  • Page 1 2009 QUICK REFERENCE GUIDE GET INFORMED. ROLL.
  • Page 2 Scion xB. A word about safe vehicle operations This Quick Reference Guide is not a full description of Scion xB operations. Every Scion xB owner should review the Owner’s Manual that accompanies this vehicle.

  • Page 3: Table Of Contents

    OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES Visit your Toyota dealer for information on customizing this feature. Programmable by customer. Refer to the Owner’s Manual for instructions and more information. Engine maintenance Fuel tank door release and cap Hood release Indicator symbols Instrument cluster Instrument panel Keyless entry...

  • Page 4: Overview

    Tire Pressure Monitoring (warning) System reset Tilt steering lock release “VSC OFF” (Vehicle Stability Control “OFF”) Instrument panel light control dial Power outside rearview mirror controls For details, refer to the SCION Audio System Owner’s Manual or SCION Navigation System Owner’s Manual.

  • Page 5: Instrument Cluster

    OVERVIEW Instrument cluster Service indicator and reminder Speedometer Tachometer Fuel gauge Engine coolant temperature Odometer and two trip meters Trip meter reset knob Multi-information display Multi-information display control switch Automatic Transmission shift position indicator Indicator symbols Brake system warning Driver seat belt reminder (alarm will sound if speed is over 12 mph) Front passenger seat belt reminder (alarm will sound if speed is over 12 mph)

  • Page 6: Light Control-Instrument Panel

    OVERVIEW Keyless entry Locking operation Unlocking operation Push NOTE: After unlocking, if a door is not opened within 60 seconds, all doors will relock for safety. Panic button Hood release Pull Light control-Instrument panel Bright Dark Fuel tank door release and cap Push ONCE: Driver door TWICE: ALL doors NOTE: Tighten until one click is heard.

  • Page 7: Features/Operations

    Auto lock functions Automatic door locks can be programmed to operate in four different modes, or turned OFF. -Doors lock when shifting from Park.* -Doors lock when the vehicle speed goes above approximately 12 mph. -Doors unlock when ignition key is turned to “ACC” or “LOCK” position and driver’s door is opened.

  • Page 8: Window Wiper & Washer

    FEATURES/OPERATIONS Lights & turn signals Headlights Headlights Parking lights Low beam Turn signals Right turn Lane change Lane change Left turn Window wipers & washers Front Single wipe Pull to wash and wipe Fast Rear Windows Driver side High beam Automatic operation (driver side only) Push the switch completely down and High beam flasher release to fully open.

  • Page 9: Steering Wheel Switches

    By inserting a mini plug into the AUX jack, you can listen to music from a portable audio device through the vehicle’s speaker system. If you do not have a SCION genuine audio system, you will not be able to use the AUX jack.

  • Page 10: Multi-Information Display

    If you do not have a SCION genuine audio system, you will not be able to use the iPod jack. Refer to the SCION Audio System Owner’s Manual or SCION Navigation System Owner’s Manual for more details.

  • Page 11: Door Locks

    EMERGENCY FEATURES Door locks Driver side Unlock Doors-Child safety locks Rear door Moving the lever to “LOCK” will allow the door to be opened only from the outside. Seat belts-Shoulder belt anchor Seat belts If belt is fully extended, then retracted even slightly, it cannot be re-extended beyond that point, unless fully retracted again.

  • Page 12: Spare Tire & Tools

    Tire Pressure Monitoring (warning) System If tire pressure indicator light is on, check/adjust each tire. After adjusting tire pressures, or after tires have been rotated or replaced, turn the ignition switch to “ON” and press and hold the “ indicator blinks three times. Then allow the vehicle to sit for a few minutes to allow initialization to complete.
  • Page 13 EMAIL www.scion.com Contact > CHAT www.scion.com Have a Question? > Contact > PHONE 1.866.70.SCION MAIL SCION 19001 S. Western Ave. D102, P.O. Box 2742 Torrance, CA 90509-2742 www.scion.com ©2009 Scion, a marque of Toyota Motor Sales, U.S.A., Inc. 00505-QRG09-XB...
