- Page 1 English English DOUBLE SIDED DOUBLE SIDED Evoflame & E-Smart Evoflame & E-Smart INSTRUCTION MANUAL INSTRUCTION MANUAL E810 DS E810 DS Stora DS Stora DS E1030 DS E1030 DS Lindstrom DS Lindstrom DS EVONIC - 104 INSTRUCTION MANUAL ISS. 11 EVONIC - 104 INSTRUCTION MANUAL ISS. 11...
-
Page 2: Table Of Contents
CONTENTS EU Directives and UKCA Standards..............3 Important Information and Health & Safety............4 Components for Evoflame & E-Smart..............5 Installation......................6 Model Dimensions..................7 Requirements and Checks................8 Installation....................9 Log Layouts......................11 Installing/Removing the Front Glass..............13 Troubleshooting....................14 Warranty &... -
Page 3: Eu Directives And Ukca Standards
EU DIRECTIVES All Evonic Fires products meet the requirements of the EC Directives. All Evonic Fires products meet the requirements of the EC Directives. These directives have been met by compliance with the following standards: These directives have been met by compliance with the following standards: EU 2011-65/EU 2015/863 Restriction of Hazardous Substances. -
Page 4: Important Information And Health & Safety
IMPORTANT INFORMATION AND HEALTH & SAFETY When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: • Read all of the instructions carefully before using the appliance, only use this appliance as described in this manual. -
Page 5: Components For Evoflame & E-Smart
EVONIC - 104 INSTRUCTION MANUAL ISS. 11 EVONIC - 104 INSTRUCTION MANUAL ISS. 11... -
Page 6: Installation
INSTALLATION INSTALLATION EVONIC - 104 INSTRUCTION MANUAL ISS. 11 EVONIC - 104 INSTRUCTION MANUAL ISS. 11... -
Page 7: Model Dimensions
MODEL DIMENSIONS The model shown in these drawings is an E1030DS, however the same processes apply to all DS appliances. Scan the QR code for more detailed specification drawings. Model Width Height Depth Overall unit Overall unit Openings Overall unit E810 DS 864mm 1208mm... -
Page 8: Requirements And Checks
INSTALLATION INSTALLATION REQUIREMENTS Before installing the appliance please read and take into account the following impor- tant requirements; • Consult a qualified professional to check the structure of the installation site. • The appliance must not be installed any- where that it may come into contact with water, i.e. -
Page 9: Installation
TOOLS REQUIRED • Tape Measure • Screwdriver • Pencil • PZ2 Screw Bit • Spirit Level INSTALLATION STEPS Remove the two bottom mounted transit brackets from both sides. You will not need these for the installation. Determine the finished height and position that you want the appliance to be located. - Page 10 Your plasterboard can now line up with the plaster kits on the edge of the appliance. Your installation is now complete and you can set up your logs. EVONIC - 104 INSTRUCTION MANUAL ISS. 11 EVONIC - 104 INSTRUCTION MANUAL ISS. 11...
-
Page 11: Log Layouts
LOG LAYOUTS LOG LAYOUTS EVONIC - 104 INSTRUCTION MANUAL ISS. 11 EVONIC - 104 INSTRUCTION MANUAL ISS. 11... - Page 12 LOG LAYOUTS When you have your appliance installed you can set up your log sets. If your model comes with Chippings, Glass Stones and/or Vermiculite lay this on the fuel bed first, then continue with laying out your logs. The following images show an example of how you could lay them out.
-
Page 13: Installing/Removing The Front Glass
INSTALLING / REMOVING THE FRONT GLASS Unscrew and remove the glass retainer panel. Apply the Suction Lifter to the glass and place the bottom edge in first, then angle the top edge into the appliance. Then replace the top retainer panel. Warning The Suction Lifter is provided to assist in moving... -
Page 14: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING EVONIC - 104 INSTRUCTION MANUAL ISS. 11 EVONIC - 104 INSTRUCTION MANUAL ISS. 11... - Page 15 Evoflame Only - LED Strip Replacement Scan the QR code to be taken to a video in our maintenance series. Please note; this video shows an old method of removing the front glass panel. Refer to page 13 for the new method. Fan Re-setting &...
-
Page 16: Warranty & Registration
WARRANTY & WARRANTY & REGISTRATION REGISTRATION EVONIC - 104 INSTRUCTION MANUAL ISS. 11 EVONIC - 104 INSTRUCTION MANUAL ISS. 11... - Page 17 This warranty is in addition to and does not affect the purchasers statutory rights of consumers. REGISTER YOUR FIRE To register a product please visit: www.evonicfires.co.uk and complete the fields required under the Register a Product Section. By registering your appliance, an extra 12 months will be added to your warranty.
- Page 18 CK Fires Ltd / Evonic Fires 1, Evonic House, Clifford Park, Clifford Lane, Stratford-on-Avon, CV37 8HW Tel: +44 (0)1789 263868 Fax: +44 (0)1789 293080 Email: sales@evonicfires.co.uk www.evonicfires.co.uk Follow us on: Instagram | Facebook | Twitter | LinkedIn @evonicfires EVONIC - 104 INSTRUCTION MANUAL ISS. 11...
