VVDI–MB TOOL User Manual

Advertisement

Table of Contents
loading

Related Manuals for Xhorse XDMBC0EN VVDI MB BGA

Summary of Contents for Xhorse XDMBC0EN VVDI MB BGA

  • Page 1 VVDI–MB TOOL User Manual...

  • Page 2: Table Of Contents

    VVDI – MB TOOL User Manual Table of Contents Document Declaration ....................5 Overview ........................6 2.1. Noun explanation ....................6 2.2. VVDI – MB TOOL Hardware ................6 2.3. Mainly function ....................7 Options ........................12 3.1. Language ......................12 3.2.
  • Page 3 VVDI – MB TOOL User Manual 6.4. About query result status ................26 Prepare Key File ......................27 ESL Tools ........................28 8.1. Functions ......................28 8.2. ESL Basic Information ................... 29 8.3. ESL Key Information ..................30 Renew ECU/Gearbox ....................31 9.1.
  • Page 4 VVDI – MB TOOL User Manual 21.3. Latest Update Information ................48 21.4. History Update Information ................48 22. Case Description ......................49 22.1. W212 EIS, all key lost ..................49 22.2. W246 EIS with BGA (79) keys, add new key via OBD ........58 2021-06-01 Ver: 2.1...

  • Page 5: Document Declaration

    VVDI – MB TOOL User Manual 1. Document Declaration Please view the following declaration carefully:  VVDI – MB TOOL User Manual can help you maintenance vehicles with VVDI MB TOOL device. Please DON‟T used for illegal purpose, Please follow the national ...

  • Page 6: Overview

    VVDI – MB TOOL User Manual 2. Overview 2.1. Noun explanation  Mercedes Benz: A car brand come from German, we simply use MB, BENZ instead  EIS：Sometimes we call it EZS. The immobilizer system for MB cars  ESL: Sometimes we call it ESL ...

  • Page 7: Mainly Function

    VVDI – MB TOOL User Manual 9. VVDI-MB NEC Key Adaptor (not standard component, need buy extra) 10. Connector for W164, W209, W211 without gateway (not standard component, need buy extra) 11. VVDI-MB W204 ESL adaptor (not standard component, need buy extra) 12.
  • Page 8 VVDI – MB TOOL User Manual v03, v06, v08 (Keyless Go) v05, v07, v09 (Keyless Go) v59, v61 (Keyless Go)  EIS Tools Support read EIS data via OBD and IR adaptor Under OBD mode, we provide auto detect EIS type for CAN protocol and need to select EIS type manually for K protocol Support read W164, W209, W211 EIS via OBD without gateway support Support read old Motorola EIS (HC05, HC08, K-Line) password via IR directly...
  • Page 9 VVDI – MB TOOL User Manual Fast collector support type („FAST‟ after the option)： W172,W204, W207 W216 W164,W251 2009- W169,W209,W211 W202,W208,W210 W203,W463,W639 W639 ， 2009- W906 W221 W164,W251 W215,W220 W230 W230（with ESL） W169 Type2 Add keys support type: W164 W251 W164,W251 2009- W166, 197, 212, 218, 246 W169, 209, 211...
  • Page 10 VVDI – MB TOOL User Manual Support renew VVDI-MB W204 emulator  Renew ECU/Gearbox This function support renew, write VIN, personalization operation for module ECU, Gearbox, ISM etc.  KM Repair Support repair dashboard KM. Support the following type: C(W204), GLK(X204), CLK(W207), E(W212), SLS(W197), CLS(W218) R-Class(W251), GL(X164), ML(W164) E-Class(W211), CLS(W219) S-Class(W221), CL(216)
  • Page 11 VVDI – MB TOOL User Manual 14. GL (X164) 15. M-Class (W164) 16. R-Class (W251) 17. SMART 18. S-Class (W221) 19. CL (W216)  FBS4 Disable key This function is suitable for disabling the keys of W166, W205, W213, W218, W222 and W246 chassis Important note: The disabled key can only be enabled online through the original diagnostics tools...

  • Page 12: Options

    VVDI – MB TOOL User Manual 3. Options 3.1. Language Please manual set user language after first run program Support following languages:  Chinese (Simplified)  English  Polish  Spanish  German 3.2. User Manual Open user manual folder 3.3.

  • Page 13: Read Write Key

    VVDI – MB TOOL User Manual 4. Read Write Key Read Write Key support read key basic information, generate new working key, renew/write NEC key (Support Keyless Go). Read password of the BE key via IR directly, renew BE key, write new key file to the BE key. NEC adaptor support read the password of the v51, v57 version key.
  • Page 14 VVDI – MB TOOL User Manual Renew: This function can renew the BE key, the original car key needs NEC adapter to wipe empty. Key current HASH (Repair key): This function need to bring in the correct key password. It can read the last key track stored in key. With this data you can fix EIS errors. Read Blank BGA (0CF4) EIS data: Support read EIS data stored in blank BGA key.

  • Page 15: Nec Adaptor Mode

    VVDI – MB TOOL User Manual Activate 0CF4 Key: Support change blank BGA key status from 0CF4 to 04FC, you can‟t read EIS data after you have active the remote. 4.2. NEC Adaptor mode Renew/Write new key file via NEC adaptor Support versions: v51, v57 v28, v35, v40...
  • Page 16 VVDI – MB TOOL User Manual The way to connect the NEC adaptor with the chip: 2021-06-01 Ver: 2.1...
  • Page 17 VVDI – MB TOOL User Manual 2021-06-01 Ver: 2.1...

  • Page 18: Eis Tools

    VVDI – MB TOOL User Manual 5. EIS Tools EIS data is the data when the key is loaded. VVDI MB TOOL support two modes to read EIS data: read by OBD and IR adaptor This picture is read from W246 EIS 5.1.

  • Page 19: Functions

    VVDI – MB TOOL User Manual 5.2. Functions Mode: Support OBD and IR adaptor read EIS. You need to connect OBD line to the car in OBD mode or the EIS, IR mode only need IR adaptor. In addition, support no gateway mode to read W164, W209 and W211 EIS via OBD (need an extra adaptor which need to be purchased separately).
  • Page 20 VVDI – MB TOOL User Manual 11. Enable Key: This function can enable the key. 12. Personalize W204 ESL: This function can synchronize key information from EIS to W204 ESL, this function is used for change W204 ESL. Before run this function, make sure “EIS status: Personalized selected, Activated not selected”, “ESL status: Activated not selected”.

  • Page 21: Eis Basic Information

    VVDI – MB TOOL User Manual under OBD mode with chassis number select W172, 204, 207. 13. Test EIS status/Working key: This function can test EIS, ESL and working key status. Mech. status: Display the corresponding position of the key in the EIS. Can status: The module communication verification status on the platform right now, the key is screwed to the corresponding position to detect the communication verification on the car, the key is inserted into the EIS and the normal display is „ON‟;...

  • Page 22: Eis Key Information

    VVDI – MB TOOL User Manual 5.4. EIS Key Information Key Password: Key password is used for EIS to authenticate the working key. It is also the password you need when you want to generate a new key (IMPORTANT). Paste key password: You can paste your password to here directly. Erase Password: Renew activated EIS to un-activated status, make EIS allow write new data.

  • Page 23: Password Calculation

    VVDI – MB TOOL User Manual 6. Password Calculation 6.1. Overview Password calculation support working key mode and lost all key mode. Password calculation needs the points or token, for detailed rules, you can contact the technical support or the local dealer. Password calculation –adding key: can get key password through EIS and working key (online).

  • Page 24: Support Type

    VVDI – MB TOOL User Manual W215 all key lost data acquisition require about 2-3 hours. Lost all keys calculate time in server: 30 seconds – 1 minute. 6.2. Support type  Add key support type W164,W251 W164,W251 2009- W166, 197, 212, 218, 246 W169, 209, 211 W172, 204, 207, 212(old with ESL) W216...

  • Page 25: Functions

    VVDI – MB TOOL User Manual W212 (old with ESL) W172,W204, W207 W216 W164, W251 2009- W169,W209,W211 W202,W208,W210 W203,W463,W639 W639 2009- W906 W221 W164,W251 W215,W220 W230 W169 Type2 6.3. Functions Select this if lost all working key: This option must be selected when all keys are lost Mode: OBD and IR adaptor, mode use for communicate with EIS...

  • Page 26: About Query Result Status

    VVDI – MB TOOL User Manual 6.4. About query result status Query result support query calculation result in 24 hours, others don‟t support Query result will display Time, SSID, Status, Filename (name when upload to server) Status has the following types: Queuing: number x, require about y minutes, means your task need y minutes Processing: requires 1 minutes, means your task need 1 minute to finish Password: xxxxxxxxxxxxxxxx (Free), means success find password, “Free”...

  • Page 27: Prepare Key File

    VVDI – MB TOOL User Manual 7. Prepare Key File Prepare key file means prepare the key file which you will write to new key (online) Step 1: Load EIS file with password. The file can auto detected by VVDI-MB TOOL Support VVDI-MB type and old Motorola EEPROM dump file If the loaded EIS don‟t contain key password, paste your password with “Paste”...

  • Page 28: Esl Tools

    VVDI – MB TOOL User Manual 8. ESL Tools ESL Tools can read/write/renew ESL via OBD (K-Line). Adaptor also support 8.1. Functions Mode: Now only support OBD (K-Line). If ESL was on car, you need connect the K-Line(find from device OBD head) to ESL separately Chassis: ESL type Allow user: If select this option, allow input key track, password, VIN manually...

  • Page 29: Esl Basic Information

    VVDI – MB TOOL User Manual 13. Check ESL damage: Fix the locked ESL to be a normal one (NEC chip fatal error: 0xAA). This function need to buy an extra NEC ESL adaptor, support W204 ESL and old Motorola ESL. You need to select Adaptor option in ESL window. 14.

  • Page 30: Esl Key Information

    VVDI – MB TOOL User Manual TP Cleared: Selected means TP was cleared. You can‟t write data to ESL without TP cleared Personalized: Selected means already written car information, insert working key will activate ESL automatically Activated: Selected means this ESL already have working key. You can‟t write data to EIS with activated status 8.3.

  • Page 31: Renew Ecu/Gearbox

    VVDI – MB TOOL User Manual 9. Renew ECU/Gearbox This function support renew, write VIN, personalization operation for module ECU, Gearbox, ISM etc. 9.1. Functions Module: Support ECU, Gearbox, ISM etc. Read: Read key information, unit status and other diagnostic information. Require connect unit with CAN separately.

  • Page 32: Advanced Function

    VVDI – MB TOOL User Manual 9.2. Advanced Function Support Read/Write gearbox special EEPROM. Support set unit status while write data. That means you can renew gearbox without erase password Read: Read module special EEPROM. Save File…: Save the read EEPROM file. Load File…: Load the saved EEPROM file.

  • Page 33: Km Repair

    VVDI – MB TOOL User Manual 10. KM Repair This function support to repair the dashboard KM. (Menu -> Other Function -> Read and Write Dashboard) 10.1. Support Type C(W204), GLK(X204), CLK(W207), E(W212), SLS(W197), CLS(W218) R-Class(W251), GL(X164), ML(W164) E-Class(W211), CLS(W219) S-Class(W221), CL(216) W166, W172, W246, W231 W205...
  • Page 34 VVDI – MB TOOL User Manual dashboard. Doesn‟t support block KM synchronization between EZS and dashboard. You can install extra CAN filter yourself or erase EIS.  Warning: This function is only used for KM repair, please follow the local legislation.

  • Page 35: Read/Write Cgw(Zgw)

    VVDI – MB TOOL User Manual 11. Read/Write CGW(ZGW) This function supports backing up the EEPROM and FLASH data form gateway.(Menu -> Other Function -> Read and Write CGW (ZGW)) 11.1. Support Type Type 1: A-Class (W169), B-Class (W245), GL (X164), E-Class (W211), ML (W164), CLS (W219), SLK, SLR, SMART Type 2: C-Class (W204), CLK (W207), GLK (X204), E-Class (W212), SLS (W197), CLS (W218)

  • Page 36: Support Type

    VVDI – MB TOOL User Manual 11.2. Support Type 1. Read: The EEPROM type which are need to select manually in the read type; 29F400 FLASH 512K；29F800 FLASH 1M data file. 2. Write: Write the currently read or loaded EEPROM or FLASH file into the gateway (the FLASH file of type 2 gateway does not support writing ) 3.

  • Page 37: Old Motorola Key

    VVDI – MB TOOL User Manual 12. Old Motorola Key This function can read and write the old Motorola key which needs the NEC ESL adaptor(Menu-Other Function-Old Motorola Key) 12.1. Function introduction The chip on the old Motorola key needs to be soldered down and placed on the NEC ESL adapter for reading and writing operations.

  • Page 38: Custom Request

    VVDI – MB TOOL User Manual 13. Custom request Support use the CAN commands for control unit communication. (Menu-Other Function-Custom Request) 13.1. Function introduction Recommended for professional users 1. Connect: manually select the corresponding EIS type connection for operation 2. Activate EIS: support to active the EIS via OBD. 3.

  • Page 39: Obd Read Eeprom

    VVDI – MB TOOL User Manual 14. OBD read EEPROM This function is supported to read W202, W208, W210 and the CPU‟s EEPROM of the EIS via K-line. (Menu -> Other Function -> OBD read and write EEPROM) 14.1. Function introduction 1.

  • Page 40: Eeprom Data Processing Tool

    VVDI – MB TOOL User Manual 15. EEPROM data processing tool Supports repairing EEPROM data of W210/W220 geared computers (Menu -> Other Function -> EEPROM Data Processing Tool) 15.1. Function introduction This function can repair the ISM data and the problem that the computer cannot be put in gear.

  • Page 41: Set Key Frequency/Upgrade Smart Key

    VVDI – MB TOOL User Manual 16. Set key frequency/upgrade smart Support specific manufacturer keys to change the key frequency through IR Support the smart key of a specific manufacturer to be upgraded to the latest version of the server through IR (Menu ->...

  • Page 42: Fbs4 Disable Key

    VVDI – MB TOOL User Manual 17. FBS4 Disable key This function is suitable for disabling the keys of W166, W205, W213, W218, W222, W246 chassis (Menu -> Other Function -> FBS4 Disable Key) 17.1. Function introduction 1. Read key information: Read the current EIS SSID, EIS number, frame number, 8 sets of key tracks, the last key bit with the car key, and the penultimate key bit information with the car key 2.

  • Page 43: Point System

    VVDI – MB TOOL User Manual 18. Point system Use the VVDI BE key to earn extra points. Using the points can not only redeem the calculation points of the password, but also redeem functions and accessories. 18.1. Function introduction 1.

  • Page 44: Synchronize Device Time

    VVDI – MB TOOL User Manual 19. Synchronize device time Online synchronization, if the network is normal then the device will automatically synchronize, and the synchronization will fail when there is a problem with the network. After checking and replacing the network, you can manually click online synchronization. 2021-06-01 Ver: 2.1...

  • Page 45: Guide

    VVDI – MB TOOL User Manual 20. Guide This function will provide the complete operation process of some commonly used functions, such as changing the EIS head, changing the ESL, etc. (under development, please pay attention to subsequent versions) 2021-06-01 Ver: 2.1...

  • Page 46: Update Online

    VVDI – MB TOOL User Manual 21. Update Online 21.1. Update Firmware  Need to download the Upgrade Kit and connect the device to update with USB cable on the PC.  Update firmware steps: 1) Connect VVDI – MB TOOL to PC with USB cable 2) Open the Upgrade Kit to select the corresponding device option (VVDIMB), the latest firmware version is selected by default without having to manually select.
  • Page 47 VVDI – MB TOOL User Manual 5) Click Upgrade and wait for the upgrade to complete 6) If the software does not display the latest version number of the server or promptsa 2021-06-01 Ver: 2.1...

  • Page 48: Update Software

    VVDI – MB TOOL User Manual network error when upgrading, please check the network connection or change another network. 7) Wait for the upgrade to complete (about 10 minutes, need to connect to the Internet), do not turn off the computer or unplug the USB cable during the upgrade process.

  • Page 49: Case Description

    VVDI – MB TOOL User Manual history update information 22. Case Description 22.1. W212 EIS, all key lost 1. Connect the device to the car, enter the EIS interface and click to Read EIS data and the device will automatically diagnose the EIS model If W209 and W211 are displayed, the OBD can directly read the password without calculating the password This example is the method of W212 EIS and under the all keys are lost situation...
  • Page 50 VVDI – MB TOOL User Manual 3. Enter the Password Calculation, collect data to calculate the key password Check the „Select this if lost all working key‟ on the upper right corner, select IR in the mode, and then manually select the number diagnosed on the EIS page The bottom of the first step of the interface will prompt whether you need to operate on the platform after you select the chassis model, and if you are prompted to operate on the platform, you need to remove the EIS and the platform wiring to collect and calculate...
  • Page 51 VVDI – MB TOOL User Manual The collection is complete, save the collected data, it is recommended to use the default file name Click Upload Data to upload the saved collected data to the server for calculation 2021-06-01 Ver: 2.1...
  • Page 52 VVDI – MB TOOL User Manual Click Query result to query the server results, you can select Auto refresh, the software will automatically refresh the server results, it takes about 1 minute After the calculation is successful, the password is automatically displayed in the key password area, click Copy to copy the password to the clipboard 2021-06-01 Ver: 2.1...
  • Page 53 VVDI – MB TOOL User Manual 4. Save EIS data with password Enter the EIS Tools interface again Re-read the EIS data Use Paste to paste the password into the key password area Then click again the „save EIS data‟ button to save the EIS data with key code 5.
  • Page 54 VVDI – MB TOOL User Manual Click to load EIS (EIS) file to Load EIS file with key password The loaded file address is displayed below the software The software automatically determines that the loading type is HC05 format Display information such as SSID and key password in the file Select the location and format of the key to be generated, click toPrepare Key file (requires online) 2021-06-01...
  • Page 55 VVDI – MB TOOL User Manual After the server search is successful, select the location to save the key file. Click save directly 6. Enter the Read write key. Prepare a new key. We need to generate a BE key Put the new BE key into the IR antenna of the device, select IR as the communication method, and select the BE key as the type Click to Identification key...
  • Page 56 VVDI – MB TOOL User Manual Load key file, select the 7th key position Click the write option After writing, click on the Identification key, it is already in a state of preparation for activation 7. Insert the key into the EIS again, and the EIS starts to learn the key The red light on the key will light up once and then go out, indicating that the key learning is complete Read the EIS data again, you will find that the Key 7 position has been used and...
  • Page 57 VVDI – MB TOOL User Manual Read the BE key again, the key status has been used. 8. Completed. 2021-06-01 Ver: 2.1...

  • Page 58: W246 Eis With Bga (79) Keys, Add New Key Via Obd

    VVDI – MB TOOL User Manual 22.2. W246 EIS with BGA (79) keys, add new key via OBD Insert the original working key into the device IR reader, Press “Identification key” to check the working key version  If the key is BE version, you can read password via IR, no need to calculate the password ...
  • Page 59 VVDI – MB TOOL User Manual 2021-06-01 Ver: 2.1...
  • Page 60 VVDI – MB TOOL User Manual Enter Password Calculation, you can calculate key password in this option  Select OBD mode, chassis select W166, 197, 212, 218, 246  Press “Data Acquisition”, progress with following steps  Insert “working key” to “EIS” before press OK; only insert working key to EIS, don‟t switch ignition ON ...
  • Page 61 VVDI – MB TOOL User Manual  Data acquisition progress, just wait it to finish. The left time will show on the bottom  After 100%, Insert “working key” to “EIS” before press OK; only insert working key to EIS, don‟t switch ignition ON 2021-06-01 Ver: 2.1...
  • Page 62 VVDI – MB TOOL User Manual  Waiting 30 seconds  Insert “working key” to “Device IR Reader” before press OK; take off working key from EIS and insert to device IR Reader, then press OK  After save acquisition data you will get next window. Please keep the default 2021-06-01 Ver: 2.1...
  • Page 63 VVDI – MB TOOL User Manual file name when save acquisition data  Press Upload Data to upload saved acquisition data to the server 2021-06-01 Ver: 2.1...
  • Page 64 VVDI – MB TOOL User Manual  Press Query result to get result, you can select “Auto reflash”, it will query server result automatically, it need about 1 minute  After calculate success, key password will display at key password area automatically, press “Copy”...
  • Page 65 VVDI – MB TOOL User Manual Save EIS data with password  Enter EIS Toolsinterface again  Read EIS data  Use “Paste” paste the password to key password area  Then save EIS data again  Steps: 1->2->3 Enter Prepare Key File ...
  • Page 66 VVDI – MB TOOL User Manual  Select key position and format for key file, Press Prepare Key File (need to be online)  After server find success, select where you want to save the key file, press save directly Enter Read Write Key.
  • Page 67 VVDI – MB TOOL User Manual  Steps:1->2->3->4->5  Press Identification key again after you have wrote key file. You can see the key has beenactivated successfully 2021-06-01 Ver: 2.1...
  • Page 68 VVDI – MB TOOL User Manual Insert new key to EIS, the EIS will learn the new key  First the red light will turn ON , then turn OFF, it means the key learns success  Read EIS data once more, you can find key 4 was selected Completed.
