ionSign Neutron3-B+ Quick Manual

connector
SIM card
Antenna
GSM LED
Pulse connectors
When the installation mode times out, all leds switch off. This is normal.
The below example command sets device 101 to start collecting hourly pulse data and
Example SETTINGS command:
SETTINGS
Command
Server
port
Operator
APN address
Attached
meters
E.g. JAMAK 2x(2+1)x0,5mm2 instrumentation
cable can be used between Neutron3-B+ and the
meter. Connect the cable to the connector and
snap it in place to the terminal block. Cable polarity
has no significance.
Copyright 2020 - ionSign

Introducing Neutron3-B:

1.
2.
3.
4.
Battery
LED
indicators
5.
Button
6.
Device
ID
60
Transmission Server
delay path
Measurement cycle:
15, 30 or 60 (min)
www.ionsign.fi
Quick Manual
Neutron3-B+ Remote Pulse Collector
Insert SIM card to its slot, PIN query disabled.
Connect the measuring device(s).
Insert the battery or remove the battery cover.
The red led lights up for 10 seconds.
Enter the installation mode by pressing the but-
ton inside the device or activating it with a mag-
net from the outside. The device wakes up for
five minutes to receive SMS messages. The
red GSM led double blinks when GSM network
search is active, and blinks when a GSM con-
nection is established.
Send a SETTINGS command to the device as
an SMS. When the command is received, the
yellow led starts blinking and the device starts
to establish a server connection. The yellow led
remains lit when the device is in operation.
Securely close the lid and mount the device
e.g. to a wall.
send it to server services.ionsign.fi,
path /cloud/input/ and port 80, using
internet as APN. Device 101 has 4 in-
puts and data is sent one minute after
24 readings have been collected. In
Server
this case, with hourly data, at 00:01.
name
Refer to section 4 on the next page
to compile your specific SETTINGS
command. Always establish your
specific SETTINGS parameters from
your reseller, service provider or
ionSign.
15.6.2020 – v1.4
