Manual Revision: 2011-08-26
Covers Software Revisions:
VS-1XXX: 01.31.00 & Higher
This manual & product supports the following radios:
Portables: TK-2180, TK-3180
Mobiles: TK-5710, TK-7180, TK-8180
Installation Manual
VS-1200-KW1
Frequency Domain Scrambler with Multi-Format ANI
VS-110- KW1
Rolling Double Inversion Scrambler
VS-1100- KW1
Double Inversion Scrambler
VS-1000- KW1
Voice Inversion Scrambler
VS-1050- KW1
Voice Inversion Scrambler with Multi-Format ANI
American Communication Systems
Discover the Power of Communications
TO ORDER – VISIT
http://www.ameradio.com
1
™
Advertisement
Table of Contents
Related Manuals for Midian VS-1200-KW1
Summary of Contents for Midian VS-1200-KW1
- Page 1 Installation Manual VS-1200-KW1 Frequency Domain Scrambler with Multi-Format ANI VS-110- KW1 Rolling Double Inversion Scrambler VS-1100- KW1 Double Inversion Scrambler VS-1000- KW1 Voice Inversion Scrambler VS-1050- KW1 Voice Inversion Scrambler with Multi-Format ANI Manual Revision: 2011-08-26 Covers Software Revisions: VS-1XXX: 01.31.00 & Higher This manual &...
-
Page 2: Hardware Specifications
HARDWARE SPECIFICATIONS Operating Voltage 4.75-9.5 VDC Operating Current – VS-1200, VS-110 & VS-1100: Power Save Mode (COR Operation) 2.5 mA typical Power Save Mode (VOX Operation) 10 mA typical Clear or Inversion Operation 29 mA typical FFT Scrambling Operation 83 mA typical Average w/COR Power Save (80-10-10 cycle) <17 mA* Average w/COR Power Save (90-5-5 cycle) -
Page 3: Installation Overview
3. Install the scrambler into the radio per the Hardware Installation Section of this manual. 4. Program the radio per the Radio Programming Section of this manual. *** Midian is not responsible for any damage/loss resulting from the use of Midian’s products. -
Page 4: General Information
VS-110: Midian’s VS-110 is a rolling double inversion scrambler that offers 1020 possible codes (4 groups with 255 codes per group). Of these codes the scrambler may be programmed with up to 4 of these codes. The VS-110 series is compatible with Icom’s UT-110. -
Page 5: Product Programming
English keyboard such as 0-9, A-Z (upper and lower case), *, #, @, $, etc. Spaces are also allowed. Midian does not recommend using international language character such as ñ, ä, ß, ü, é, etc. as these have not been tested. -
Page 6: Hardware Alignment
The scrambler uses programmable gain amplifiers to accomplish this. Determining the gain settings for these amplifiers is an involved process, so Midian simplified this process by developing an algorithm that requires the technician to make only four voltage measurements. From these four measurements, all of the many internal settings are determined. - Page 7 Midian recommends the following values based on 60% modulation: The following table shows Midian’s recommended levels in mVpp for the VS-1200, VS-110 & VS-1100 at 60% modulation for tested models of radios:...
-
Page 8: Hardware Installation
HARDWARE INSTALLATION Be certain to follow standard anti-static procedures when handling any of Midian’s products. When ordering the scrambler, the radio must be specified as audio levels vary between radio models. TK-2180, TK-3180: Plug the unit into the options connector located behind the options door under the battery. Before plugging the unit in, remove R-659 to open the radio’s TX path and R-670 to open the radio’s RX path. -
Page 9: Radio Programming
RADIO PROGRAMMING TK-2180, TK-3180: Use KPG-89 version 1.51 or higher. Under the “Edit” menu select “Extended Function” and set “Optional Board” as “Voice Scrambler”. Under the “Edit” menu select “Key Assignment” and set “Side 2” under the “Top/Side” tab as “Scrambler”. This will set the button under the PTT as the mode select button. - Page 10 TK-5710: Under the “Edit” menu select “Extended Function” and set “Optional Board” as “Voice Scrambler + ANI Board”. Under the “Edit” menu select “Key Assignment” and under the “Head 1” tab set the desired button (PF1-PF5) as “Scrambler/Encryption”. This will set the programmed button as the mode select button. If Emergency ANI in the VS-1200 or VS-1050 is being used PF5 must be set to “Emergency”.
- Page 11 Under the “Edit” menu select “Key Assignment” and under the “Panel” tab set the desired button Triangle, A, B, C or Square as “Scrambler”. This will set the programmed button as the mode select button. If using Midian’s Kryptic ENI set the triangle button to Emergency.
-
Page 12: Operation
However, some features may not be available in the radio when an option board is used. If a feature is not available, please contact Midian to see if the feature can be added. - Page 13 (SOURCE) 1.2M P1:14 +3.3VDD NOTES: * = NOT INSTALLED 560p P1:10 .0068u U7:1 100K U7:2 P1:13 DOCUMENT NAME 8.2K MIDIAN ELECTRONICS, INC. .01u VS-1000/1050-KW1 .001u cs7508b4_vs10kw1 APPR DATE: DWN BY: SCHEMATIC SHEET PROJECT NUMBER DESIGN: 2007-12-16 REV: 2009-10-22 COPYRIGHT © 2009...
- Page 14 This page intentionally left blank...
- Page 17 (SOURCE) 1.2M P1:14 +3.3VDD NOTES: * = NOT INSTALLED 560p P1:10 .0068u U7:1 100K U7:2 P1:13 DOCUMENT NAME 8.2K MIDIAN ELECTRONICS, INC. .01u VS-1200-KW1 .001u cs7508b4_vs12kw1 APPR DATE: DWN BY: SCHEMATIC SHEET PROJECT NUMBER DESIGN: 2007-12-16 REV: 2009-10-22 COPYRIGHT © 2009...
- Page 18 This page intentionally left blank...
