Smart Switch HNS430SW Owner's

HNS430SW
OWNER'S MANUAL
1. FEATURES
• Soft touch push button ON/ OFF switch.
• Blue LED indicates device status.
• Returns to OFF after loss of power.
• Compatible with HPM and Clipsal Style wall plates.
2. OPERATING CONDITIONS
• Operating Voltage:
• Operating Temperature:
• Compliance Standard:
• Maximum Load:
• Minimum Load:
• Maximum Current capacity: 1.7A
• Terminals:
Note: Operation at temperature, voltage or load outside of the specifications may cause permanent damage to the unit.
3. LOAD COMPATIBILITY
Low Voltage Halogen / Dichroic Lighting with Iron-Core Transformers
Low Voltage Halogen / Dichroic Lighting with Electronic Transformers
Fluorescent Tube with Electronic Ballast
Refer to lamp manufacturer's guidelines. Lamps must be compatible with electronic switches
(1)
Note: This manual was correct at the time of manufacture. For the latest version of the manual and any technical or
safety updates refer to the website:- www.sclick.com.au or scan the QR code with a mobile phone.
HNS430SW Electronic ON/ OFF Switch 2-Wire
Scan our QR code
with your phone to go
directly to our website
for technical information
230 – 240V a.c. 50Hz
0 to +50 °C
CISPR15, AS/NZS 3100, AS/NZS 60669.2.1
400VA
10VA
Screw Terminals suit 0.5mm
LOAD TYPE
LED Lamps
Incandescent / 240V Halogen / Dichroic Lamps
Dimmable Compact Fluorescent Lamps
Motors / Fans / Contactors / Relays / Transformers
to 1.5mm stranded (bootlace terminal reccomended)
2 2
(1)
(1
(1)
or Iron Core Ballast
(1)
2-WIRE NOT
SUITABLE FOR
FANS, MOTORS
OR IRON CORE
BALLASTS
COMPATIBILITY
400VA
400VA
Not Compatible
400VA
)
400VA
Not Compatible
Not Compatible
CP14731 Rev 3, 7TH June 2018
