Connecting the Telephone and Modem Cables
1.
Unplug your telephone cable from the wall jack and plug it into the telephone jack located on the back panel of
your computer.
2.
Plug the modem cable (supplied) into the modem line jack, located on the back panel of your computer
3.
Plug the other end of the cable into the wall jack.
To connect the telephone and m odem cables (PCV- RZ series m odel)
Your computer has a protective sticker
Connect only 10BASE-T and 100BASE-TX cables to the Ethernet port. Using other cables or a telephone cable
may result in an electric current overload that can cause a malfunction, excessive heat, or fire in the Ethernet
port. For help on connecting to a network, see your network administrator.
covering the Ethernet port located on the rear panel.
Page 27
