- Page 1 тел. +7(499) 703-39-86 www.thk.ru sales@thk.ru THK Linear Motion System Ball Spline Instruction Manual No. 1030-T34669...
-
Page 2: Table Of Contents
1. Introduction Foreword―――――――――――――――――――――――――――――――― 1-1 About This Manual―――――――――――――――――――――――――――― 1-1 Applying This Product― ――――――――――――――――――――――――― 1-2 Product Support――――――――――――――――――――――――――――― 1-2 Product Information and THK Information―――――――――――――――――― 1-2 2. Precautions on Use Safety Related Warning Displays― ―――――――――――――――――――― 2-1 Handling― ――――――――――――――――――――――――――――――― 2-1 Precautions on Use― ―――――――――――――――――――――――――― 2-2 Lubrication―... -
Page 3: Introduction
The diagrams contained herein are representative examples and may vary from the actual product. z THK will not be liable for the effects resulting from the use of this manual for any reason whatsoever. z This manual also applies to special products, but content specified on the Delivery Specification―Diagram―takes―priority.―... -
Page 4: Applying This Product
Do not use this product for equipment or systems used in life-threatening situations. z Consult THK beforehand when considering using this product for special applications such as in passenger vehicles or in medical, aviation and space, nuclear power, or electrical power equipment or systems. -
Page 5: Precautions On Use
Tilting a spline nut or spline shaft may cause them to fall by their own weight. z Take care not to drop or strike the Ball Spline. This could cause injury or damage the product. If the product receives an impact, it could impair the product's functions, even if the product Falling objects looks intact. -
Page 6: Precautions On Use
If―desiring―to―have―a―flanged-type―Ball―Spline―additionally―machined,―such―as―having―a―dowel― pin hole, contact THK. z If any of the rolling elements fall from the spline nut, discontinue use and contact THK. Falling objects Ball Spline... -
Page 7: Lubrication
Grease consistency can vary depending on the temperature. Please keep in mind that the Ball―Spline―sliding―resistance―may―be―affected―by―changes―in―consistency. z Following greasing, the stirring resistance of the grease can cause the Ball Spline to exhibit increased sliding resistance. Before commencing operation, be sure to run the unit through several warm-up cycles to ensure that the grease is adequately integrated and dispersed. -
Page 8: Assembly
Note: Both ends of the Ball Spline SLS model with a retainer have a resin end cap. Hammering or forcefully pressing may cause damage. Be careful not to apply an excessive load. - Page 9 тел. +7(499) 703-39-86 www.thk.ru sales@thk.ru 3. Assembly Assembly Model LBH Flanged Type Model LTR Pulley Pulley Model LBG Figure 3-2 Example of Mounting the Spline Nut Ball Spline...
-
Page 10: Installing The Spline Nut
Table 3-1 Model LBS Jig Dimensions Unit: mm Nominal shaft diameter 12.5 16.1 20.3 24.4 32.4 40.1 47.8 55.9 69.3 83.8 103.8 131.8 Table 3-2 Model LT Jig Dimensions Unit: mm Nominal shaft diameter 11.5 14.5 18.5 37.5 46.5 75.5 94.5 Ball Spline... -
Page 11: Installing The Spline Shaft
If the spline nut is attached with a seal or given a preload, apply a lubricant to the outer surface of the spline shaft. Serial number Matching Matching mark mark Serial number Matching mark Matching mark Matching mark Figure 3-4 Installing the Spline Shaft Ball Spline... -
Page 12: Lubrication
(or replace) roughly every 100 km of travel distance (three to six months). For a Ball Spline model type without a seal, apply grease to the interior of the spline nut or to the raceway of the spline shaft. - Page 13 Daphne Super Multi Oil (Idemitsu Kosan) Mobil DTE Oil Series (Exxon Mobil) Raceway Oil or Turbine Oil Shell Tonna S3 M (Showa Shell Sekiyu) Mobil Vactra Numbered Series (Exxon Mobil) ISOVG32 to 68 Mobil Vactra No. 2 SLC (Exxon Mobil) or equivalent Ball Spline...
- Page 14 тел. +7(499) 703-39-86 www.thk.ru sales@thk.ru Appendix Revision History The instruction manual number is on the back cover. Publication Date Instruction Manual No. Revisions December 2017 No. 1030-T34669 First edition...
- Page 15 тел. +7(499) 703-39-86 www.thk.ru sales@thk.ru Inquiries Website URL: https://www.thk.com/eng/ Technical support site URL: https://tech.thk.com/ No. 1030-T34669...
