**** PLEASE READ THOROUGHLY PRIOR TO USE FOR IMPORTANT SAFETY INFORMATION****
WARNING:
Sections labeled "Warning" can lead to serious injury or death if not followed. Please thoroughly read these sections and understand them completely
before use. If you do not understand them or have any questions, contact your retailer or Anvil Brewing Equipment (www.anvilbrewing.com) before use.
CAUTION:
Sections labeled "Caution" can lead to equipment damage or unsatisfactory performance of the equipment. Please read these sections thoroughly. If
you have any questions, contact your retailer or Anvil Brewing Equipment (www.anvilbrewing.com) before use.
IMPORTANT:
Sections labeled "Important" should specifically be followed to ensure satisfactory results with the product.
Anvil Brewing Crucible - V2
©Anvil Brewing Equipment 2021
www.anvilbrewing.com
Crucible
Assembly & Maintenance Manual
Description
1-1/2" Tri-Clamp Butterfly Valve
1-1/2" Tri-Clamp Gasket
1-1/2" Tri-Clamp
1-1/2" Tri-Clamp Elbow
Straight Ball Valve
Racking Arm
Air Lock and Stopper
Temperature Gauge (Liquid Crystal)
Legs
Plastic Rivets
Plastic Feet
™
1
Quantity
1
2
2
1
1
1
1
1
3
3
3
Advertisement
Related Manuals for Anvil Crucible
Summary of Contents for Anvil Crucible
- Page 1 Sections labeled “Warning” can lead to serious injury or death if not followed. Please thoroughly read these sections and understand them completely before use. If you do not understand them or have any questions, contact your retailer or Anvil Brewing Equipment (www.anvilbrewing.com) before use.
- Page 2 Step 5: Remove the locknut from the valve and insert the male threads of the valve into the large hole in the cone of the Crucible from the outside as shown in the drawing below. Make sure the o-ring is seated in the groove on the valve on the outside of the fermentor as shown.
-
Page 3: Operation
Warning: Never seal the yeast storage vessel! The yeast may create dangerous pressures that could burst the container! TIP: controlling fermentation temperature is important for proper fermentation. The optional ANVIL cooling kit (ANV-CS-CARB) is ideal for precisely controlling fermentation temperatures. -
Page 4: Cleaning And Maintenance
Use a glass cleaner to install each grommet into each leg brace bar. After the 3 pieces are together, install onto the legs as shown. Optional Accessories Figure 4 7 Gallon Crucible Cooling System - ANV-Crucible-CS-7gal 14 Gallon Crucible Cooling System - ANV-Crucible-CS-14gal O2 Wand and Regulator - ANV-O2-WAND-REG Anvil Brewing Crucible - V2 ©Anvil Brewing Equipment 2021... - Page 5 3. This warranty does not cover, and in no event shall ANVIL Brewing Equipment be liable for, travel, lodging, or any other expense incurred due to manufacturing defects in material and work manship, or any other reason.
