Summary of Contents for Evonicfires E-LLUSION Alisio 850
- Page 1 English English E-LLUSION E-LLUSION E-Smart E-Smart INSTRUCTION MANUAL INSTRUCTION MANUAL Alisio 850 Alisio 850 Alisio 1550 Alisio 1550 Sirus Sirus Alisio 1150 Alisio 1150 Alisio 1850 Alisio 1850 EVONIC - 104 INSTRUCTION MANUAL ISS. 9 EVONIC - 104 INSTRUCTION MANUAL ISS. 9...
-
Page 2: Table Of Contents
CONTENTS EU Directives and UKCA Standards..............3 Important Information and Health & Safety............4 Components for E-llusion..................5 Installation for Alisio..................... 6 Model Dimensions..................7 Installation Process..................9 Converting to GF / GF2 / GF3............... 10 Installing the Side Panels / Converting to GF / GF2......11 Requirements and Checks................ -
Page 3: Eu Directives And Ukca Standards
EU DIRECTIVES All Evonic Fires products meet the requirements of the EC Directives. All Evonic Fires products meet the requirements of the EC Directives. These directives have been met by compliance with the following standards: These directives have been met by compliance with the following standards: EU 2011-65/EU 2015/863 Restriction of Hazardous Substances. -
Page 4: Important Information And Health & Safety
IMPORTANT INFORMATION AND HEALTH & SAFETY When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: • Read all of the instructions carefully before using the appliance, only use this appliance as described in this manual. -
Page 5: Components For E-Llusion
EVONIC - 104 INSTRUCTION MANUAL ISS. 9 EVONIC - 104 INSTRUCTION MANUAL ISS. 9... -
Page 6: Installation For Alisio
INSTALLATION INSTALLATION Alisio Alisio EVONIC - 104 INSTRUCTION MANUAL ISS. 9 EVONIC - 104 INSTRUCTION MANUAL ISS. 9... -
Page 7: Model Dimensions
MODEL DIMENSIONS The model shown in these drawings is an 1150, however the same processes apply to all Alisio models. Scan the QR code for more detailed specification drawings. EVONIC - 104 INSTRUCTION MANUAL ISS. 9 EVONIC - 104 INSTRUCTION MANUAL ISS. 9... - Page 8 MODEL DIMENSIONS Model Width Height Depth With glass With Overall unit Opening Overall unit sides optional side panels 882mm 902mm 557mm 350mm 315mm 1150 1182mm 1202mm 557mm 350mm 315mm 1550 1582mm 1602mm 557mm 350mm 315mm 1850 1882mm 1902mm 557mm 350mm 315mm EVONIC - 104 INSTRUCTION MANUAL ISS.
-
Page 9: Installation Process
INSTALLATION PROCESS Alisio Model Alisio Model (GF2) (GF2) (GF3) (GF3) (GF) (GF) Front & Front & Front & Front & Glass Glass 1 Glass Side 1 Glass Side 2 Glass Sides 2 Glass Sides Fronted Fronted Fit 2 Side Panels Fit 2 Side Panels Fit 1 Side Panel Fit 1 Side Panel... -
Page 10: Converting To Gf / Gf2 / Gf3
CONVERTING TO GF / GF2 / GF3 The appliance is shipped in the GF3 configuration, however it can be converted to be GF or GF2 depending on your preference. GF Configuration Glass Fronted A single glass panel at the front of the appliance. -
Page 11: Installing The Side Panels / Converting To Gf / Gf2
INSTALLING THE SIDE PANELS / CONVERTING TO GF / GF2 Unscrew and remove the plaster kits from the side/s of the appliance. Screw in the side panel/s, on one or both sides. EVONIC - 104 INSTRUCTION MANUAL ISS. 9 EVONIC - 104 INSTRUCTION MANUAL ISS. 9... -
Page 12: Requirements And Checks
INSTALLATION INSTALLATION REQUIREMENTS Before installing the appliance please read and take into account the following important requirements; • Consult a qualified professional to check the structure of the installation site. • These appliances have been designed to be installed into either a stud and plasterboard wall, or an existing chimney breast. -
Page 13: Installation
TOOLS REQUIRED • Tape Measure • Rear Wall Screws (Masonry type supplied) • Pencil • Top Mounted Bracket Screws (supplied) • Spirit Level • Top Mounted Bracket Wall Plugs (supplied) • Screwdriver • Stud Detector (Plasterboard installations • PZ2 Screw Bit only. - Page 14 Determine the finished height and position that you want the appliance to be located. Then secure the wall bracket to the wall in the position you need using the wall plugs and screws provided. If you’re not securing the appliance to a masonry wall you will need to use the appropriate fixings.
- Page 15 Screw the two top mounted brackets to the wall. You can now construct your stud wall/s around the appliance in the design of your choosing. When constructing the studwork, remember that the vents on the underside of the appliance need a minimum of 50mm clearance beneath them.
- Page 16 Your plasterboard can now line up with the plaster kits on the edge of the appliance. Alternatively, the chrome side panels can be attached to the case with the magnets as shown below. Ensure that the magnets are positioned with the short side touching the case. EVONIC - 104 INSTRUCTION MANUAL ISS.
-
Page 17: Installation For Sirus
INSTALLATION INSTALLATION Sirus Sirus EVONIC - 104 INSTRUCTION MANUAL ISS. 9 EVONIC - 104 INSTRUCTION MANUAL ISS. 9... -
Page 18: Model Dimensions
MODEL DIMENSIONS EVONIC - 104 INSTRUCTION MANUAL ISS. 9 EVONIC - 104 INSTRUCTION MANUAL ISS. 9... -
Page 19: Requirements And Checks
INSTALLATION TOOLS REQUIRED • Tape Measure • Screwdriver • Pencil • PZ2 Screw Bit • Spirit Level • Screws (Supplied) INSTALLATION REQUIREMENTS Before installing the appliance please read and take into account the following important requirements; • Consult a qualified professional to check the structure of the installation site. •... -
Page 20: Installation
INSTALLATION STEPS First, unscrew and remove the four transit brackets on the bottom corners of the fire. You won’t need these for the installation. Then measure the appliance, excluding the plaster kits, to determine the size of the opening you need to create. -
Page 21: Installation With Fascia Board
WITH FASCIA BOARD Plasterboard your studwork, then slide the appliance into the prepared void. Once in place screw the appliance to the plasterboard using the two screw holes on each side. Do not use silicones or adhesives to seal in the appliance. -
Page 22: Installation Without Fascia Board
WITHOUT FASCIA BOARD Slide the appliance into the prepared void then screw the appliance to the studwork using the two screw holes on each side. You can now plasterboard your studwork fitting it flush with the plaster kits on the appliance. Then screw the plasterboard to the appliance using the two screw holes on the inner sides. -
Page 23: Removing The Internal Glass
REMOVING THE INTERIOR GLASS Unscrew and remove the top side brackets and decorative panels on the sides of the interior. Then remove the velcro decorative panel at the back of the internal glass. Lift and slide out the interior glass panel. You can now set up your logs, and replace the interior glass by reversing the above steps. -
Page 24: Log Layouts
LOG LAYOUTS LOG LAYOUTS EVONIC - 104 INSTRUCTION MANUAL ISS. 9 EVONIC - 104 INSTRUCTION MANUAL ISS. 9... - Page 25 LOG LAYOUTS When you have your appliance installed you can set up your log set/s. Lay out the provided Glass Stones and Vermiculite on the fuel bed first, then continue with laying out your logs. There is no right or wrong way to arrange your logs, the following images are an example of how you could lay them out.
-
Page 26: Installing The Glass Alisio
INSTALLING THE GLASS INSTALLING THE GLASS Alisio Alisio EVONIC - 104 INSTRUCTION MANUAL ISS. 9 EVONIC - 104 INSTRUCTION MANUAL ISS. 9... - Page 27 INSTALLING THE ANGLED SCREEN Apply the Suction Lifter to the glass and position the bottom edge of the glass behind the retaining bar. Warning The Suction Lifter is provided to assist in moving the glass NEVER as the sole support of the glass.
- Page 28 INSTALLING THE SIDE & FRONT GLASS PANELS If you are installing a GF model, you should complete Step 1 then skip to Step 3. Unscrew and remove the top glass retaining bar. Position and slide in the glass panel/s to one or both sides. EVONIC - 104 INSTRUCTION MANUAL ISS.
- Page 29 Pivot the front glass into the appliance from the bottom edge first. Then replace the top glass retaining bar. EVONIC - 104 INSTRUCTION MANUAL ISS. 9 EVONIC - 104 INSTRUCTION MANUAL ISS. 9...
-
Page 30: Installing The Glass Sirus
INSTALLING THE GLASS INSTALLING THE GLASS Sirus Sirus EVONIC - 104 INSTRUCTION MANUAL ISS. 9 EVONIC - 104 INSTRUCTION MANUAL ISS. 9... - Page 31 RE-INSTALLING THE INTERIOR GLASS Replace the interior glass that you removed on page 23 by repeating the steps in reverse, Replace the interior glass that you removed on page 23 by repeating the steps in reverse, making sure that you’re happy with your log layout. making sure that you’re happy with your log layout.
-
Page 32: Troubleshooting Warranty & Registration
TROUBLESHOOTING TROUBLESHOOTING WARRANTY & WARRANTY & REGISTRATION REGISTRATION EVONIC - 104 INSTRUCTION MANUAL ISS. 9 EVONIC - 104 INSTRUCTION MANUAL ISS. 9... - Page 33 This warranty is in addition to and does not affect the purchasers statutory rights of consumers. REGISTER YOUR FIRE To register a product please visit: www.evonicfires.co.uk and complete the fields required under the Register a Product Section. By registering your appliance, an extra 12 months will be added to your warranty.
- Page 34 CK Fires Ltd / Evonic Fires 1, Evonic House, Clifford Park, Clifford Lane, Stratford-on-Avon, CV37 8HW Tel: +44 (0)1789 263868 Fax: +44 (0)1789 293080 Email: sales@evonicfires.co.uk www.evonicfires.co.uk Follow us on: Instagram | Facebook | Twitter | LinkedIn @evonicfires EVONIC - 104 INSTRUCTION MANUAL ISS. 9...
