- Page 1 Tracker Pod1 User Manual Revision: 1.00 Document Title Pod1 User manual 1.00 Version Finale Date 2020-03-30 Status Released Document Control ID TRACKER POD1...
-
Page 2: Table Of Contents
Contents 1 Introduction ............................ 3 2 Product Overview .......................... 3 2.1 Appearance .......................... 3 2.2 LED Description ......................... 4 3 Getting Started ..........................5 3.1 Parts List ..........................5 3.2 How GPS position Fix ......................5 3.3 Disassemble Introduction ....................5 3.4 Insert SIM Card ........................ -
Page 3: Introduction
1 Introduction Pod1 use primary batteries. it is a powerful GPS locator which is designed for vehicle, and assets tracking . With superior receiving sensitivity, Its location can be real time or schedule tracked by backend server or specified terminals. Based on the embedded wireless tracking protocol, Pod1 can communicate with the backend server through LTE Cat-M network, and transfer reports of emergency, Geo-fencing, device status and scheduled GPS position etc…... -
Page 4: Led Description
2.2 LED Description Figure 2-2 There is one tricolour LED lights in Pod1 device, the description as following. Light Event State LED show blue GPS fixed Solid LED show red low power Solid LED show green standby mode Slow Flash... -
Page 5: Getting Started
3 Getting Started 3.1 Parts List Name Picture Remark Pod1 The LTE/GPS locator. 3.2 How GPS position Fix Your device has an unobstructed view of the sky,lying face up,so it can obtain the initial GPS Fix Figure 3-1 3.3 Disassemble Introduction 1.Dismantling machine tools：... -
Page 6: Insert Sim Card
2.Machine appearance： Figure 3-2 3.Unscrew cover Figure 3-3 3.4 Insert SIM Card Figure 3-4 3.5 Device Power on Figure 3-5... -
Page 7: Install
3.6 Install Figure 3-6 4 Frequency LTE CatM: B2(TX 1850-1910MHz,RX 1930-1990MHz) LTE CatM: B4(TX 1710-1755MHz,RX 2110-2155MHz) LTE CatM: B5(TX 824-849MHz,RX 869-894MHz) LTE CatM: B12(TX 699-716MHz,RX 729-746MHz) LTE CatM: B13(TX 777-787MHz,RX746-756MHz) LTE CatM: B25(TX 1850-1915MHz,RX1930-1995MHz) LTE CatM: B26(TX814-849MHz,RX859-894MHz) LTE CatM: B66(TX1710-1780MHz,RX2110-2200MHz) LTE CatM: B85(TX698-716MHz,RX728-746MHz) LTE NB-IoT: B2(TX 1850-1910MHz,RX 1930-1990MHz) LTE NB-IoT: B4(TX 1710-1755MHz,RX 2110-2155MHz) -
Page 8: Trouble Shooting And Safety Info
Please do not put the device on the overheating or too humid place, avoid exposure to direct sunlight. Too high temperature will damage the device or even cause the battery explosion. Please do not use Pod1 on the airplane or near medical equipment. - Page 9 FCC Caution. § 15.19 Labelling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
