Coast Spas EcoClean Installation & Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
13-DEC-2010
2010-5304
(EcoClean Cell Label ENGLISH Oct 2008)
EcoClean Cell
This is a replacement cell for the chlorine generating devices Coast Spas, EcoClean unit
REGISTRATION NUMBER 27899.02, PEST CONTROL PRODUCTS ACT. This cell must only be used
on this model of chlorine generating device.
Read the Label and the Installation and Operation Manual of the chlorine generating device Coast Spas,
EcoClean unit before using.
Coast Spas Manufacturing Inc. 6315 - 202 Street
Langley, BC • V2Y 1N1
PHONE: (604) 514-8111

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EcoClean and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Coast Spas EcoClean

Summary of Contents for Coast Spas EcoClean

  • Page 1 REGISTRATION NUMBER 27899.02, PEST CONTROL PRODUCTS ACT. This cell must only be used on this model of chlorine generating device. Read the Label and the Installation and Operation Manual of the chlorine generating device Coast Spas, EcoClean unit before using.
  • Page 2 USING. KEEP OUT OF REACH OF CHILDREN. Warning: Operating the EcoClean without water flow through the cell can cause a build up of flammable gases which can result in FIRE or EXPLOSION. Tel: (604) 514-8111 (EcoClean PCP Sticker English Oct 2008)
  • Page 3 REGISTRATION NUMBER 27899.02 PEST CONTROL PRODUCTS ACT Maximum output equivalent to 15 grams of free available chlorine per day. One EcoClean unit can treat a maximum of 1500 Litres of spa water. Controls Bacteria in Spa Water. PLEASE RETAIN OWNER'S MANUAL FOR FUTURE REFERENCE...

  • Page 4: Table Of Contents

    Spa Water Preparation & Monitoring Section 2 Installation Requirements Power Supply & Cell Installation 7, 8 Equipment Dimensions Section 3 Start Up & Operation Power Supply Functions 10, 11 Start Up Sequence Section 4 Trouble Shooting Trouble Shooting the EcoClean Appendix Service Information...

  • Page 5: Important Safety Instructions I,Ii

    1. Follow all aspects of the local and National Electrical Codes when installing the EcoClean unit. 2. During installation, mount the EcoClean unit to ensure the least amount of direct exposure to rain, garden sprinkler water, direct sunlight or any corrosive environment.
  • Page 6 GFCI. 2. The GFCI must be tested before each use. With the EcoClean unit operating push the test button on the GFCI. The EcoClean unit should stop operating. Push the reset button. The EcoClean unit should now start to operate normally.

  • Page 7: Health, General & Hyperthermia

    Health, General & Hyperthermia General: WARNINGS - To reduce the risk of injury: 1. People using medications and/or having an adverse medical history should consult a physician before using a spa or hot tub. 2. People with infectious diseases should not use a spa or hot tub. 3.

  • Page 8: Specifications

    24 hours @max. dial setting of 100% NOTE: The EcoClean unit is designed to provide a chlorine/bromine residual whenever the spa IS NOT in use. With an average residential spa, this “non-use” time represents 95% to 99% of each day.

  • Page 9: System Sizing

    Average Length (Ft) x Average Width (Ft) x Average Depth (Ft) x 7.5 = Total U.S. Gal. IMPORTANT CONCEPTS COAST SPAS EcoClean Production Capacity 1 . Sanitizer Demand The rate at which sanitizer is consumed in any spa depends on the relationship of eight major variables.
  • Page 10 "rules of thumb" will assist you in properly selecting the correct EcoClean feed rate dial setting. 1. An EcoClean power supply with cell , operated at maximum output (100%), at 3000 ppm salt residual will produce 15 grams of free available chlorine in 24 hours of continuous operation.

  • Page 11: Spa Water Preparation & Monitoring

    Also test your make up water for its level of salt and compare it with the charts on the next page. Before adding salt to a spa/hot tub for the first time, turn your EcoClean unit OFF, then pour salt around the perimeter of the spa.
  • Page 12 Section 1 b Salt Requirements Needed for 3000 PPM KILOGRAMS OF SALT NEEDED POUNDS OF SALT NEEDED FOR 3000 PPM RESIDUAL FOR 3000 PPM RESIDUAL Tub Volume in Salt Level Tub Volume in Litres Salt Level U.S. Gallons Before 1125 1500 Before Addition...

  • Page 13: Power Supply & Cell Installation

    The Power Supply is equipped with a 1.5m (5 ft.) DC cell cord. The unit comes complete with one of two cell types. For existing spas, the EcoClean unit will be provided with the cell attached, for simple over the wall installation. The cell should be placed into the footwell of the spa.
  • Page 14 Section 2 a Power Supply and Cell Installation (Continued) Diagram 2 Model C1-IW Cell SPADE CONNECTORS TO DC CABLE CELL BLADES WALL UNIT WITH “IN WALL” FACTORY INSTALLED CELL.

  • Page 15: Equipment Dimensions

    Section 2 b Dimensions – Power Supply and Cell AC PLUG – ALWAYS PLUG INTO GFCI RECEPTACLE FEED RATE DIAL 0 – 100% CELL BLADES BODY COVER POWER SUPPLY END CAPS L.E.D. INDICATOR DC CELL CABLE...
  • Page 16 The light will flash GREEN slowly (1 flash per second) for approximately 5 seconds while the EcoClean unit self-tests. If your EcoClean unit is operating properly, this indicator will display solid GREEN. This indicates AC power is being delivered to the Power Supply and/or the unit is producing sanitizer and your spa is being sanitized by Hypochlorous Acid (chlorine) or Hypobromous Acid (bromine).

  • Page 17: Start Up Sequence

    Where Cyanuric acid is not available or where its use is restricted, bromine can be used as an alternative sanitizer to chlorine. The EcoClean unit will convert sodium bromide to bromine in the same way that it converts sodium chloride to chlorine.

  • Page 18: Section 4 Trouble Shooting

    (Refer to the Spa Water Preparation section, page 5.) 6. No solid green “OK” light. Incoming 110VAC power is not present. Ensure that the EcoClean’S circuit breaker is set to "ON" and functional. 7. Rapid Green Flash – (Two flashes per second) A.

  • Page 19: Service Information

    To obtain service for your EcoClean system, contact the Dealer/Service Centre listed below, or: Coast Spas Manufacturing Inc. 6315 - 202 Street Langley, BC • V2Y 1N1 PHONE: (604) 514-8111 If warranty service is being requested, you must provide a copy of your registered warranty card as proof of purchase.
  • Page 20 ****************************** This label transcript service is offered by the Pest Management Regulatory Agency to provide efficient searching for label information. This service and this information do not replace the official hard-copy label. The PMRA does not provide any guarantee or assurance that the information obtained through this service is accurate, current or correct, and is therefore not liable for any loss resulting, directly or indirectly, from reliance upon this service.
