- Page 1 ® Solar Bear Solar Pool Heater for above-ground swimming pools (Not recommended for Inflatable Pools) Installation & Owner’s Manual...
- Page 2 Installation................. 3-7 Operation & Winterization............8 Troubleshooting… ..............9 Overview ® Thank you for choosing the Solar Bear solar swimming pool heating system. Solar ® Bear is proudly manufactured in the United States. Since 1969, we have provided high-quality, long- lasting products that help our customers save money on energy costs and reduce the environmental impact associated with traditional energy sources.
- Page 3 Overview (continued) Contents Your system includes one solar collector, along with mounting hardware, connection hardware, and integrated bypass valve (The Big Red Handle). See the list below for the contents of your exact system: Component 965-3 4’ x 20’ Wide Solar Collector with 1-1/2”...
-
Page 4: Installation
Installation 1) Determine location to install solar collector Select an unshaded location on the ground near the pool that is at least 5’ x 20’ and receives full sun for most of the day. The solar collectors operate most efficiently when tilted 10 to 30 degrees towards the South, although they are still effective when facing West, East, or mounted flat. - Page 5 Installation (continued) Ground Rack Example...
- Page 6 Installation (continued) 2) Roll out solar collector Lay the box containing the solar system near the selected installation location. Ensure there are no rocks or other sharp objects lying on the ground that could puncture the solar collector. Remove the contents and verify quantities using list shown in the overview.
- Page 7 Installation (continued) which case either end can be the inlet. Place a hose clamp on the end of the hose and push the hose onto solar collector end at least one inch past the raised ribs. Slide the hose clamp into place and tighten. Note: You may need to warm the hose end by placing it in hot water for several seconds to make it more pliable.
- Page 8 Installation (continued) Turn your pump on and check the hose clamps and plumbing for leaks. If there’s a leak, you may have to loosen the clamp, then push the hose further up onto the barb. Then tighten the hose clamps or couplers again. After the pump is on and has run for about 5 minutes, slowly turn the red handle (‘Solar On’...
-
Page 9: Operation
The sun’s heat will be carried into your pool immediately. For best results, ® turn on your Solar Bear whenever the solar collector is in the sun. Turn the solar and/or the pump off at night, when it’s cloudy, or when it’s raining to prevent cooling of the pool. -
Page 10: Troubleshooting Guide
A tube leak can be repaired if damage is located at least 2” away from the 6. I have a leak in my solar collector header. Contact your local dealer, where you purchased the product or email service@fafco.com for more information on how to repair the solar collector. - Page 11 For above-ground swimming pool use only. ® Don’t forget, if you need more solar heat, you can always add another Solar Bear (maximum of 2 per system). ® Solar Bear www.fafco.com P/N 09008C 4/20...
