Summary of Contents for Philips Momentum 559M1
- Page 1 Momentum 559M1 www.philips.com/welcome User manual Customer care and warranty Troubleshooting & FAQs...
-
Page 2: Table Of Contents
Power .......... 24 7. Technical Specifications ..25 7.1 Resolution & Preset Modes ...28 8. Power Management ....30 9. Customer care and warranty .. 31 9.1 Philips’ Flat Panel Displays Pixel Defect Policy ....... 31 9.2 Customer Care & Warranty ..34... -
Page 3: Important
This electronic user’s guide is intended • Remove any object that could fall for anyone who uses the Philips display. into ventilation holes or prevent Take time to read this user manual proper cooling of the monitor’s before you use your display. - Page 4 1. Important tilt angle maximum is exceeded, the lighting, and surfaces that don’t monitor damage will not be covered reflect too much light. under warranty. • Seeing a doctor if your symp- • Do not knock or drop the monitor toms.
-
Page 5: Notational Descriptions
1. Important that falls within the following • For transportation information, temperature and humidity ranges. please refer to “Technical Specifications”. • Temperature: 0-40°C 32-104°F • Do not leave your monitor in a car/ • Humidity: 20-80% RH trunk under direct sun light. Important information for Burn-in/ Note Ghost image... -
Page 6: Disposal Of Product And Packing
From the planning, design and production stages, Philips emphasizes the important of making products that can easily be recycled. At Philips, end- of-life management primarily entails This marking on the product or on participation in national take-back... -
Page 7: Setting Up The Display
This product has been manufactured by and is sold under the responsibility of Top Victory Investments Ltd., and Top Victory Investments Ltd. is the warrantor in relation to this product. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used under license. - Page 8 ON at all times to be able to 9. USB downstream/USB fast charger use this function. 10. USB downstream Some select Philips displays may not 11. USB downstream/USB fast charger Power or Charge your device when it 12. USB downstream enters to “Sleep/Standby”...
- Page 9 2. Setting up the display This will then keep the USB power and The remote control is powered by two 1.5V AAA batteries. charging functions active even when the monitor is in sleep/standby mode. To install or replace batteries: 1. Press and then slide the cover to ...
-
Page 10: Operating The Display
2. Setting up the display 2.2 Operating the display Description of the control buttons Press to switch power on. Press more than 3 seconds to switch power off. Access the OSD menu. Confirm the OSD adjustment. Change the Sound Mode. Adjust the OSD menu. - Page 11 2. Setting up the display Description of the remote control Change the signal input buttons source. Adjust the OSD menu/ Turn up the values. Adjust the OSD menu / Return to previous OSD level. Confirm the OSD adjustment. Access the OSD menu. Confirm the OSD adjustment.
- Page 12 EasyLink (CEC) allow you to control On-Screen Display (OSD) is a feature in functions of multiple connected all Philips LCD displays. It allows an end devices with one remote control. Enjoy user to adjust screen performance or high quality picture and sound without select functions of the displays directly clutter or fuss.
- Page 13 2. Setting up the display The OSD Menu Note Xbox: Level up your gaming experience Below is an overall view of the structure while playing Xbox games, you can of the On-Screen Display. You can use even control the connected Xbox this as a reference when you want to console using the remote control.
- Page 14 2. Setting up the display Ideal setting position for optimal acoustic performance For optimal acoustic performance when table-mounting the monitor, please ensure the screen is not tilted and the speaker enclosure is facing front, parallel with the table.
-
Page 15: Remove The Base Assembly For
2. Setting up the display 3. Recover the hinge cover. 2.3 Remove the Base Assembly for VESA Mounting Before you start disassembling the display base, please follow the instructions below to avoid any possible damage or injury. 1. Place the display face down on a smooth surface. - Page 16 The display wall mounting should meet safety standards according to the display’s weight. Also read the safety precautions before positioning the display. Philips bears no responsibility for improper mounting or any mounting that results in accident or injury.
-
Page 17: Multiview
Why do I need it? 3. Toggle to the up or down to select With the ultra high resolution Philips [PBP Mode], then toggle to the right. MultiView display, you can experience 4. Toggle to the up or down to select... - Page 18 2. Setting up the display MultiView in OSD menu [PBP]: Picture by Picture Open up a sub-window side-by-side of another (main) signal source. When the sub source is not detected: (main) Note The black strip shows on the top and the bottom of the screen for the correct aspect ratio when in the PBP mode.
-
Page 19: Ambiglow
Whether you are playing games, 2. To switch Ambiglow off, or select or watching movies, Philips Ambiglow [Follow Video], [Follow Audio], offers you a unique and immersive [Color Shift], [Color Wave], [Color viewing experience. -
Page 20: Image Optimization
How does it work? • Xbox: Level up your gaming SmartImage is an exclusive, leading experience while playing Xbox edge Philips technology that analyzes games, you can even control the the content displayed on your screen. connected Xbox console using the Based on a scenario you select, remote control. - Page 21 Developed for wellbeing, shadows. Philips LowBlue Mode setting uses • HDR Movie: Ideal setting for a smart software technology to reduce harmful shortwave blue watching HDR movie. Deliver better contrast and brightness for more light.
-
Page 22: Smartcontrast
4. Image Optimization 4.2 SmartContrast What is it? Unique technology that dynamically analyzes displayed content and automatically optimizes a display's contrast ratio for maximum visual clarity and viewing enjoyment, stepping up backlighting for clearer, crisper and brighter images or dimming backlighting for clear display of images on dark backgrounds. -
Page 23: Hdr Settings In Windows 10 System
4. Image Optimization 4.3 HDR Settings in Windows 10 system Steps 1. Right click on the desktop, enter to display settings. 2. Select the display/monitor. STEP 5 3. Adjust resolution to 3840 x 2160. 4. Turn the “HDR and WCG” to on mode. -
Page 24: Adaptive Sync
4. Image Optimization 4.4 Adaptive Sync Adaptive Sync PC gaming has long been an imperfect experience because GPUs and monitors update at different rates. Sometimes a GPU can render many new pictures during a single update of the monitor, and the monitor will show pieces of each picture as a single image. -
Page 25: Sound By Bowers & Wilkins
• Monitor placement: Select ‘Stand’ Bowers & Wilkins or ‘Wall’ to have the best sound reproduction according to the The new Philips Momentum display setting. boasts sound by legendary audio experts Bowers & Wilkins. Its speaker system, created exclusively for Philips by Bowers &... -
Page 26: Power Delivery And Smart Power
6.Power Delivery and Smart Power 6. Power Delivery and Smart Power Smart Power is an exclusive Philips technology that provides flexible power delivery options. With Smart Power, you can still charge your device without sacrificing the screen brightness, even set your screen as VESA DisplayHDR 1000. -
Page 27: Technical Specifications
7. Technical Specifications 7. Technical Specifications Picture/Display Display Panel Type Backlight W-LED Panel Size 55" (139.7 cm) Pixel Pitch 0.315 (H) mm x 0.315 (V) mm Aspect Ratio 16:9 Contrast ratio (typ.) 4,000:1 3840x2160 @ 144Hz (HDMI/DP) Optimum Resolution 3840x2160 @ 120Hz (USB C) Viewing Angle 178°... - Page 28 7. Technical Specifications English, German, Spanish, Greek, French, Italian, Hungarian, Dutch, Portuguese, Brazil Portuguese, OSD Languages Polish, Russian, Swedish, Finnish, Turkish, Czech, Ukranian, Simplified Chinese, Traditional Chinese, Japanese, Korean Other Convenience VESA mount(200x200 mm), Kensington Lock Plug & Play Compatibility DDC/CI, sRGB, Windows 10/8.1/8/7, Mac OSX Power AC Input...
- Page 29 Finish Glossy and texture Note 1. This data is subject to change without notice. Go to www.philips.com/support to download the latest version of leaflet. 2. SmartUniformity and Delta E information sheets are included in the box. 3. The version of HDMI and DisplayPort comply with the Compliance Test...
-
Page 30: Resolution & Preset Modes
67.50 1920 x 1080 60.00 the maximum resolution and refresh 135.00 1920 x 1080 120.00 rate of this Philips display. 133.29 1920x2160 59.98 2. The default resolution through HDMI (PBP) is 3840 x 2160 @120Hz for optimal HDMI 2.1 console gameplay. If you 183.00... - Page 31 7. Technical Specifications 3. If you feel the texts in your display is a little fade away, you can adjust your fonts setting in your PC/ Notebook as following steps. Step 1: Control panel/All Control Panel Items/Fonts Step 2: Adjust Clear Type Text Step 3: Uncheck "Clear Type"...
-
Page 32: Power Management
8. Power Management 8. Power Management If you have VESA DPM compliance display card or software installed in your PC, the display can automatically reduce its power consumption when not in use. If an input from a keyboard, mouse or other input device is detected, the display will 'wake up' automatically. -
Page 33: Customer Care And Warranty
Pixel Defect Policy sub pixels together appear as a single white pixel. When all are dark, the three Philips strives to deliver the highest colored sub pixels together appear as a quality products. We use some single black pixel. Other combinations of... - Page 34 Three adjacent lit sub pixels (one white replacement due to pixel defects during pixel). the warranty period, a TFT display panel in a Philips flat panel display must have Note pixel or sub pixel defects exceeding the A red or blue bright dot must be tolerances listed in the following tables.
- Page 35 9. Customer care and warranty BRIGHT DOT DEFECTS ACCEPTABLE LEVEL 1 lit subpixel 2 adjacent lit subpixels 3 adjacent lit subpixels (one white pixel) Total bright dot defects of all types BLACK DOT DEFECTS ACCEPTABLE LEVEL 1 dark subpixel 10 or fewer 2 adjacent dark subpixels 2 or fewer 3 adjacent dark subpixels...
-
Page 36: Customer Care & Warranty
Please contact our Philips Customer Service Representative or local contact center (by Consumer care number) for more details. Philips Customer Care Center number listed below. -
Page 37: Troubleshooting & Faqs
• Disconnect the display from mains No Picture (Power LED not lit) power source immediately for safety • Make sure the power cord is plugged • Contact with Philips customer service into the power outlet and into the representative immediately. back of the display. - Page 38 10. Troubleshooting & FAQs • Adjust the image using the “Auto” Green, red, blue, dark, and white dots function in OSD Main Controls. appears on the screen • Eliminate the vertical bars using the • The remaining dots are normal Phase/Clock of Setup in OSD Main characteristic of the liquid crystal Controls.
-
Page 39: General Faqs
• Shut down your computer, How should I clean the LCD disconnect your old display and surface? reconnect your Philips LCD display. Ans.: For normal cleaning, use a clean, • Turn on your display and then turn soft cloth. For extensive cleaning, on your PC. - Page 40 “burn-in” or “after- any PC, workstation or Mac? imaging” or “ghost image” symptoms that will not disappear and cannot be Ans.: Yes. All Philips LCD displays are repaired. The damage mentioned above fully compatible with standard is not covered under your warranty.
-
Page 41: Multiview Faqs
Q14: which then will become the Information manual mentioned “default” mode. in EDFU? Ans.: Important Information manual Why the sub-windows flickers can be download on the Philips when I enable PBP. website support page. Ans: It’s because the sub-windows video source is interlace timing (i-timing), please change sub- window signal source to be... - Page 42 This product has been manufactured by and is sold under the responsibility of Top Victory Investments Ltd., and Top Victory Investments Ltd. is the warrantor in relation to this product. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used under license.
