INSTRUCTION MANUAL
WINE/BEVERAGE CELLAR SEAMLESS FRAME
WINE COOLER model:
ILWS18BV、ILWD36BV、ILWD37BV、ILWD154BV、ILWDD154BV
BEVERAGE COOLER model:
ILBC142BV
To ensure proper use of this
instructions completely before operating this appliance.
Version number : V20200615
and your safety, please read the following
appliance
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ILVE ILWS18BV
Summary of Contents for ILVE ILWS18BV
- Page 1 INSTRUCTION MANUAL WINE/BEVERAGE CELLAR SEAMLESS FRAME WINE COOLER model: ILWS18BV、ILWD36BV、ILWD37BV、ILWD154BV、ILWDD154BV BEVERAGE COOLER model: ILBC142BV To ensure proper use of this and your safety, please read the following appliance instructions completely before operating this appliance. Version number : V20200615...
-
Page 2: Important Safety Instructions
1. IMPORTANT SAFETY INSTRUCTIONS WARNING Before the appliance is used, it must be properly positioned and installed as described in this manual. So read the manual carefully. To reduce the risk of fire, electric shock or injury when using the appliance, follow basic precautions. - Page 3 • When disposing of your appliance, please choose an authorized disposal site. • This appliance is equipped with a power cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded •...
-
Page 4: Installation Instructions
2. INSTALLATION INSTRUCTIONS ATTENTION If the appliance is transported in a horizontal position, the oil from the compressor may leak into the cooling circuit. For this reason, allow the appliance to rest in a vertical position for 12 hours before turning it on, so that the oil flows back into the compressor. -
Page 5: Operating Your Appliance
Correct installation (e.g. leveling, the capacity of the system corresponds to the specifications on the rating label of the appliance). COMMANDS ILWS18BV、ILWD36BV This wine cooler has a temperature range from 4°C to 18°C “ ”button to turn the unit ON and OFF,press and hold this button for approximately 3 seconds. -
Page 6: Selector Buttons
“ ” button: turns the interior light ON and OFF. If you use this button, the light is no longer controlled by the switch, and remains ON.(Light button is useless when Energy conservation button is on ) LED display Display screen shows the temperature setting. ILWD37BV The upper zone has a temperature range of 5°C to 12°C, The lower zone has a temperature range of... - Page 7 ILWD154BV、ILWDD154BV This wine cooler has a temperature range from 4°C to 18°C. “ ”button to turn the unit ON and OFF,press and hold this button for approximately 3 seconds. “ ” button Energy conservation button: Pressing this button for 3 seconds will turn the energy conservation mode ON or OFF.
-
Page 8: Temperature Settings
“ ” button: It is used to increase (warm) the temperature in steps of 1°C. “ ” button: It is used to decrease (cool) the temperature in steps of 1°C. “ °C/°F ” button : press this button to switch the indicator light between° C/°F. “... -
Page 9: Wine Storage
It is normal that the cabinet shows “HI” or “LO” from time to time. If it occurs frequently or lasts for a long time, you can restart the unit by unplugging it, then re-plugging after 5 minutes. If the problem occurs again after restarting, please contact customer service. Before reconnecting the power, wait 3 to 5 minutes. - Page 10 SHELVES 、 、 、 ILWS18BV ILWD36BV ILWD37BV ILBC142BV To prevent damaging the doors or gasket seals, open the doors wide when removing the shelves. When removing any of these shelves out of the rail compartment, you must lift (from the rear) and pull it towards you. To re-install, ensure the shelf is resting securely on the support brackets and push shelf inward until it locks into place.
- Page 11 Pull-out Roller Shelves To prevent damaging the door gasket, make sure to have the door all the way opened when pulling shelves out of the rail compartment. For easy access to the bottles, you must pull the shelves approximately 1/3 out of the rail compartment.
- Page 12 Installation specifications for built-in purposes ILWS18BV ILWD36BV ILBC142BV、 ILWD37BV...
- Page 13 、 ILWD154BV ILWDD154BV In order to guarantee the stability of the model ILWD36X, install and screw the fastening bracket correctly onto the kitchen furniture: Cabinet Leg To ensure correct function it is important that the cabinet is level. The cabinet is supplied with legs, Which can be adjusted by pliers or professional installer.
-
Page 14: Care And Maintenance
4. CARE AND MAINTENANCE CLEANING YOUR WINE CELLAR • Turn off the power, unplug the appliance, and remove all items including shelves and rack. • Wash the inside surfaces with warm water and baking soda solution. The solution should be about 2 tablespoons of baking soda with a quart of water. -
Page 15: Troubleshooting Guide
1. Troubleshooting guide You can solve many common appliance problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. Problem Possible cause Appliance does not operate. Not plugged in. - Page 16 Warranty Registration Card and return it to us (d) use or operation after a defect has occurred or so that we have a record of the ILVE products you been discovered; purchased. Alternatively you can register on line (see...
- Page 17 Last Name: First Name: Address: State: Postcode: Email: Home Phone: Mobile: Purchase Date: (Please attach proof of purchase to validate warranty) SERIAL NUMBER MODEL NUMBER (if you cannot locate the serial number please call ILVE on 1300 85 64 11)
