 100 04 Interior Storage compartments Storage compartment in door Storage pocket in front edge of front seat Glove compartment Storage compartment and cup holders in center console, see page 100 for more information Storage space and cup holders in rear seat armrest Storage pocket in rear side of front seats WARNING...
  • Page 101 Cup holders in the center console To remove the cup holders: 1. Press the cup holder forward (1), while lift- ing the rear edge (2). 2. Move the cup holder rearward (3), into the groove under the sliding cover. 3. Angle the front edge of the cup holder upward (4) and lift it out.

  • Page 102: Rear Seat And Trunk

    04 Interior Rear seat and trunk Folding the rear seat backrest 8503282m Backrest release handles in trunk Both rear seat backrests can be folded down, together or individually to enable you to trans- port long objects. Fold the rear seat backrests as follows: 1.
  • Page 103 Carrying long loads (ski hatch) The center backrest cushion folds forward, allowing you to transport long, light cargo such as skis in the trunk of your vehicle. To lower the backrest: 1. Pull the right release control handle in the trunk to release the backrest, see page 102.
  • Page 104 04 Interior Rear seat and trunk WARNING The center rear seat head restraint should only be in its lowest position when this seat is NOT occupied. When the center position is occupied, the head restraint should be correctly adjusted to the passenger’s height.

  • Page 105: Spare Wheel, Tools And Jack

    Spare wheel* Securing bracket Tool bag* with towing eyelet Jack* The spare wheel, jack and tool bag are located under the floor of the trunk. To access the spare tire: 1. Pull up the floor mats. 2. Remove the jack and tool bag. 3.
  • Page 106 Keys... 108 Remote control... 109 Locking and unlocking... 112 Child safety locks... 114 Alarm... 116...
  • Page 107 L O C K S A N D A L A R M...

  • Page 108: 05 Locks And Alarm

    The vehicle will start only with a properly coded key. Each key has a unique code, which your Volvo retailer uses if new keys are required. A maxi- mum of six remote controls/keys can be pro- grammed and used for one vehicle.

  • Page 109: Remote Control

    The vehicle can also be locked/ unlocked with the key. If one of the transmitters is misplaced, a replacement can be purchased from your near- est authorized Volvo retailer. Using the remote control Unlock Open trunk "Panic" function...
  • Page 110 05 Locks and alarm Remote control • FCC ID:LQNP2T-APU This device complies with part 15 of the FCC rules. Operation is subject to the following conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 111 3. Press the cover back into place. Ensure that the rubber seal is correctly positioned to help keep out moisture. NOTE The old battery should be disposed of prop- erly at a recycling center or at your Volvo retailer. 05 Locks and alarm Remote control...

  • Page 112: Locking And Unlocking

    05 Locks and alarm Locking and unlocking Locking and unlocking the vehicle from the inside The button on the driver's door armrest can be used to lock or unlock all doors and the trunk, and to set the alarm. Each door can also be locked with the lock button on the respective door and opened by pulling the door handle on the door.
  • Page 113 NOTE If the trunk is opened with the master key, the alarm will sound. To turn off the alarm, unlock the driver's door with the master key. Opening/locking the trunk lid with the remote control Do as follows to unlock the trunk lid only: 1.

  • Page 114: Child Safety Locks

    05 Locks and alarm Child safety locks Manual child safety locks - rear doors Control for child safety lock - left rear door The controls are located on the rear door jambs. Use the ignition key or a screwdriver to adjust these controls.
  • Page 115 05 Locks and alarm Child safety locks Disarming the alarm Press the UNLOCK button on the remote con- trol or unlock the doors with the key. Turning off (stopping) the alarm If the alarm is sounding, it can be stopped by pressing the UNLOCK button on the remote control or by unlocking the driver's door with the key.

  • Page 116: Alarm

    05 Locks and alarm Alarm Visual alarm signal The visual alarm signal is given by flashing all turn signals and turning on the interior lighting for approximately 5 minutes. Audible alarm signal An audible alarm signal is given by a battery powered siren.
  • Page 117 Fault in the alarm system: If a fault has been detected in the alarm system, a mes- sage will be displayed in the text window. Contact a trained and qualified Volvo serv- ice technician. Automatic re-lock/re-arm system If the vehicle is unlocked with the remote, the...
  • Page 118 General information... 120 Fuel requirements... 121 Refueling... 122 Starting the vehicle... 124 Economical driving... 127 Handling and road holding... 128 Manual transmission... 129 Automatic transmission (option)... 130 All Wheel Drive (option)... 134 Brake system... 135 Stability system... 138 Towing... 140 Jump starting...
  • Page 119 S T A R T I N G A N D D R I V I N G...

  • Page 120: 06 Starting And Driving

    To meet sea- sonal air quality standards, some areas require the use of "oxygenated" fuel. Volvo allows the use of the following "oxygen- ated" fuels; however, the octane ratings listed on this page must still be met.

  • Page 121: Fuel Requirements

    Typical pump octane label Volvo recommends premium for best perform- ance, but using 87 octane or above will not affect engine reliability. Volvo engines are designed to achieve rated horsepower, torque, and fuel economy per- formance using premium 91 octane fuel. Demanding driving...

  • Page 122: Refueling

    Volvo service technician for correction. WARNING Driving with the trunk open: Driving with the trunk open could lead to poisonous exhaust gases entering the passenger com- partment.
  • Page 123 If the fuel filler cap is not closed tightly or if the engine is running when the vehicle is refueled, the Check Engine Light (malfunction indicator lamp) may indicate a fault. However, your vehicle's performance will not be affected. Use only Volvo original or approved fuel filler caps.

  • Page 124: Starting The Vehicle

    06 Starting and driving Starting the vehicle Starting the engine WARNING Before starting, check that the seat, steering wheel and mirrors are adjusted properly. Make sure the brake pedal can be depressed completely. Adjust the seat if necessary. See pages 94 and 94. 1.
  • Page 125 WARNING Always place the gear selector in Park or in reverse on models with a manual transmis- sion, and apply the parking brake before leaving the vehicle. Never leave the vehicle unattended with the engine running. Always open garage doors fully before star- ting the engine inside a garage to ensure adequate ventilation.
  • Page 126 06 Starting and driving Starting the vehicle WARNING Never switch off the ignition (turn the ignition key to position 0) or remove the key from the ignition switch while the vehicle is in motion. This could cause the steering wheel to lock, which would make the vehicle impossible to steer.

  • Page 127: Economical Driving

    Economical driving conserves natural resources Better driving economy may be obtained by thinking ahead, avoiding rapid starts and stops and adjusting the speed of your vehicle to immediate traffic conditions. Observe the fol- lowing rules: • Bring the engine to normal operating tem- perature as soon as possible by driving with a light foot on the accelerator pedal for the first few minutes of operation.

  • Page 128: Handling And Road Holding

    06 Starting and driving Handling and road holding Weight distribution affects handling At the specified curb weight your vehicle has a tendency to understeer, which means that the steering wheel has to be turned more than might seem appropriate for the curvature of a bend.

  • Page 129: Manual Transmission

    6-speed manual transmission (option on certain models) Depress the clutch pedal completely when changing gears Remove your foot from the clutch pedal while driving. The shift pattern should be followed. Fifth and sixth gears should be used as often as possible to help improve fuel economy. Clutch interlockThe clutch must be fully depressed before you can start your vehicle.

  • Page 130: Automatic Transmission (Option)

    06 Starting and driving Automatic transmission (option) P (Park) Use this position when starting the engine or parking the vehicle. CAUTION The vehicle must be stationary when posi- tion P is selected. The parking brake should be set whenever the vehicle is parked.
  • Page 131 W - Winter/Wet driving mode - enhanced vehicle traction Press the button at the base of the gear selec- tor to engage/disengage this driving mode (see illustration). The symbol will appear in the display (see page 50) when the function is acti- vated.
  • Page 132 06 Starting and driving Automatic transmission (option) Geartronic P (Park) Use this position when starting the engine or parking the vehicle. CAUTION The vehicle must be stationary when posi- tion P is selected. The parking brake should also be set whenever the vehicle is parked.
  • Page 133 The currently selected gear will be displayed in the instrument panel (see page 50). • To access the MAN shifting position from D, move the gear selector to the left to MAN. • To return to the D position from MAN, move the gear selector to the right.

  • Page 134: All Wheel Drive (Option)

    06 Starting and driving All Wheel Drive (option) All Wheel Drive (AWD) - general information Your Volvo can be equipped with permanent All Wheel Drive, which means that power is distributed automatically between the front and rear wheels. Under normal driving condi- tions, most engine's power is directed to the front wheels.

  • Page 135: Brake System

    DO NOT DRIVE window: . Have the vehicle towed to a trained and qualified Volvo serv- ice technician and have the brake system inspected. NOTE When the vehicle is at a standstill and the engine is idling, e.g.
  • Page 136 " message is displayed in the text window: DO NOT DRIVE . Have the vehicle towed to a trained and qualified Volvo serv- ice technician and have the brake system inspected. 4. If both lights are still on after the engine has...
  • Page 137 NOTE • When the EBA system is activated, the brake pedal will go down and pressure in the brake system immediately increa- ses to the maximum level. You must maintain full pressure on the brake pedal in order to utilize the system com- pletely.

  • Page 138: Stability System

    06 Starting and driving Stability system Dynamic Stability Traction Control (DSTC) The stability system consists of a number of functions designed help reduce wheel spin, counteract skidding, and to generally help improve directional stability. NOTE A pulsating sound will be audible when the system is actively operating and is normal.
  • Page 139 ANTI SKID SERVICE REQUIRED " - the system has been automatically disen- gaged due to a fault. A trained and qualified Volvo service technician should check the system. Symbols in the instrument panel The Stability Control indicator light This light indicates different condi- tions, depending on how it illumi- nates.

  • Page 140: Towing

    06 Starting and driving Towing Emergency towing Front towing eyelet The towing eyelet is located in the tool bag, under the floor of the trunk, with the spare tire. This eyelet must be screwed into the positions provided on the right sides of either the front or rear bumper (B, see illustrations).
  • Page 141 Towing vehicles with front wheel drive/ All Wheel Drive Volvo recommends the use of flat bed equip- ment. If wheel lift equipment must be used, please use extreme caution to help avoid damage to the vehicle.

  • Page 142: Jump Starting

    06 Starting and driving Jump starting Jump starting Follow these instructions to jump start your vehicle's dead battery or to jump start another vehicle's dead battery using your vehicle. Although your vehicle's battery is located under the floor of the trunk, jumper cables should be connected in the engine compart- ment, to the points shown in the illustrations.

  • Page 143: Towing A Trailer

    Volvo recommends the use of Volvo trailer hitches that are specially designed for the vehi- cle. • Maximum trailer weight recommended by Volvo is: Trailers without brakes: 1650 lbs (750 kg) Trailers with brakes: 2" (50 mm) ball - 3300 lbs* (1500 kg), 1 7/8 " (47 mm) ball - 2000 lbs (900 kg).
  • Page 144 (using too high a gear). • The drawbar assembly/trailer hitch may be rated for trailers heavier than the vehicle is designed to tow. Please adhere to Volvo's recommended trailer weights. Leveling If your vehicle is equipped with automatic lev- eling, the rear suspension always retains the correct ride height regardless of the load.

  • Page 145: Detachable Trailer Hitch

    2. Pull the ball holder out of the hitch assem- bly. A cover for the hitch assembly can be pur- chased from your Volvo retailer. 06 Starting and driving Detachable trailer hitch...

  • Page 146: Load Carriers (Accessory)

    06 Starting and driving Load carriers (accessory) Load carrier Load carriers are available as Volvo accesso- ries. Observe the following points when in use: • To avoid damaging your vehicle and to achieve maximum safety when driving, we recommend using the load carriers that Volvo has developed especially for your vehicle.
  • Page 147 5. Turn the tightening wheel to secure the load carrier in the attachment bracket. 6. Repeat this procedure for the other load carrier attachments. 7. Check that the hooks on all four load carrier attachments are securely tightened in the respective attachment brackets on the roof of the vehicle.

  • Page 148: Cold Weather Precautions

    Volvo Washer Solvent should be diluted as follows: • Use Volvo Teflon Lock Spray in the locks. NOTE Avoid the use of de-icing sprays as they can cause damage to the locks.

  • Page 149: Before A Long Distance Trip

    Reflective warning triangles are legal requirement in some countries. To prevent injury from contact with hot surfaces, do not inspect your vehicle's transmission fluid yourself. Have your vehicle's transmission fluid level inspected by a qualified Volvo service technician. • Have a word with your Volvo retailer if you intend to drive in countries where it may be difficult to obtain the correct fuel.

  • Page 150: Front/Rear Park Assist (Option/Accessory)

    NOTE Rear park assist is deactivated automati- cally when towing a trailer if Volvo genuine trailer wiring is used. Front park assist The distance monitored in front of the vehicle is approximately 2.5 ft (0.8 m).
  • Page 151 Consult a trained and qualified Volvo service technician. CAUTION In certain circumstances, the park assist system may give unexpected warning sig-...
  • Page 152 General information... 154 Tire inflation... 156 Tire inflation pressure table - U.S. models... 158 Tire inflation pressure table - Canadian models... 159 Tire designations... 160 Glossary of tire terminology ... 162 Vehicle loading... 163 Uniform Tire Quality Grading... 165 Snow chains, snow tires, studded tires... 166 Temporary spare...
  • Page 153 W H E E L S A N D T I R E S...

  • Page 154: 07 Wheels And Tires

    WARNING The wheel and tire sizes for your Volvo are specified to meet stringent stability and handling requirements. Unapproved wheel/ tire size combinations can negatively affect your vehicle's stability and handling.
  • Page 155 Tread wear indicator Tread wear indicator The tires have wear indicator strips running across or parallel to the tread. The letters TWI are printed on the side of the tire. When approximately 1/16 " (1.6 mm) is left on the tread, these strips become visible and indicate that the tire should be replaced.

  • Page 156: Tire Inflation

    07 Wheels and tires Tire inflation Tire inflation placards on U.S. models Check tire inflation pressure regularly. Tables listing the recommended inflation pres- sure for your vehicle can be found on pages 158 and 159. A tire inflation pressure placard is also located on the driver's side B-pillar (the structural member at the side of the vehicle, at the rear of the driver's door opening).
  • Page 157 The tires are considered to be cold when they have the same temperature as the surrounding (ambient) air. This temperature is normally reached after the vehicle has been parked for at least 3 hours. After driving a distance of approximately 1 mile (1.6 km), the tires are considered to be hot.

  • Page 158: Tire Inflation Pressure Table - U.s. Models

    07 Wheels and tires Tire inflation pressure table - U.S. models The following tire pressures are recommended by Volvo for your vehicle. Refer to the tire infla- tion placard for information specific to the tires installed on your vehicle at the factory.

  • Page 159: Tire Inflation Pressure Table - Canadian Models

    The following tire pressures are recommended by Volvo for your vehicle. Refer to the tire infla- Tire size Cold tire pressures up to five persons psi (kPa) Front 195/65R15 38 (260) 205/55R16 215/55R16 235/45R17 235/40R18 39 (270) Temporary spare tire...

  • Page 160: Tire Designations

    07 Wheels and tires Tire designations Federal law mandates that tire manufacturers place standardized information on the sidewall of all tires (see the illustration). The following information is listed on the tire sidewall: The tire designation (the following figures are examples of a tire designation): 215: the width of the tire (in millimeters) from sidewall edge to sidewall edge.
  • Page 161 Maximum Load: Indicates the maximum load in pounds and kilograms that can be carried by the tire. Refer to the vehicle's tire information placard or the safety certifica- tion label, located on the B-Pillar or the driver's door or on the inside of the fuel filler door on Canadian models, for the correct tire pressure for your vehicle.

  • Page 162: Glossary Of Tire Terminology

    • Recommended tire inflation pressure: inflation pressure, established by Volvo, which is based on the type of tires that are mounted on a vehicle at the factory. This inflation pressure is affected by the number...

  • Page 163: Vehicle Loading

    Properly loading your vehicle will provide maxi- mum return of vehicle design performance. Before loading your vehicle, familiarize yourself with the following terms for deter-mining your vehicle's weight ratings, with or without a trailer, from the vehicle's Federal/Canadian Motor Vehicle Safety Standards (FMVSS/ CMVSS) label, and the vehicle's tire informa- tion placard: Curb weight...
  • Page 164 07 Wheels and tires Vehicle loading how this reduces the available cargo and luggage load capacity of your vehicle. WARNING • Exceeding the permissible axle weight, gross vehicle weight, or any other weight rating limits can cause tire over- heating resulting in permanent defor- mation or catastrophic failure.

  • Page 165: Uniform Tire Quality Grading

    ALL PASSENGER VEHICLE TIRES MUST CONFORM TO FEDERAL SAFETY REQUIREMENTS IN ADDITION TO THESE GRADES Quality grades can be found, where applicable, on the tire sidewall between the tread shoulder and maximum section width. For example: Treadwear 200 Traction AA Temperature A TREADWEAR The treadwear grade is a comparative rating based on the wear rate of the tire when tested...

  • Page 166: Snow Chains, Snow Tires, Studded Tires

    07 Wheels and tires Snow chains, snow tires, studded tires Snow chains Snow chains can be used on your Volvo with the following restrictions: • Snow chains should be installed on front wheels only. Use only Volvo approved snow chains.

  • Page 167: Temporary Spare

    In the event of damage to this tire, a new one can be purchased from your Volvo retailer. WARNING Current legislation prohibits the use of the "Temporary Spare"...

  • Page 168: Tire Rotation

    The tires with the most tread should always be at the rear (to reduce the risk of skid- ding). • Contact a Volvo workshop if you are unsure about the tread depth. Tire rotation Your vehicle has no recommended tire rota- tion.

  • Page 169: Changing Wheels

    Insert flat end of lug wrench and turn/pull straight The spare wheel is located under the carpet on the trunk floor. The jack and crank are secured in the wheel recess. There are two jack attachment points on each side of the vehicle (see illustration below). To change a wheel: 1.
  • Page 170 07 Wheels and tires Changing wheels Attaching the jack 1. Position the jack correctly on the bar in the attachment (see illustration) and crank while simultaneously guiding the base of the jack to the ground. The base of the jack must be flat on a level, firm, non-slippery surface.
  • Page 171 WARNING • The jack must correctly engage the jack attachment. • Be sure the jack is on a firm, level, non- slippery surface. • Never allow any part of your body to be extended under a vehicle supported by a jack. •...

  • Page 172: Tire Pressure Monitoring System (Tpms) - U.s. Models

    07 Wheels and tires Tire Pressure Monitoring System (TPMS) - U.S. models The tire pressure monitoring system uses sen- sors mounted in the tire valves to check infla- tion pressure levels. When the vehicle is moving at a speed of approximately 20 mph (30 km/h) or faster, these sensors transmit inflation pressure data to a receiver located in the vehicle.
  • Page 173 Once TPMS sensors are properly installed, the warning message should not reappear. • Volvo recommends that TPMS sensors be fitted on all wheels used on the vehicle. Volvo does not recommend moving sen- sors back and forth between sets of wheels.
  • Page 174 Washing and cleaning the vehicle... 176 Paint touch up... 180...
  • Page 175 C A R C A R E...

  • Page 176: 08 Car Care

    Exterior components Volvo recommends the use of special cleaning products, available at your Volvo retailer, for cleaning colored plastic, rubber, or ornamental components such as chromed strips on the exterior of your vehicle.
  • Page 177 (the surface of the vehicle should not be warmer than 113 ° F (45 ° C). CAUTION Volvo does not recommend the use of long- life or durable paint protection coatings, some of which may claim to prevent pitting, fading, oxidation, etc.
  • Page 178 The light cream protectant restores a barrier against soil and sunlight. Volvo also offers a special leather softener that should be applied after the cleaner and pro- tectant. It leaves leather soft and smooth, and reduces friction between leather and other fin- ishes in the vehicle.
  • Page 179 Cleaning floor mats The floor mats should be vacuumed or brushed clean regularly, especially during winter when they should be taken out for drying. Spots on textile mats can be removed with a mild deter- gent. Bear in mind • Take extra care when removing stains such as ink or lipstick since the coloring can spread.

  • Page 180: Paint Touch Up

    60° F (15° C). Minor scratches on the surface Minor scratches can be repaired by using Volvo touch-up paint. If the stone chip has not penetrated down to the metal and an undam- aged layer of paint remains, the touch-up paint can be applied as soon as the spot has been cleaned.
  • Page 181 08 Car care...
  • Page 182 Volvo service... 184 Maintaining your vehicle... 185 Emission inspection readiness... 186 Working on your vehicle... 187 Hood and engine compartment... 189 Engine oil... 190 Fluids... 192 Wiper blades... 194 Battery... 195 Replacing bulbs... 198 Fuses... 206...
  • Page 183 M A I N T E N A N C E A N D S E R V I C I N G...

  • Page 184: 09 Maintenance And Servicing

    Volvo advises you to follow the service program outlined in this booklet. To keep your Volvo in top condition, specify time- tested and proven Genuine Volvo Parts and Accessories. The Federal Clean Air Act - U.S.

  • Page 185: Maintaining Your Vehicle

    Visually inspect battery terminals for cor- rosion. Corrosion may indicate a loose ter- minal connector, or a battery near the end of its useful service life. Consult a trained and qualified Volvo service technician for additional information. 09 Maintenance and servicing As needed: •...

  • Page 186: Emission Inspection Readiness

    OBD II system to "ready" for inspection. A half-hour trip of mixed stop-and-go/high- way driving is typically needed to allow OBD II to reach readiness. Your Volvo retailer can provide you with more infor- mation on planning a trip. •...

  • Page 187: Working On Your Vehicle

    • The battery contains acid that is both cor- rosive and poisonous. It is important that the battery is handled in an environmen- tally friendly way. Let your Volvo dealer assist you. 09 Maintenance and servicing Hoisting the vehicle If a garage jack is used to lift the vehicle, the two jack attachments points should be used.
  • Page 188 It can also cause damage to the cooling system if it should freeze. Top off with Volvo Genuine Coolant/Antifreeze only (a 50/50 mix of water and antifreeze)

  • Page 189: Hood And Engine Compartment

    Opening the hood 1. Pull the lever located under the left side of the dash to release the hood lock. 2. Lift the hood slightly. 3. Press up the release control located under the front edge of the hood (at the center) and lift.

  • Page 190: Engine Oil

    Depending on your driving habits, premium or synthetic oils may provide superior fuel econ- omy and engine protection. Consult your Volvo retailer or a trained and qualified Volvo service technician for recommendations on premium or synthetic oils. Oil additives must not be used.
  • Page 191 NOTE Volvo uses different systems to indicate a low oil level or pressure. Some models have an oil pressure sensor, in which case a warning symbol (see page 52) is used to indicate low oil pressure. Other models have an oil level sensor, in which case the driver...

  • Page 192: Fluids

    Changing coolant Coolant reservoir Normally, the coolant does not need to be changed. If the system must be drained, con- sult a trained and qualified Volvo service tech- nician. CAUTION • High levels of chlorine, chlorides and other salts can cause corrosion in the cooling system.
  • Page 193 Power steering fluid reservoir FULL The fluid level should always be between the ADD and FULL marks. Fluids Fluid type: Volvo synthetic power steering fluid (Pentosin CHF 11S) P/N 1161529 or equiva- lent. Replace: No fluid change required. NOTE If a problem should occur in the power...

  • Page 194: Wiper Blades

    09 Maintenance and servicing Wiper blades Windshield wiper blades 1. Lift the wiper arm off the windshield. 2. Press in the catches. 3. Pull out the wiper blade. 4. Insert a new wiper blade and ensure that it is firmly in place. The driver's side wiper blade is longer than the one on the passenger's side.

  • Page 195: Battery

    Battery NOTE Used batteries should be properly disposed of at a recycling station or similar facility, or taken to your Volvo retailer. Symbols: Wear protection goggles See owner's manual for details Keep away from children...
  • Page 196 09 Maintenance and servicing Battery Corrosive No smoking, no open flames, no sparks Explosion Replacing the battery Ventilation hose 1. Switch off the ignition and remove the key. 2. Wait at least 5 minutes after switching off the ignition before disconnecting the bat- tery so that all information in the vehicle's electrical system can be stored in the con- trol modules.
  • Page 197 Be sure the ventilation hose is free of debris. • Only use replacement batteries equip- ped with a ventilation hose. Consult a trained and qualified Volvo service tech- nician. NOTE After the battery has been disconnected or replaced, lock and unlock the vehicle with...

  • Page 198: Replacing Bulbs

    Diodes in the rear tail lights NOTE For information regarding any other bulbs not mentioned in this section, please con- tact your Volvo retailer or a trained and authorized Volvo service technician. Replacing bulbs at the front of the vehicle WARNING •...
  • Page 199 NOTE If the vertical aim of your headlights needs to be adjusted for any reason (e.g., towing a trailer for extended periods), this should be done by a trained and qualified Volvo service technician. High beam headlight High beam bulb...
  • Page 200 09 Maintenance and servicing Replacing bulbs (Halogen headlights) Removing the defective bulb: 1. Switch off the headlights and turn the igni- tion switch to position 0. 2. Remove the cover to access the bulb assembly. 3. Turn the bulb counterclockwise and pull it out.
  • Page 201 Turn signal, driver's side Removing the defective bulb: 1. Switch off the headlights and turn the igni- tion switch to position 0. 2. Pull out the bulb holder by twisting it coun- terclockwise. 3. Remove the bulb from the holder by press- ing it in and turning it counterclockwise.
  • Page 202 09 Maintenance and servicing Replacing bulbs 3. Reinsert the lamp holder and turn it clock- wise until it seats properly. Front fog lights (option) Front fog light Removing the defective bulb: 1. Switch off the headlights and turn the igni- tion switch to position 0.
  • Page 203 3. Replace the bulb. 4. Reconnect the cable. 5. Close and secure the side panel. NOTE If the message indicating a burned out bulb remains in the information display after the bulb has been replaced, consult a trained and qualified Volvo service technician.
  • Page 204 09 Maintenance and servicing Replacing bulbs High level brake light These bulbs are of a special type. We recom- mend that you ask a trained and qualified Volvo service technician to replace this bulb. License plate lights 1. Switch off the ignition.
  • Page 205 NOTE Other bulbs may be difficult for you to replace yourself. Let a trained and qualified Volvo service technician replace these bulbs if necessary. 09 Maintenance and servicing Replacing bulbs...

  • Page 206: Fuses

    Spare fuses are stored in the fuse box in the passenger compartment. If fuses burn out repeatedly, have the electrical system inspected by a trained and qualified Volvo service technician. WARNING Never use metal objects or fuses with higher amperage than those stated on the follow- ing pages.
  • Page 207 Relay/Fuse box in the engine compartment When replacing fuses, be sure to replace a blown fuse with a new one of the same color and amperage (written on the fuse). Fuses in the engine compartment Headlight washers (certain models) – 09 Maintenance and servicing Auxiliary lights (option) Starter motor relay...
  • Page 208 09 Maintenance and servicing Fuses Passenger's side low beam headlight – Engine control module feed, engine relay Parking lights Vacuum pump...
  • Page 209 Fuse box in the passenger compartment, behind the plastic cover This fuse box is located behind the plastic cover below the steering wheel. When replac- ing a blown fuse, be sure to replace it with a new one of the same color and amperage (writ- ten on the fuse).
  • Page 210 09 Maintenance and servicing Fuses Driver's side front foglight (option) Passenger's side front foglight (option) – – Transmission control module, reverse gear block (M66) Driver's side high beam Passenger's side high beam – – – – Power passenger's seat (option), audio system Fuel pump –...
  • Page 211 Fuse box on the edge of the dashboard Fuses are located inside the access panel on the edge of the dashboard. There are also a number of spare fuses. Power driver's seat (option) Power passenger's seat (option) Climate system blower Control module - front pas- senger's door 09 Maintenance and servicing...
  • Page 212 09 Maintenance and servicing Fuses Fuses in the trunk The fuses in the cargo area are located behind the panel on the driver's side of the cargo com- partment. When replacing a blown fuse, be sure to replace it with a new one of the same color and amperage (written on the fuse).
  • Page 213 Accessory audio – Folding head restraints Trailer wiring (15-feed) - option – – All Wheel Drive Four-C chassis system (option) – Park assist (option) Main fuse: trailer wiring, Four- C, park assist, All Wheel Drive Central locking system Driver's side trailer lighting: parking lights, turn signal (option) Passenger's side trailer light-...
  • Page 214 Introduction... 216 Audio system HU-650 - overview... 217 Audio system HU-850 - overview... 218 Radio functions HU-650/HU-850... 219 RBDS functions HU-650/HU-850... 223 HU-650 - CD player... 226 HU-850 - internal CD changer... 227 External CD changer (option)... 228 Dolby Surround Pro Logic II - HU-850 only... 229 Audio systems - specifications...
  • Page 215 A U D I O...

  • Page 216: 10 Audio

    • Do not put tape or labels on the disc itself. • Volvo does not recommend the use of plastic outer rings on the disc. • Condensation may occur on discs/optical components of the changer in cold winter weather.

  • Page 217: Audio System Hu-650 - Overview

    COMPACT DIGITAL AUDIO HU-650 13 14 15 16 17 18 RND CD random play AM AM (select AM1 or AM2) CD slot Display Scan (automatically search for radio sta- tions) CD eject FM FM (select FM1, FM2, FM3) CD CD player AUTO AUTO - automatically search for radio stations Navigation buttons (seek/change radio...

  • Page 218: Audio System Hu-850 - Overview

    10 Audio Audio system HU-850 - overview COMPACT DIGITAL AUDIO HU-850 16 17 18 20 21 RND CD random play AM AM (select AM1 or AM2) CD slot Display 3-CH 3-channel stereo OFF 2-channel stereo Dolby Surround Pro Logic II CD eject FM FM (select FM1, FM2, FM3) CD CD player...

  • Page 219: Radio Functions Hu-650/Hu-850

    Switch on/off Press the knob to switch on or turn off the radio. Volume control Turn the knob clockwise to increase volume. Volume control is electronic and does not have an end stop. If you have a key pad in the steer- ing wheel, increase or decrease the volume with the + or –...
  • Page 220 10 Audio Radio functions HU-650/HU-850 The volume level for the auxiliary device can now be adjusted. Press EXIT to save the setting and exit the menu. Sound settings Optimal sound reproduction The audio system is calibrated for optimal sound reproduction through the use of digital signal processing.
  • Page 221 Selecting a sound source The sound source (e.g. AM, FM, etc.) can be selected in two ways: • Use the sound source buttons (see the center illustration above). • Turn the SOURCE knob (see illustration) to select a sound source (AM1, AM2, FM1, FM2, FM3, or CD).
  • Page 222 10 Audio Radio functions HU-650/HU-850 Storing stations To store a selected station under one of the station setting buttons 1-6: 1. Tune to the desired station. 2. Press the button under which the station is to be stored and keep it depressed. The audio system sound will be interrupted for STORED a few seconds and...

  • Page 223: Rbds Functions Hu-650/Hu-850

    The RBDS or Radio Broadcast Data System operates in the FM band only, and the infor- mation transmitted is supplied exclusively by participating broadcasters. Volvo has no con- trol over the accuracy of the data or informa- tion. Coverage by local broadcasters may be limited...
  • Page 224 10 Audio RBDS functions HU-650/HU-850 Format Display text Entertainment VARIED Pop music POP M Rock music ROCK M Easy listening EASY M Light classics LIGHT M Classical music CLASSICS Other music OTHER M Weather WEATHER Finance FINANCE Religious programs RELIGION Travel TRAVEL Leisure...
  • Page 225 6. Turn the SOURCE knob to select LOW, MEDIUM, HIGH , or and press SOURCE. 7. Press EXIT. NOTE Please be aware that there are certain RBDS menu selections, for example EON, TP search, News, etc, that may not be available in North America.

  • Page 226: Hu-650 - Cd Player

    10 Audio HU-650 - CD player Starting the CD player Please refer to the illustration on page 217 for the location of the buttons referred to on this page. 1. Insert a disc into the player. 2. Press the CD button or turn the SOURCE knob to CD.

  • Page 227: Hu-850 - Internal Cd Changer

    Starting the CD changer The HU-850 is equipped with an internal, 6- disc CD changer. Please refer to the illustration on page 218 for the location of the buttons referred to on this page. To load discs into the changer: 1.

  • Page 228: External Cd Changer (Option)

    10 Audio External CD changer (option) The optional 10-CD changer is mounted in the cargo compartment. Please refer to the illustrations on pages 217 and 218 for the location of the buttons referred to on this page. Turn the SOURCE knob to select the external CD changer.

  • Page 229: Dolby Surround Pro Logic Ii - Hu-850 Only

    Dolby Surround Pro Logic II Dolby Surround Pro Logic II is a further devel- opment of the previous version of the system and provides enhanced sound quality. The improved sound is particularly apparent to passengers in the rear seat. Dolby Surround Pro Logic II, together with a center speaker in the dashboard, offers you a sound experience very close to a live perform- ance.

  • Page 230: Audio Systems - Specifications

    This would cause damage to the amplifier. Contact a trained and quali- fied Volvo service technician. Low battery voltage If the level of battery voltage is low, a message will be displayed.
  • Page 231 10 Audio...
  • Page 232 Label information... 234 Dimensions ... 236 Weights ... 238 Capacities... 240 Engine specifications... 242 Bulbs... 243 Electrical system... 244 Three-way catalytic converter... 245 Suspension... 246 Volvo programs... 247...
  • Page 233 S P E C I F I C A T I O N S...

  • Page 234: 11 Specifications

    11 Specifications Label information MANUFACTURER: VOLVO CAR CORP. SWEDEN ENGINE: B6324S ENGINE DISPLACEMENT:3.2 LITERS TEST GROUP: 7VVXB03.2U2N EVAPORATIVE/REFUELING FAMILY:7VVXR0130EVX EXHAUST EMISSION CONTROL SYSTEM SFI, 2HO2S, SHA/FS, 2TWC(2) TUNE-UP SPECIFICATIONS: NO ADJUSTMENTS NEEDED THIS VEHICLE CONFORMS TO USE EPA TIER 2 BIN 5 REGULATIONS AND CALIFORNI REGULATIONS APPLICABLE TO 2007 MODEL YEAR NEW LEVII ULEV PASSENGER CARS.
  • Page 235 Standards (FMVSS) specifications (USA) and Ministry of Transport (CMVSS) standards (Canada) Your Volvo is designed to meet all applicable safety standards, as evidenced by the certifi- cation label on the facing side of the driver's door. For further information regarding these regulations, please consult your Volvo retailer.

  • Page 236: Dimensions

    11 Specifications Dimensions G020131 Position Dimension Wheelbase Length Load length, floor, seatback down Load length, trunk Height Track, front Track, rear in. (mm) 107 in. (272 cm) 181 in. (460 cm) 65.4 in. (166 cm) 32.2 in. (82 cm) 56.2 in. (143 cm) 61.5 in.
  • Page 237 Position Dimension Width Width incl. door mirrors 11 Specifications Dimensions in. (mm) 71 in. (180 cm) 81.5 in. (207 cm)

  • Page 238: Weights

    11 Specifications Weights Gross vehicle weight Capacity weight Permissible axle weights, front Permissible axle weights, rear Curb weight AWD = All Wheel Drive 5-cyl. turbo manual 4430 lbs 5-cyl. turbo automatic 4470 lbs 4540 lbs 5-cyl turbo AWD automatic 5-cyl. turbo 870 lbs 5 cyl.
  • Page 239 Max. loads Max. roof load Max. trailer weight: – without brakes – with brakes, 2” ball – with brakes, 1 7/8” ball Max. tongue weight: Trailer weights below 2,650 lbs (1,200 kg) Trailer weights above 2,650 lbs (1,200 kg) When driving for prolonged periods at temperatures above 86 °F (30 °C), the maximum recommended weight is 2000 lbs (900 kg). See also page 143 for additional information.

  • Page 240: Capacities

    Manual transmission oil Coolant Brake fluid Specification Volvo engines are designed to achieve rated horsepower, torque, and fuel economy performance using premium 91 octane fuel. Volvo recommends premium for best performance, but using 87 octane or above will not affect engine reliability Engine oil must meet the minimum ILSAC specification GF-4, API SL, or ACEA A1/B1.
  • Page 241 Category Specification Power steering fluid Volvo synthetic power steering fluid (Pentosin CHF 11S) P/ N 1161529 or equivalent Washer fluid reservoir Use washer fluid solvent in cold weather conditions. NOTE The transmission oil does not normally need to be changed during the service life of the vehicle.

  • Page 242: Engine Specifications

    11 Specifications Engine specifications Engine designation Output Torque No. of cylinders Displacement (liter/cu.in.) Bore (in./mm) Stroke (in./mm) Compression ratio Charge air cooler (Intercooler) Turbocharged engines employ a turbo-com- pressor to force air into the engine inlet mani- fold and a charge air cooler to cool the compressed inlet air.

  • Page 243: Bulbs

    Front fog lights Glove compartment lighting WARNING Active Bi-Xenon headlights (option) – due to the high voltage used by these headlights, these bulbs should only be replaced by an authorized Volvo service technician. 11 Specifications Bulbs Output Type BA15s BAU15s BAY15d SV8.5...

  • Page 244: Electrical System

    11 Specifications Electrical system General information 12-volt system with voltage controlled gener- ator. Single wire system in which the chassis and engine block are used as conductors, grounded on the chassis. Battery Voltage: 12 V Voltage 12 V Cold start capacity (CCA) Reserve capacity (RC)

  • Page 245: Three-Way Catalytic Converter

    Three-way catalytic converter – general information • Keep your engine properly tuned. Certain engine malfunctions, particularly involving the electrical, fuel or distributor ignition systems, may cause unusually high three- way catalytic converter temperatures. Do not continue to operate your vehicle if you detect engine misfire, noticeable loss of power or other unusual operating condi- tions, such as engine overheating or back-...

  • Page 246: Suspension

    11 Specifications Suspension Rear suspension Individual rear wheel suspension with longitu- dinal support arms, double link arms and track rods. Front suspension Spring strut suspension with integrated shock absorbers and control arms linked to the sup- port frame. Power-assisted rack and pinion steering.

  • Page 247: Volvo Programs

    11 Specifications Volvo programs Volvo On Call Roadside Assistance Your new Volvo comes with a four year ON CALL roadside assistance. Additional informa- tion, features, and benefits are described in a separate information package in your glove compartment. If you require assistance, dial:...
  • Page 248 12 Index A/C (air conditioning)... 90 ABS... 136 Airbag system... 20 Air conditioning... 89 Air distribution... 88, 90, 91 Air quality sensor... 91 Air vents... 88 Alarm... 116 All Wheel Drive... 134 towing... 141 Anti-lock Brake System (ABS)... 136 Audio system... 216 CD changer (external)...
  • Page 249 Defroster... 89 Detachable trailer hitch... 145 Dimensions... 236 Disabling the passenger's side front air- bag... 25 Driving economically... 127 Driving through water... 128 Dynamic Stability and Traction Control (DSTC)... 138 Economical driving... 127 Electrical system... 244 Emission inspection... 186 Engine specifications...
  • Page 250 12 Index Jack location of... 105 using... 169 Jacket hanger... 101 Keys... 108 Kickdown... 131 Label information... 234 Leather care... 177 Load carriers... 146 Locking steering wheel... 125 Locking the car... 112, 113 Long distance trips... 149 Long loads - carrying... 103 Maintenance, periodic...
  • Page 251 Valet key... 108 Vanity mirror... 98 Vehicle dimensions... 236 Vehicle Event Data... 184 Vehicle Identification Number (VIN)... 235 Vehicle loading... 163 Volvo Inflatable Curtain... 29 Volvo On Call Roadside Assistance... 247 Warranties... 184 Washer fluid reservoir... 189, 192 Washing the car... 176...
  • Page 252 12 Index Water, driving through... 128 Waxing... 177 Weight distribution... 128 Weights... 238 Wheels changing... 169 storing... 155 Whiplash Protection System (WHIPS)... 30 Windshield washer fluid reservoir... 192 Winter/Wet driving mode... 131...

This manual is also suitable for:

S60

Table of Contents
