Summary of Contents for Vibe LiteAir Optisound Auto 8
- Page 1 LITEAIRAUTO8-V1 LITEAIRAUTO8A-V1...
- Page 2 Please ensure that when installing this product the heatsink will not contact with any materials that mat be damaged by heat such as upholstery or plastics.
- Page 3 LITEAIRAUTO8A-V1 Connect to +12V of battery with REM GND attached 20 amp fuse Connect to chassis ground of +12V vehicle Connect to chassis ground of vehicle Connect to speaker output of headunit R + white R - white / black L + grey L - grey / black Connect to RCA (low level) output of headunit...
- Page 4 LITEAIRAUTO8-V1 Connect to Speaker output of amplifier NOTE: VIBE recomends the LiteAir Bass 1 amplifier as the perfect partner for the LITEAIRAUTO8-V1...
-
Page 5: Side Panel
The LiteAir Auto 8 subwoofer enclosure can be mounted in many different locations in the vehicle due to it’s shallow profile. Below are a few examples of different mounting applications that are possible with the LiteAir Auto 8 subwoofer enclosures. Rear of seat Under seat Side panel... - Page 6 Note: Be sure to investigate your mounting area thoroughly for electrical wires, brake or fuel lines or fuel tank to prevent causing any damage. If you are unsure VIBE recommend that the enclosure is installed by an authorised VIBE dealer.
- Page 7 Terminals & controls LITEAIRAUTO8-V1 LITEAIRAUTO8A-V1 Speaker terminal Connect to the speaker output of the amplifier...
- Page 8 900 watts RMS Power: 300 watts Height: 80mm (excl grill) Width: 285mm Depth: 397mm Impedance: 4 Ohms LiteAir Optisound Auto 8 active Part Number: LITEAIRAUTO8-V1 Peak Power: 900 watts RMS Power: 300 watts Height: 80mm (excl grill) Width: 285mm Depth:...
- Page 9 20 amp fuse...
