- Page 1 USB TYPE-C TOOL-FREE ENCLOSURE FOR M.2 PCIe NVMe AND SATA SSDs LINUX USB TYPE-C M.2 SSD WINDOWS MAC OS NVMe / SATA COMPATIBLE COMPATIBLE EC-SNVE quick installation guide...
-
Page 2: Package Contents
EC-SNVE quick installation guide FEATURES • Tool-free: quickly install and remove SSDs without any tools. • Aluminum case with ABS frame. • Compatible with sizes: 2230/2242/2260/2280. • Plug & Play. No additional drivers required. • Bus powered. Does not need an external power supply. -
Page 3: Ssd Installation
EC-SNVE quick installation guide SSD INSTALLATION STEP 1 Make sure to disconnect the cable before opening the enclosure. STEP 2 Push the button and lift the aluminum case as seen in the illustration above. - Page 4 EC-SNVE quick installation guide STEP 3 Do NOT force nor detach the aluminum case from the ABS frame, just rotate it until it is open. STEP 4 At a 20 degree angle, slide the SSD into the M.2 socket until it is properly seated.
-
Page 5: Connection Diagram
EC-SNVE quick installation guide ConnecTIon DIAGRAM • Connect the USB cable to both the device and the computer. LED Indicators Color Function Description Power LED Solid blue for power on. BLUE Activity LED Flashing blue LED for activity. - Page 6 Linux or an Apple computer on a Windows computer, it might not work. This has nothing to do with your Sabrent enclosure, it happens because the Windows operating systems is not capable of seeing the file-system that is used in Linux or Apple computers.
- Page 7 EC-SNVE quick installation guide USING A BRAND NEW HARD DISK If you are using a brand new HDD, you might have to initialize it before you can use it. NOTE: Only initialize a disk if you are absolutely sure it is a brand new disk and it does not have any of your data on it.
- Page 8 EC-SNVE quick installation guide TO INITIALIZE NEW DISKS 1. Open Disk Management with administrator permissions. To do so, in the search box on the taskbar, type Disk Management, select and hold (or right-click) Disk Management, then select Run as administrator > Yes. If you can't open it as an administrator, type Computer Management instead, and then go to Storage >...
- Page 9 EC-SNVE quick installation guide 4. Select and hold (or right-click) the unallocated space on the drive and then select New Simple Volume. 5. Select Next, specify the size of the volume (you'll likely want to stick with the default, which uses the whole drive), and then select Next.
- Page 12 EC-SNVE quick installation guide STEP 5 Lower the SSD and install the rubber fastener to secure the disk to the enclosure. STEP 6 Rotate the aluminum case back to its closed position until it clicks.
