Sharp 28LS-92E Service Manual

Sharp 28LS-92E Service Manual

System colour television
Hide thumbs

Advertisement

Quick Links

Download this manual
PAL
/ SECAM
B/G, I
ELECTRICAL SPECIFICATIONS ........................................................................................ 3
IMPORTANT SERVICING NOTES ...................................................................................... 4
CONTROLS & TERMINALS ................................................................................................ 5
PRINTED WIRING BOARD LAYOUT ................................................................................. 7
PARTS LISTING ................................................................................................................... 8
HOW TO UPDATE THE TECHNICAL INFORMATION ...................................................... 11
SHARP CORPORATION
SERVICE MANUAL
SYSTEM COLOUR TELEVISION
L/L', B/G, D/K
28LS-92E
MODEL
In the interests of user safety (required by safety
regulations in some countries) the set should be re-
stored to its original condition and only parts identi-
cal to those specified should be used.
CONTENTS
1
28LS-92E
SE0028LS92E00
Issued: 22
Jan. 2004
nd
AK- 45
CHASSIS
This document has been published to
be used for after sales service only.
ES
