Nexus Input Breakout Module
Introduction
Congratulations on your purchase of this SynQuaNon product! It is our belief that our
products will enable you to find new and interesting ways to create custom sounds
with your synthesizer and other SynQuaNon modules. Check out our full line at
www.synquanon.com.
➊
➋
➊
Input
➋
Outputs
➌
Audio outputs
➍
CV outputs
Nexus Input Breakout Module User Manual
Module front panel overview
➌
LEMO-compatible 19-pin jack.
Channels 1-6 are dedicated to audio only. The outputs on
jacks 7, 8 depend on the connections set in the Nu Multi
guitar (7- and 8-string audio or CVs).
Jacks dedicated to audio as selected on back of module.
Jacks dedicated to CVs as selected on back of module.
➍
Page
1
of
3
