Talkaphone ETP-CI-4G-GSM Installation Instructions

I. Introduction
The ETP-CI-4G-GSM is used in conjunction with an ETP-500 Series ADA-compliant, hands-free Emergency
Phone.
IMPORTANT NOTE: Programming of the ETP-500 Series Phones cannot be done through a
remote call to the ETP-CI-4G-GSM Cellular Interface. For programming, an ETP-500 Series Phone
must be connected directly to a standard analog phone line connection.
II. Prerequisite Cellular Service Requirements
Prior to installation and setup, the ETP-CI-4G-GSM Cellular Interface has the following perquisite requirements:
(1) 4G Voice over LTE service from a local cellular service provider that supports GSM (e.g. AT&T,
T-Mobile);
(2) An activated micro-SIM (3FF) card provided by the local cellular service provider.
III.
Contents
Before beginning installation, make sure you have all the included components. The ETP-CI-4G-GSM includes:
Qty. Part Number
1 68746
1 160-00049
2 4247
2 4248
2 42767
Page 1 of 5
Copyright 2019-2021 Talk-A-Phone, LLC • 7530 North Natchez Avenue • Niles, Illinois 60714 • Phone 773.539.1100 • info@talkaphone.com • www.talkaphone.com
All prices and specifications are subject to change without notice. Talk-A-Phone, Talkaphone, bAlert, Scream Alert, WEBS, and WEBS Contact are registered trademarks of Talk-A-Phone,
LLC. All rights reserved. All other trademarks mentioned in this document or website are the property of their respective owners and does not imply or indicate any approval, endorsement,
sponsorship, or affiliation with such owners unless such approval, endorsement, sponsorship, or affiliation is expressly indicated.
ETP-CI-4G-GSM – Cellular Interface
Description
ETP-CI-4G-GSM Cellular Interface
MIMO antenna kit (includes antenna with built-in cable
assembly)
8-32 x 1/2 BH Screw
8-32 x 5/16 Hex Nut
#10 External Lock Washer
Installation Instructions
Rev. 5/12/2021
