Richell 803840 94902-3 Instruction Manual

Manuel d' instruction
Thank you for choosing Richell's Product. Please read this instruction manual carefully before using this product, and keep
for future reference. If you give this product to someone else, please also give this instruction manual to the new owner.
Please note some parts of the figures shown below may be slightly different from the actual product, for your better
understanding of the structure and proper use of the product.
1. Proper Usage
This product is designed for medium size dogs, 17.6 - 44 lbs. No screws or additional tools are needed to mount the gate in
a doorway or hallway opening of 30" - 35.8" wide.
Welsh Corgi, Spitz, etc
Medium Dog*
2. Features
lTension-mount design is safe to use on wall surfaces.
Designed for placement against a wall or within a door frame
using a tension-spring effect. The extra width at the top of the
Main Frame is not a defect. The top of the gate will be wider
than the bottom before installation because of the tension-spring
design of the product. Tightening the top Adjuster Knobs will
create the same spacing between the Gate Door and the Main
Frame during installation.
NOTE:
This product includes a bottom bar that is part of the Main Frame.
The bottom bar should touch the floor when correctly installed.
Pay close attention while stepping over the bottom bar for safety.
3. Parts/Specifications
Handle
Top Lock
Bottom Lock
Body (1)
What are the following signs?
The following signs are special remarks for safety use of the product.
Keep these remarks in mind before using this product.
Warnings!
: Remarks on inappropriate use which might cause death, serious injury and/or physical damage.
Cautions!
: Remarks on inappropriate use which might cause slight injury and/or physical damage.
Important!
: Remarks on inappropriate use which might cause trouble, damage and/or shorter life to product.
4. Instruction of Proper Use
Warnings!
l IMPORTANT: This product includes a bottom bar that is part of the Main Frame. The bottom bar should touch
the floor when correctly installed. Pay close attention while stepping over the bottom bar for safety.
l Keep this product in sight to avoid unexpected injury and/or accidents when pets behave unexpectedly.
l Be careful not to stumble on bottom of door frame.
l Never place the product at the top of a staircase, near a glass door, or exit hallway. Avoid places
where it may be unsafe to install this product.
l Lock the Gate Door at all times when not in use to keep pets confined safely and to avoid unexpected
escape and/or injuries to pets during confinement
(please see step ).
l CHILDREN and ADULTS can trip over product under low-light/darkness. Place a night light
near the product to avoid possible personal injury under low-light/dark conditions.
l Install this product onto a wall surface that is vertical and a floor surface that is steady and level.
The door frame must be wider than 2.4" for proper installation
(please see step ).
Instruction Manual Manual de instrucciones
Examples of appropriate dog types: should weigh between 17.6 - 44 lbs.
*Do not use this product if your dog weighs less than 17.6 lbs or more than 44 lbs.
Before installing this product, make sure the following parts are included:
Door
Main Frame
7. Installation Check / How to Open and Close the Door
6. How to Install the Gate
取扱説明書
The top width of frame is wider than the bottom
Tension
-force
Option Frame (1)
1
Knob gasket (small) (1) Knob gasket (large) (1)
Adjuster Knob (4)
Adjuster Bolt (4)
Adjuster Set
94902
UPC
JAN
98790
Tension
-force
