- Page 2 General description The extractor is designed to give you the option to extract to the outside TABLE OF CONTENTS (via an exterior wall) with ducting, or to re-circulate air through additional ▇ ▇ ▇ ▇ filters to minimise odours, steam and condensation. The choice is yours to decide at installation, Both options are explained in this booklet.
- Page 3 Ensure there is a minimum distance if 700mm between the bottom of the extractor and Caple hob surface. (See installation guides for other hob makes). Then fix the two mounting brackets(G) to the rear wall. Once the two mounting brackets are in position, hook the extractor mounting bracket (D) onto the wall mounting bracket.
- Page 4 Electrical Safety Cleaning Before you think about fixing, give careful consideration to the power Particular care must be paid to the grease filtering panels which must be connection. It is vital that the supply cable should be well shielded from periodically cleaned in relation to use (at least once every two months) your grill, hob or oven.
- Page 5 2. Ducted air must not be discharged into a flue which is used for The Grease Filter Mat exhausting fumes from appliances supplied with any energy other The grease filter mat on model 2MINCHP5 requires replacing or than electricity. cleaning every 3 months. The filter can be cleaned in a dishwasher 3.
- Page 6 Alternative Methods Of Extraction Electrical Connections To change the Charcoal Filter remove the flexible wire frame and simply IMPORTANT: ENSURE THAT THE ELECTRICITY SUPPLY IS replace with a new filter as shown below. SWITCHED OFF BEFORE CONNECTING. Your appliance must be connected to fix wiring via the use of a double pole switched fused spur outlet with at least 3 mm contact separation, and preferably with a pilot lamp.
- Page 7 Electrical Connections Not working Properly ? Light bulb doesn’t come on Important: The wires in this mains lead are coloured in accordance with the following A replacement is probably necessary, But check first that the bult code: is firmly screwed in to its holder. If the filament is broken, Blue Neutral remember that the light bulbs are not covered by our guarantee.
