Important safety instructions! Please read before connection!
Laser safety requirements - basic principles:
It is based on the BGV-B2 of the UVV of the Berufsgenossenschaften in Germany and the DIN EN
60825-1:2015.
This effect includes a laser of class 4. The system is equipped with a connection for an external
safety switch and a safety key. The safety key should always be removed from the device if no
trained personnel are using the product.
The operator of the system is responsible for the health of the persons present! It is therefore
essential that you familiarise yourself with the applicable regulations for the operation of systems
with lasers. It is essential that you observe the following instructions for safe use.
Before commissioning, an expert must be appointed in writing by the operator of the system as
laser safety officer. In addition, the operation must be reported to the authority responsible for
occupational health and safety and to the employers' liability insurance association. If the laser
system is to be operated publicly, it must first be submitted to an expert for acceptance.
DANGER! (Electrical shock due to high voltages in the device)
The housing must not be removed! There are no parts to be maintained in the device.
Inside the unit there are components which are under high electrical voltage.
Before each use, check the device for damage or the absence of components, protective
devices or housing parts. If this is the case, the device must not be used!
Leave maintenance and repair work to a qualified service workshop or contact your
dealer. In the case of a malfunction of the device, operation must also be stopped
immediately until the device has been repaired by a specialist!
DANGER! (Electric shock due to short circuit)
Modifications to the power cord or plug are prohibited. If the power cord is damaged, it
must be replaced immediately with an original spare part from the manufacturer. Failure to
do so may result in fire or death due to electric shock!
DANGER! (Laser radiation - do not expose to the beam)
This effect includes a class 4 laser according to EN 60825-1:2015. Do not look into the
laser beam! Do not expose to the laser beam! Looking into the laser beam can cause eye
injuries. Burns can be caused by the laser beam. In addition, care must be taken when
using optically collecting instruments.
DANGER! (For babies and children)
Dispose of or store any packaging material properly! Packaging material must be kept out
of the reach of babies and children due to the risk of suffocation.
Ensure that children never use the appliance unattended! In addition, make sure that
children do not remove (small) parts from the device, as they could suffocate by swallowing
parts!
ENGLISH

Advertisement

Table of Contents
loading

Summary of Contents for Lightmaxx VEGA Lase 3.0

  • Page 1 ENGLISH Important safety instructions! Please read before connection! Laser safety requirements - basic principles: It is based on the BGV-B2 of the UVV of the Berufsgenossenschaften in Germany and the DIN EN 60825-1:2015. This effect includes a laser of class 4. The system is equipped with a connection for an external safety switch and a safety key.
  • Page 2 ENGLISH WARNING! (Epilepsy) Stroboscopic effects (flashes of light) can trigger seizures of epilepsy in some people. Accordingly sensitive people should be warned and should not be in the vicinity of such devices. Hint! (Fire hazard due to overheating) The maximum permissible ambient temperature of this device is 40°C. Ensure that the unit is placed in a well-ventilated location away from direct heat sources, naked flames, combustible materials, and liquids.
  • Page 3 ENGLISH Symbols on device and packaging: The lightning flash symbol warns the user of uninsulated voltages and the risk of electric shock. The exclamation mark symbol draws the user’s attention to important maintains and operating instructions in the manual. Only suitable for indoor use. Read the manual Please read and follow the warnings and recommendations carefully to ensure safe and trouble-free use.
  • Page 4: Installation

    ENGLISH Installation: Be sure to check the unit for damage before use. Use the original packaging or a suitable transport or storage packaging to protect the product from dust, moisture, etc. when not in use. The unit can be installed either upright or suspended. The device must always be attached to a solid, approved carrier or a suitable surface.
  • Page 5: Intended Use

    Manual Intended use: The lightmaXX VEGA Lase 3.0 was designed for use as an electronic LED lighting effect. The device may only be used for this purpose and in accordance with the operating instructions. Other purposes as well as operation under other operating conditions are expressly not intended and can lead to damage to property or personal injury! No liability is assumed for damage resulting from improper use.
  • Page 6: Operating Mode Dmx

    ENGLISH Set up: All connections of the device should be made before switching on. Only use high-quality cables that are as short as possible for the connections. Configuration of the DMX connector: Resistance 120 ohm // ¼ w between pin 2 (DMX-) and pin 3 (DMX+) oft he last fixture. Operating mode DMX: Connect the DMX input of your device to the DMX output of your DMX controller, your DMX software or the DMX output of a device already in your DMX line.
  • Page 7 ENGLISH 13-channel-Mode Channel Value Function 000-073 LASER Blackout 074-110 PRG show in SD card 111-147 ILD show in SD card 148-165 AUTO SHOW 1 166-184 AUTO SHOW 2 185-202 MUSIC SHOW 1 203-221 MUSIC SHOW 2 222-255 DMX mode (other channels activated) 000-255 86 Patterns as shown in pattern list 000-005...
  • Page 8 ENGLISH 000-010 Original pattern 011-074 Fixed clipping 075-104 Clipping out 105-144 Clipping in 145-184 Clipping out and in 185-224 Clipping on 225-255 Clipping off 000-010 Original pattern 011-189 Wave effect in pattern with speed control 190-255 Wave effect in pattern with amplitude control 000-016 White 017-033...
  • Page 9 ENGLISH Overview of 86 integrated patterns...
  • Page 10: Operation

    ENGLISH Static, Auto or Sound mode: The device contains automatic programs that run according to fixed schemes (Auto) or are recalled via the built-in microphone to match the music (Sound). The selection of the respective mode takes place via the menu directly on the device. If you connect several devices of the same type via DMX, they can be controlled simultaneously via the master device.
  • Page 11: Connections And Controls

    ENGLISH Connections and controls: Front Function Function Music signal detected to Handle synchronize Main power indicator. Red light is Position Lock Power ON. Laser aperture, do not look directly into the window!
  • Page 12 ENGLISH Back Function Function Switch on/off the power ILDA Out (25-pin) Key switch Eye bolt Interlock Control panel SD-Card Slot Cooling Fan DMX-Input (3-polig) Power input DMX-Output (3-polig) Power output ILDA In (25-pin)
  • Page 13 ENGLISH Menu: Navigation in the menu is via the four menu buttons below the display. Use the "Mode" button to activate the menu, navigate via the "Up" and "Down" buttons. A corresponding selection is confirmed with the "Enter" key. The menu structure in detail: Menu Value Function...
  • Page 14: Specifications

    ENGLISH Specifications: Model VEGA Lase 3.0 Power supply 100-240V 50/60Hz Power consumption 60 Watts Lightsource 638nm 700mw Green 525nm 900mw Blue 450nm 1400mw Fuse T1.6A , 250V Laser divergence angle 1.8mard (Full angle) Laser class Scanner 30Kpps, 1-36° (Angle) DMX-Connections...
  • Page 15: Troubleshooting

    ENGLISH Troubleshooting: The following overview serves as an aid for quick troubleshooting. If you are unsure, contact the manufacturer, the dealer or the corresponding specialist personnel. Never open the device on your own! Symptom Troubleshooting No function Check the mains connection and the fuse Check the cable connections No reaction in DMX mode Check your DMX address setting...
  • Page 16 ENGLISH Disposal of your old device: Do not dispose of the device with household waste! This device is subject to the WEEE Directive (Waste Electrical and Electronic Equipment) in its currently valid version. The device will be disposed of by an approved waste disposal company or your local waste disposal office.
