    GETTING STARTED GUIDE PXIe-5163 PXIe, 200 MHz, 1 GS/s, 14-bit PXI Oscilloscope Note Before you begin, install and configure your chassis and controller. This document explains how to install, configure, and test the PXIe-5163. The PXIe-5163 is a 200 MHz, 1 GS/s oscilloscope. Documentation for the PXIe-5163 is available from the Start menu by navigating to NI-SCOPE Documentation in the National Instruments folder.
  • Page 3: Verifying The System Requirements

    Verifying the System Requirements To use the NI-SCOPE instrument driver, your system must meet certain requirements. Refer to the product readme, which is available on the driver software media or online at ni.com/manuals, for more information about minimum system requirements, recommended system, and supported application development environments (ADEs).
  • Page 4: Other Equipment

    Other Equipment There are several required items not included in your device kit that you need to operate the PXIe-5163. Your application may require additional items not included in your kit to install or operate your device. Required Items • A PXI Express chassis and chassis documentation •...
  • Page 5: Preparing The Environment

    Table 1. Probe Options for the PXIe-5163 (Continued) Model NI Part Number Description CC5002X 786848-01 500 A RMS, 2 MHz current probe CC15010X 786849-01 150 A RMS, 10 MHz current probe CC3050X 785561-01 30 A RMS, 50 MHz current probe CC30100X 785562-01 30 A RMS, 100 MHz current probe...
  • Page 6: Installing The Pxie-5163

    When the installer completes, select Restart in the dialog box that prompts you to restart, shut down, or restart later. Installing the PXIe-5163 Notice To prevent damage to the PXIe-5163 caused by ESD or contamination, handle the module using the edges or the metal bracket. Ensure the AC power source is connected to the chassis before installing the module.
  • Page 7 Figure 3. Module Installation 1. Chassis 2. Hardware Module 3. Ejector Handle in Downward (Unlatched) Position Latch the module in place by pulling up on the ejector handle. 10. Secure the module front panel to the chassis using the front-panel mounting screws. Note Tightening the top and bottom mounting screws increases mechanical stability and also electrically connects the front panel to the chassis, which can...
  • Page 8: Pxie-5163 Front Panel And Pinout

    PXIe-5163 Front Panel and Pinout Front Panel PXIe-5163 200 MHz Oscilloscope ACCESS ACTIVE CH 0 MAX INPUT: 250 V RMS CAT II TO 50 Ω: 5 V Peak MAX 1 MΩ: 250 V Peak MAX CH 1 +5 V MAX PFI 0 AUX 0 PXIe-5163 Getting Started Guide | ©...
  • Page 9 Table 2. Connectors Signal Connector Type Description CH 0 and CH 1 BNC female Analog input connection; digitizes data and triggers acquisitions. CLK IN Imports an external reference clock or sample clock to the oscilloscope. PFI 0 PFI line for digital trigger input/output, probe compensation.
  • Page 10 AUX 0 Connector Pinout Table 5. AUX 0 Connector Pin Assignments Signal Signal Description Ground reference for signals CLK IN Used to import an external reference clock Ground reference for signals Ground reference for signals CLK OUT Used to export the reference clock Ground reference for signals Ground reference for signals AUX 0/PFI 0...
  • Page 11: Pxie-5163 Scb-19 Pinout

    Table 5. AUX 0 Connector Pin Assignments (Continued) Signal Signal Description AUX 0/PFI 4 Bidirectional PFI line AUX 0/PFI 5 Bidirectional PFI line AUX 0/PFI 6 Bidirectional PFI line AUX 0/PFI 7 Bidirectional PFI line +3.3 V +3.3 V power (200 mA maximum) Ground reference for signals PXIe-5163 SCB-19 Pinout You can use the SCB-19 connector block to connect digital signals to the AUX 0 connector on...
  • Page 12: Pxie-5163 Mini-Hdmi Breakout Cable To 6 Bnc Pinout

    Table 6. SCB-19 Signal Descriptions (Continued) Signal Signal Description No connection CLK OUT Used to export the reference clock PFI 4 Bidirectional PFI line PFI 5 Bidirectional PFI line PFI 6 Bidirectional PFI line PFI 7 Bidirectional PFI line +3.3 V +3.3 V power (200 mA maximum) 14 to 26 Ground reference for signals...
  • Page 13: Configuring The Pxie-5163 In Max

    Table 7. Mini-HDMI Breakout Cable to 6 BNC Signal Descriptions Signal Connector Type Description CLK IN Used to import an external reference clock CLK OUT Used to export the reference clock PFI 0 Bidirectional PFI line BNC female PFI 1 Bidirectional PFI line PFI 2 Bidirectional PFI line...
  • Page 14: Running Self-Calibration

    • Calibrates offset error of interleaving ADCs • Takes approximately 1 minute to complete Running Self-Calibration Running self-calibration enables the PXIe-5163 to yield full performance over its operating temperature range and two-year external calibration cycle. Before running self-calibration, warm up the PXIe-5163 for at least 15 minutes. Note Warm-up begins after the chassis and controller or PC is powered and NI-SCOPE is loaded and recognizes the PXIe-5163.
  • Page 15: Making A Measurement With Labview

    If the soft front panel is not already running, click Run/Stop. Add oscilloscope measurements to the channel by selecting Add/Remove in the measurement table of the oscilloscope. For more information on the measurements available for oscilloscopes in InstrumentStudio, refer to the InstrumentStudio Manual at ni.com/manuals. Making a Measurement with LabVIEW Launch LabVIEW.
  • Page 16 Depending on your connection method, connect the probe tip to the oscilloscope: • Oscilloscope Probe Compensator Connect the SMB end of the Oscilloscope Probe Compensator to the PFI connector of the oscilloscope that generates the probe compensation signal. Connect the ground clip of the probe to the ground terminal. Contact the tip of the probe to the square wave terminal.
  • Page 17: Programming The Pxie-5163

    Compensated Correctly Undercompensated Overcompensated Probe Adjustment Signal Probe Adjustment Signal Probe Adjustment Signal Proper Amplitude of a Reduced Amplitude of a Increased Amplitude of a 1 MHz Test Signal 1 MHz Test Signal 1 MHz Test Signal Once compensated, the probe conveys signals to the input channel accurately, without artificially attenuating or amplifying frequency components of the signal.
  • Page 18 Table 8. PXIe-5163 Programming Options Application Location Description InstrumentStudio When you install NI-SCOPE Note InstrumentStudio is on a 64-bit system, you can supported only on 64-bit monitor, control, and record systems. If you are using a measurements from supported 32-bit system, use your devices using driver's specific soft front InstrumentStudio.
  • Page 19: Ni-Scope Examples

    Table 8. PXIe-5163 Programming Options (Continued) Application Location Description NI-SCOPE LabVIEW—Available on the LabVIEW The NI-SCOPE API Instrument Driver Functions palette at Measurement I/O» configures and operates the NI-SCOPE. device hardware and provides customizable acquisition, C or LabWindows/CVI—Available at control, analysis, and Program Files»IVI Foundation»IVI»...
  • Page 20: Troubleshooting

    Application Development Locating Examples Environment (ADE) LabVIEW or Locate examples with the NI Example Finder. Within LabWindows/CVI LabVIEW or LabWindows/CVI, select Help»Find Examples, and navigate to Hardware Input and Output» Modular Instruments. Visual C/C++ or Visual Basic Locate examples in the file directory Users\Public \Public Documents\National Instruments\NI–...
  • Page 21: What Should I Do If The Pxie-5163 Fails The Self-Test

    If the module is still not listed, power off the system, ensure that all hardware is correctly installed, and restart the system. Navigate to the Device Manager. Operating System Description Windows 10/8.1 Right-click the Start button, and select Device Manager. Windows 7 Select Start»Control Panel»Device Manager.
  • Page 22: Where To Go Next

    Where To Go Next Located online at ni.com/manuals EXPLORE LEARN CREATE the application development about hardware features custom applications with environment (ADE) or review device an application programming for your application. specifications. interface (API). NI PXIe-5164 Getting Started with PXIe-5163 InstrumentStudio LabVIEW NI-SCOPE Instrument Driver...
  • Page 23 Information is subject to change without notice. Refer to the NI Trademarks and Logo Guidelines at ni.com/trademarks information on NI trademarks. Other product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering NI products/technology, refer to the appropriate location: Help»Patents in your software, the file on your media, or the National Instruments Patent Notice at .
