- Page 1 2009 QUICK REFERENCE GUIDE GET INFORMED. ROLL...
- Page 2 A word about safe vehicle operations This Quick Reference Guide is not a full description of Scion xD operations. Every Scion xD owner should review the Owner’s Manual that accompanies this vehicle. Pay special attention to the boxed information highlighted in color throughout the Owner’s Manual.
-
Page 3: Table Of Contents
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES Visit your Toyota dealer for information on customizing this feature. Engine maintenance Fuel tank door release and cap Hood release Indicator symbols Instrument cluster Instrument panel Keyless entry Light control-Instrument panel Air Conditioning/Heating Automatic Transmission AUX audio jack Bottle holders Clock... -
Page 4: Instrument Panel
AUX audio jack* Cruise control Engine switch Tilt steering lock release Tire Pressure Monitoring (warning) System Instrument panel light control Power rearview mirror controls * For details, refer to the SCION Audio System, Owner’s Manual or SCION Navigation System Owner’s Manual. -
Page 5: Instrument Cluster
OVERVIEW Instrument cluster Service indicator and reminder Speedometer MODE switch Multi-information display Tachometer Shift position indicator Fuel gauge Indicator symbols Brake system warning Driver seat belt reminder (alarm will sound if speed is over 12 mph) Front passenger seat belt reminder (alarm will sound if speed is over 12 mph) Charging system warning Malfunction/Check Engine indicator... -
Page 6: Engine Maintenance
OVERVIEW Keyless entry Locking operation Unlocking operation NOTE: If a door is not opened within 30 seconds of unlocking, all Push doors will relock for safety. Panic button Fuel tank door release and cap Driver seat Pull up NOTE: Tighten until one click is heard. If the cap is not tightened enough, Check Engine “... -
Page 7: Features/Operations
Automatic Transmission (if equipped) Park* Reverse Neutral Drive Third gear Second gear First gear * The engine switch must be “ON” and the brake pedal depressed to shift from Park. Downshifting increases power going uphill, or provides engine braking downhill. For best fuel economy during normal driving conditions, always drive with the shift lever in the “D”... -
Page 8: Window Wiper & Washer
FEATURES/OPERATIONS Lights & turn signals Headlights Headlights Parking lights High beam Low beam High beam flasher Turn signals Right turn Lane change Lane change Left turn Window wipers & washers Front Single wipe Interval wipe Pull to wash and wipe Slow Fast Rear... -
Page 9: Aux Audio Jack
By inserting a mini plug (not included) into the AUX jack, you can listen to music from a portable audio device through the vehicle’s speaker system while in AUX mode. If you do not have a SCION genuine audio system, you will not be able to use the AUX jack. H-Hour set Refer to the SCION Audio or Navigation System Owner’s Manual for more... -
Page 10: Multi-Information Display
-In CD mode Push to skip up or down to a next/previous track. “MODE” Push to turn audio ON and select an audio mode. Push and hold to turn the audio system OFF. Refer to the SCION Audio or Navigation System Owner’s Manual for more details. Multi-information display Push... -
Page 11: Safety/Emergency Features
EMERGENCY FEATURES Door locks Driver side Unlock Lock Doors-Child safety locks Rear door Moving the lever to “LOCK” will allow the door to be opened only from the outside. Seat belts-Shoulder belt anchor Seat belts If belt is fully extended, then retracted even slightly, it cannot be re-extended beyond that point, unless fully retracted again. -
Page 12: Spare Tire & Tools
Tire Pressure Monitoring (warning) System After adjusting tire pressures, or after tires have been rotated or replaced, turn the ignition switch to “ON” and press and hold the “ SET” button until indicator blinks three times. Let the vehicle sit for a few minutes to allow initialization to complete. - Page 13 EMAIL www.scion.com Contact > CHAT www.scion.com Have a Question? > Contact > PHONE 1.866.70.SCION MAIL SCION 19001 S. Western Ave. D102, P.O. Box 2742 Torrance, CA 90509-2742 www.scion.com ©2009 Scion, a marque of Toyota Motor Sales, U.S.A., Inc. 00505-QRG09-XD...
