- Page 1 MMR-77CL 中文 Version 1...
- Page 2 Controls AM/FM band switch Rotary tuning Dynamo power Power and volume control AM/FM band indicator Hand strap holder Tuning LED indicator Earphone socket Charging LED indicator DC jack for AC power adaptor Backlight button Battery/Dynamo switch Dial scale Battery compartment Dial pointer Wire antenna...
- Page 3 Power Supply 1. Battery operation a. Open the battery compartment by pressing the marking and opening the lid. b. Take out the used batteries by pulling the first one with your index finger. Then take out the second battery. c. When inserting the new batteries (2 x 1.5V, type UM-3, AA or LR6), observe the correct polarity.
- Page 4 3. Dynamo power Note: You can charge the radio via Dynamo power either the battery switch in battery or dynamo position. The Dynamo charging is to the built-in dynamo battery not the battery in the battery compartment. a. take out Dynamo power handle from it rest position. b.
- Page 5 Radio operation 1. Select the power to be Battery (make sure the batteries are in and powerful) or Dynamo position by switching battery/dynamo switch. 2. Switch on the radio by turning the power/volume control. 3. Select required radio band (AM or FM). 4.
- Page 6 Technical Data Power Supply: Battery operation 2x1.5V (type Mignon LR6/UM3/AA) Mains operation 3V 300mA, mains power adaptor, center Pin Positive in polarity Dynamo operation built-in 2 AAA size x 1.2V rechargeable Battery Output 100 mW Frequency Coverage FM (VHF) 87.50 - 108 MHz AM (MW) 530 - 1710 kHz Antenna wire antenna FM (VHF)
