Summary of Contents for AIR GUARD AG-1000
- Page 1 AG-1000 Antibacterial Vaporizer USER MANUAL - ENGLISH...
-
Page 2: Safety Information
Never add flammable liquid of any kind to the machine. Make sure there are no flammable materials close to the machine while operating. Only use Air Guard Antibacterial Solution. Other solution may lead to heater clog and malfunction. If the machine fails to work, unplug the machine and stop operation immediately. Contact your local dealer for advise . -
Page 3: Unpacking And Inspection
Air Guard Antibacterial Solution may present health risks if swallowed. Do not drink Air Guard solution. Store it securely. In case of eye contact or if solution is swallowed immediately look for medical advice. Unpacking and Inspection Immediately upon receiving the antibacterial vaporizer, carefully unpack the carton, check the content to ensure that all parts are present and have been received in good condition. -
Page 4: Product Overview
Step 1: Place the machine on a flat surface and in a suitably large area with at least 50 cm of open space around the machine. Step 2: Fill the fluid tank with Air Guard fluid. Step 3: Connect the machine to a suitably rated power supply.To determine the power requirement for the machine refer to the label on the back of the machine. -
Page 5: Operation
Step 6: To turn off the machine, hold the STOP button for 3 seconds; the machine will automatically run a self-cleaning process and shut off after the process is done. Operation Control Panel Operation The machine can be operated with the onboard digital control interface. AG-1000 Ready to Fog Button Function [MENU]... - Page 6 Volume Output Set output volume at Volume mode from 1 to 100 % XXX % Fan Speed Set fan speed from 20 to 100% XXX % DMX-512 Set DMX/W-DMX address from 1 to 511 Address: XXX Wireless Turn On/Off Wireless Remote Control function Air Pump Sensor Turn On/Off Air Pump Sensor DMX Mode...
- Page 7 DMX Connector Pin Assignment The machine provides a 3- or 5-pin XLR connector for DMX connection. The diagram below indicates pin assignment information. Function Ground Data- Data+ DMX Operation Making the DMX Connection – Connect the machine to a DMX controller or to one of the machines in the DMX chain.
- Page 8 Operation Wireless remote control system W-1 consists of a transmitter equipped with two buttons to activate, deactivate and an onboard receiver attached to the rear panel of AG-1000. W-1 Wireless Transmitter Press [A] button to emit fog and press [B] button to stop.
- Page 9 Wireless Receiver Transmitter setting By default [A] button is set to activate and deactivate. To change activation button, simply press desire button within 15 seconds after power is turn on. Registering a transmitter Transmitter can be paired from the receiver. Each receiver can pair up to 5 transmitters. Follow below steps to pair transmitter from receiver.
-
Page 10: Service And Maintenance
Replace with the same type and specification of battery which is 27A 12V Fluid Use Air Guard Antibacterial Solution for AG-1000. The machine is tested and calibrated with these authorized fluids to achieve the best performance. Warranty will be void, if any other type of liquid is used. -
Page 11: Technical Specifications
-Warm-up time 4.5 minutes (approx) -Fluid consumption 8.5 ml/min -Fluid tank capacity 2.4 Liters (0.63 gallon) -Compatible fluid Air Guard Antibacterial Solution -Operating time 9.5 hrs at max. output -Ambient temp.range 0°C - 40°C (32°F - 104°F) -Control Manual, DMX512, Timer... - Page 12 M22 Moisture Co., Ltd. Tel : +886 3 2227470 Fax : +886 3 2227469 www.airguard.com.tw e-mail : sales@airguard.com.tw C08AG1000...
