7. OPERATING MODES

AUTO mode (SmArT)
The auto mode is turned on and off with the use of the button "MODE" on
the remote control board.
1. While working in the AUTO mode, a microprocessor will automatically
select COOL, FAN, HEAT or DRY modes based on the difference between
actual and preset air temperature indoors.
2. If the AUTO mode does not provide comfort conditions, select the mode
manually. In automatic mode, depending on air temperature in the room,
the conditioner will select needed temperature parameters of its operation
in the following order:
Temperature indoors Automatic mode sele ction
if <20° С then HEAT mode shall be turned on
if <20° С - 26° С then DRY mode shall be turned on
if <26° С then COOL mode shall be turned on
ASmart mode allows changing threshold of switching from mode to mode.
During operation in Smart mode you see «-» on the display. Press keys
Temp +/-. «-» will change by +(-) 2. The range shift of this threshold
ASmart mode allows changing threshold of switching from mode to mode.
During operation in Smart mode you see «-» on the display. Press keys
Temp +/-. «-» will change by +(-) 2. The range shift of this threshold is within
-2...+2 of default temperatures.
COOL, HEAT and FAN
1. Turn the conditioner on pressing the «ON/OFF» button.
2. Pressing the «MODE» button, select COOL, HEAT or FAN mode
manually.
3. Pressing the «TEMP» button (up-down), set the desired air temperature
indoors (except for FAN mode).
4.Pressing the «FAN SPEED» button on the remote control board, select
the fan rotation speed: AUTO, LOW, MIDDLE, HIGH, and the conditioner
will start working in accordance with the selected setting. In the Smart
mode fan speed automatically selected.
8
www.timberk.com • Electric air conditioner
5.To turn the conditioner off, press the «ON/OFF» button once again.
In the FAN mode air temperature indoors is not set.
DRY
Turn the conditioner on pressing the «ON/OFF» button. Pressing the
«MODE» button, select the DRY mode. The conditioner will start working
in the set mode. To turn the conditioner off, press the «ON/OFF» button
once again.
Automatically maintained temperature
«SUPer» mode (TUrbO)
23° С
When pressing the «TURBO» button on the remote control board, the
conditioner will start working in turbo mode – for maximum cooling (in cool
18° С
mode) or for maximum heating (in heat mode).
23° С
TImer mode
Procedure of timing:
– If the conditioner is off, then press the "TIMER" button to activate the
automatic turning on. Pressing this button once again, set the time for
turning the conditioner on in the set time interval. To cancel the timer mode,
press the "TIMER" button once again.
–If the conditioner is working, then press the "TIMER" button to activate
the automatic turning off. Pressing this button once again, set the time for
turning the conditioner off in the set time interval. To cancel the timer mode,
press the "TIMER" button once again.
«SLeeP» mode
Button «SLEEP» (Night Care). Using this button, you may turn the sleep
mode on and off. In this mode, if working for cooling, the conditioner will
increase temperature by 1 °С an hour from the specified one within two
hours. If working for heating, the conditioner will decrease temperature by
1 °С an hour from the specified one within two hours. After 10 hours of
operation the conditioner will turn off automatically.
NOTE:
If there is a difference between set and actual air
temperature in DRY mode, the conditioner will
automatically turn on in COOL or FAN modes.
