Fusion
Apollo
AP-DA214 Zone Amplifier Installation Instructions
™
®
Important Safety Information
WARNING
See the Important Safety and Product Information guide in the product box for product warnings and other
important information.
This device must be installed according to these instructions.
Disconnect the vessel's power supply before beginning to install this device.
CAUTION
Continuous exposure to sound pressure levels over 100 dBA may cause permanent hearing loss. The volume is
typically too loud if you cannot hear people speaking around you. Limit the amount of time you listen at high
volume. If you experience ringing in your ears or muffled speech, stop listening and have your hearing checked.
To avoid possible personal injury, always wear safety goggles, ear protection, and a dust mask when drilling,
cutting, or sanding.
NOTICE
YOU MUST NOT USE THIS AMPLIFIER WITH ANY THIRD-PARTY MARINE AUDIO SYSTEMS. This amplifier is
compatible only with Fusion DSP-enabled marine audio equipment and may cause damage to third-party
speakers due to the amplifier power output.
When drilling or cutting, always check what is on the opposite side of the surface to avoid damaging the vessel.
It is strongly recommended that you have your audio system installed by a professional installer to ensure
optimum performance.
You must read all installation instructions before beginning the installation. If you experience difficulty during
the installation, go to
support.garmin.com
for product support.
After installing an audio system, you should run the connected speakers and subwoofers at low to medium
volumes for the first few hours of use. This helps to improve the overall sound by gradually loosening up the
moving components of new speakers and subwoofers, such as the cone, spider, and surround. See the
installation instructions provided with your speakers, because there may be more details about the
recommended time for each model.
July 2021
GUID-68740D5A-C048-457D-B721-E7264F74056E v1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Garmin Fusion Apollo AP-DA214
Summary of Contents for Garmin Fusion Apollo AP-DA214
- Page 1 You must read all installation instructions before beginning the installation. If you experience difficulty during the installation, go to support.garmin.com for product support. After installing an audio system, you should run the connected speakers and subwoofers at low to medium volumes for the first few hours of use.
-
Page 2: Tools Needed
This distance is listed in the specifications section. • You must not mount the device in close proximity to other navigation-critical equipment, antennas, or radio- communication equipment on the vessel. Fusion Apollo AP-DA214 Zone Amplifier Installation Instructions... -
Page 3: Installing The Mounting Bracket
3 Using the included pan-head screws or other pan-head mounting hardware, secure the bracket to the mounting surface. NOTICE You must use pan-head screws, because countersunk screws will damage the bracket. Fusion Apollo AP-DA214 Zone Amplifier Installation Instructions... -
Page 4: Connection Considerations
Improper terminal or wire contact may result in damage to the audio system. NOTE: You must connect the amplifier to the AMPLIFIER ON wire from the stereo for the amplifier to turn on and off with the stereo. Fusion Apollo AP-DA214 Zone Amplifier Installation Instructions... - Page 5 This must connect to the zone output from your stereo using a 2-way RCA cable (not included) REMOTE ON signal wire (blue) Right speaker wires: • Gray: positive (+) • Gray/black: negative (-) Left speaker wires: • White: positive (+) • White/black: negative (-) Fusion Apollo AP-DA214 Zone Amplifier Installation Instructions...
-
Page 6: Connecting To Power
5 Connect the red power wire to the fuse or circuit breaker, and connect the fuse or circuit breaker to the positive (+) battery terminal if necessary. 6 Connect the wiring harness plug to the amplifier. Fusion Apollo AP-DA214 Zone Amplifier Installation Instructions... -
Page 7: Configuring The Amplifier
3 Follow the instructions in the Fusion-Link app to select a configured profile for the connected amplifier, speakers, and/or subwoofer(s). 4 Send the DSP profile to the connected stereo and test the sound. 5 Repeat steps 3 and 4 until the audio system sounds satisfactory. Fusion Apollo AP-DA214 Zone Amplifier Installation Instructions... -
Page 8: Specifications
Input under/over voltage Protection circuits Over temperature Output short circuit The device withstands incidental exposure to water of up to 1 m for up to 30 min. For more information, go to www.garmin.com/waterrating. Fusion Apollo AP-DA214 Zone Amplifier Installation Instructions... - Page 9 If the Fusion amplifier has been installed by a professional installation company, you should contact the company so a technician can assess the problem and advise you about possible solutions. Fusion Apollo AP-DA214 Zone Amplifier Installation Instructions...
- Page 10 • Check the wire gauge used to connect the speakers to the amplifier, and make sure it is appropriate for the length of the wire run. Fusion Apollo AP-DA214 Zone Amplifier Installation Instructions...
- Page 11 NOTE: You must select the option in the app to send the DSP settings to the stereo after you configure the settings. High-volume issue Reduce the volume. Speaker fault Check all connected speaker wires. Fusion Apollo AP-DA214 Zone Amplifier Installation Instructions...
- Page 12 If the LED continues to show a red fault, contact support. fault 物質宣言 有毒有害物质或元素 部件名称 铅 镉 汞 六价铬 多溴联苯 多溴二苯醚 印刷电路板组件 金属零件 电缆 电缆组件 连接器 本表格依据 SJ/T11364 的规定编制。 : 代表此种部件的所有均质材料中所含的该种有害物质均低于 (GB/T26572) 规定的限量 產品 : 代表此种部件所用的均质材料中, 至少有一类材料其所含的有害物质高于 (GB/T26572) 规定的限量 *該產品說明書應提供在環保使用期限和特殊標記的部分詳細講解產品的擔保使用條件。 © 2021 Garmin Ltd. or its subsidiaries support.garmin.com...
