Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information What Is Included Specifications Main Power Connection DMX-512 Connection Output Connection Rear Panel Display Board Universe Activation Size & Weight Cleaning & Maintenance Warranty Customer Support... -
Page 2: Safety Information
1. Unit surface may reach high temperature. Allow about 5 minutes after powering the unit before moving. 2. When repositioning rack ears, make sure they are securely attached. What is Included 1pc Memo Core Control 1pc Power Con Type Cable to Nema 5-15 2pc Rear & Wall Support Rack Ears 1pc Bluetooth Keyboard and Mouse... -
Page 3: Specifications
Specifications Part Numbers Fixture MC1095– Memo Core Control DMX RJ45 Outputs Mechanical Specifications Fastening System: Removable Rack Ears for Wall Mounting, Rack Mounting and Rear Rack Mounting Digital 6 Button Function Display Display: Power Connection: Power Con (type) Cable Mounted to Nema 5-15 Connection... -
Page 4: Main Power Connection
Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit has Auto switching power supply. It will respond to 110V or 220V automatically. This unit must be earthed (electronically grounded). Replace fuse only with the specified type and rating (F2 240V Size 5x20MM). The occupation of the connection-cable is as follows: This fixture is equipped with an electronic power supply that will let the unit operate from 100V to 240V from 50 to 60Hz. -
Page 5: Rear Panel
Rear Panel Memo Core’s output connection can be used to control DMX fixtures, video, and audio scenes on the Enlighten Soft- ware. 1= DMX Output: 8 RJ45 output connections each representing a universe 512 DMX Channels. 2= RS485/RS232: 4 point Screw Terminal Port, used for connecting Memo Remote wall connection or any other type of command device that will send or receive RS232 or RS485 Commands. -
Page 6: Display Board
Display Board Display Screen gives you direct Mega Lite access to recorded scenes Memo Core Control Page Select: Use the Up / Down arrows to select the correct button page Page 1 Blue FOH Button Select: Use the Left / Right... -
Page 7: Universe Activation
Universe Activation To Activate New Universes 1: Select Fixture to Patch: Prosed to the Patch Icon on the upper left side. Click on the Load / Patch New Fixture icon 2: Make Fixture Selection: Make the selection of fixture manufacture and fixture model using the drop down fixture select. -
Page 8: Size & Weight
Size & Weight 17.37” 13.25” 1.75” 19” Fixture Size 19" X 13.25" X 1.75" Fixture Packaged 21" X 12" X 3.75" Net Weight 8.8lb Gross Weight 10lb... -
Page 9: Cleaning & Maintenance
Cleaning and Maintenance Installation Maintenance: The operator has to make sure that the unit is operating safely and has the installations and electronics checked by an expert every 2 years. The following points have to be considered during the inspection: 1) All screws used for installing the device or part of the device have to be tightly connected and must not be corroded. -
Page 10: Warranty
MEGA Systems, Inc. Warranty MEGA SYSTEMS INC (“MSI”) hereby warrants to the original purchaser/owner (“Customer”), MSI products to be free of manufacturing defects in material and workmanship, for the warranty periods as defined below from the original purchase invoice date. This warranty applies exclusively to new MSI branded and/or distributed products listed below, purchased from an MSI AUTHORIZED dealer/ reseller. -
Page 11: Customer Support
Customer Support Mega Lite has a customer support line to provide set up help and to answer any question should you encounter a prob- lem. Please visit our website for any other related technical documents. For service related issue please contact our service dept.
