ARABLE Mark 2 Quick Start Manual

1 Uninstall Mark
Remove Mark 2 from mount. Remove the device by loosening
the mounting screw and carefully lifting the device off the
mounting pole.
3 Confirm Undeployment
Verify by pressing the top button for 1 second, then check
the LED on the bottom of the Mark. If yellow, the device has
successfully undeployed.
Remove Bird Spikes
5
Remove bird-deterrent spikes. Pinch the ends of each spike,
and push back through the slots. It may be helpful to have a
small pair of pliers nearby.
04/2021 Arable Labs. Inc. www.arable.com
Safe removal and storage of your Arable Mark 2
2 Undeploy Mark
To undeploy, press and hold the top button for 5 seconds.
The top four LEDs will begin blinking blue and then turn off
one-by-one in a counter-clockwise direction.
4 Uninstall Mounting Equipment
Remove pole and ground anchor, if using. Don't forget a metal
rod to unscrew the anchor. Make sure to hold on to the eye bolts.
Wipe Clean
6
Clean the exterior of the device with a soft cloth. Take special
care with the clear dome and the white area over the
spectrometer and radiometers.
