BODY COMPOSITION ANALYZER
Instruction Manual
<Usage Conditions>
: 41˚F to 95˚F/5˚C to 35˚C
Temperature Range
: 30% to 80% (non-condensing)
Relative Humidity Range
: 6,500ft ASL (2,000m ASL)
Max Altitude
Atomospheric Pressure Range : 86kPa to 106kPa
Please read this Instruction Manual carefully and keep it for future reference.
DC-13CU
<Storage Conditions>
Temperature Range
Relative Humidity Range
Atmospheric Pressure Range : 70kPa to 106kPa
To avoid malfunctions, avoid storing the equipment in a place with direct sunlight,
significant temperature changes, a risk of dampness, a large amount of dust or a
risk of vibration or impact, or in the vicinity of flames.
: 14˚F to 140˚F/-10˚C to 60˚C
: 10% to 90% (non-condensing)
