INSTRUCTION MANUAL
WINE/BEVERAGE CELLAR SEAMLESS FRAME
WINE COOLER model:
BEVERAGE COOLER model:
To ensure proper use of this appliance and your safety, please read the following
instructions completely before operating this appliance.
ILWS18X
ILWD36X
ILWD37XL
ILWD37XR
ILWDD154XL
ILWDD154XR
ILWD154XL
ILWD154XR
ILBC142XL
ILBC142XR
ILBC142BVL
ILBC142BVR
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ILVE ILWS18X
Summary of Contents for ILVE ILWS18X
- Page 1 INSTRUCTION MANUAL WINE/BEVERAGE CELLAR SEAMLESS FRAME WINE COOLER model: ILWS18X ILWD36X ILWD37XL ILWD37XR ILWDD154XL ILWDD154XR ILWD154XL ILWD154XR BEVERAGE COOLER model: ILBC142XL ILBC142XR ILBC142BVL ILBC142BVR To ensure proper use of this appliance and your safety, please read the following instructions completely before operating this appliance.
-
Page 2: Important Safety Instructions
1. IMPORTANT SAFETY INSTRUCTIONS WARNING Before the appliance is used, it must be properly positioned and installed as described in this manual. So read the manual carefully. To reduce the risk of fire, electric shock or injury when using the appliance, follow basic precautions. - Page 3 When disposing of your appliance, please choose an authorized disposal site. This appliance is equipped with a power cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded Do not under any circumstances cut or remove the third (ground) prong from the power cord.
-
Page 4: Installation Instructions
2. INSTALLATION INSTRUCTIONS ATTENTION If the appliance is transported in a horizontal position, the oil from the compressor may leak into the cooling circuit. For this reason, allow the appliance to rest in a vertical position for 12 hours before turning it on, so that the oil flows back into the compressor. -
Page 5: Operating Your Appliance
Regular maintenance is performed according to the instructions in this user’s manual. The ventilation openings on the appliance must not be covered. Correct installation (e.g. leveling, the capacity of the system corresponds to the specifications on the rating label of the appliance). COMMANDS ILWS18X ILWD36X ILBC142XL ILBC142XR 、 ILBC142BVL ILBC142BVR 、... -
Page 6: Wine Storage
“ ” button Energy conservation button: Pressing this button for 3 seconds will turn the energy conservation mode ON or OFF. In this mode, the LED light and display will turn off, and the °C/°F light will be on. “ “... - Page 7 TO SET THE TEMPERATURE: Use the buttons to set the desired temperature. Each time the buttons are pressed, the temperature will increase / decrease by 1°F (or 1°C). When you press the button once, the temperature will increase or decrease by 1°F (or 1°C). If you try to go beyond the minimum/maximum value that can be established, the display will jump to the lowest/highest adjustable temperature value automatically.
-
Page 8: Selector Buttons
If you turn on the appliance for the first time or after a restart, or after it has been out of operation for a long time, there may be a temperature difference between the temperature inside the appliance and that on the LED display. This is a normal event caused by the duration of the activation period. - Page 9 SHELVES ILWD36X ILWS18X ILBC142XL ILBC142XR ILBC142BVL ILBC142BVR 、 、 、 、 、 ILWD37XL ILWD37XR 、 To prevent damaging the doors or gasket seals, open the doors wide when removing the shelves. When removing any of these shelves out of the rail compartment, you must lift (from the rear) and pull it towards you.
- Page 10 Pull-out Roller Shelves To prevent damaging the door gasket, make sure to have the door all the way opened when pulling shelves out of the rail compartment. For easy access to the bottles, you must pull the shelves approximately 1/3 out of the rail ...
- Page 11 Installation specifications for built-in purposes ILWS18X ILWD36X...
- Page 12 ILBC142XL ILBC142XR ILBC142BVL ILBC142BVR ILWD37XL ILWD37XR 、 、 、 、 、 ILWDD154XL ILWDD154XR ILWD154XL ILWD154XR 、 、 、 Cabinet Leg To ensure correct function it is important that the cabinet is level. The cabinet is supplied with legs, Which can be adjusted by pliers or professional installer. See fig.1.1.
-
Page 13: Care And Maintenance
4. CARE AND MAINTENANCE CLEANING YOUR WINE CELLAR Turn off the power, unplug the appliance, and remove all items including shelves and rack. Wash the inside surfaces with warm water and baking soda solution. The solution should be about 2 tablespoons of baking soda with a quart of water. Wash the shelves with a mild detergent solution. -
Page 14: Troubleshooting Guide
1. Troubleshooting guide You can solve many common appliance problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. Problem Possible cause Not plugged in. Appliance does not operate. - Page 15 Post: Locked Bag 3000, Annandale, N.S.W 2038 deterioration of parts and accessories and glass P: 1300 MY ILVE (694 583) breakage); (b) use for purpose for which the ILVE product was not WARRANTY REGISTRATION sold or designed; Your ongoing satisfaction with your ILVE product is (c) use or installation which is not in accordance with any specified instructions for use or installation;...
-
Page 16: Warranty Registration Card
Last Name: First Name: Address: State: Postcode: Email: Home Phone: Mobile: Purchase Date: (Please attach proof of purchase to validate warranty) SERIAL NUMBER MODEL NUMBER (if you cannot locate the serial number please call ILVE on 1300 85 64 11)
