Assembled by
Installation date
Phone number elevator
Battery changed on date
Keep this manual on a save place, preferably in the logbook in the machineroom
The RUKRA GSM / PSTN interface replaces a standard PSTN landline and can be installed in
the engine room, the elevator shaft or on the roof of the cabin. Up to 5 RUKRA Elevator
Phones can be connected parallel to one RUKRA GSM / PSTN interface.
The RUKRA GSM / PSTN interface is simlock free and equipped with an internal battery.
Comes with magnetic antenna, internal battery and a power adapter with 230VAC power
cord with molded plug and is ready for immediate use without programming.
No programming required, you only need an active SIM-card with or without PIN. The SIM-
card can be protected against theft using PIN 1111, with this function the RUKRA GSM / PSTN
interface make itself a new unknown PIN code.
Read this manual carefully before you start the installation or programming
RUKRA EUROPE B.V.
:
:
:
:
WWW.RUKRA.EU
RUKRA GSM/PSTN INTERFACE_ENG_V1
ARTICLE
NUMBER: RK-1201
Engineer:
PIN
:
PUK:
Name :
INFO@RUKRA.EU
Advertisement
Table of Contents
Related Manuals for Rukra RK-1201
Summary of Contents for Rukra RK-1201
- Page 1 The RUKRA GSM / PSTN interface replaces a standard PSTN landline and can be installed in the engine room, the elevator shaft or on the roof of the cabin. Up to 5 RUKRA Elevator Phones can be connected parallel to one RUKRA GSM / PSTN interface.
- Page 2 Note: A 4 or 6 wire phone cord may cause interference and the yellow and green LEDs will blink. The RUKRA GSM / PSTN interface can be installed in the engine room, the lift shaft or on the roof of the elevator cabin.
- Page 3 PUK code. Insert the SIM card into the RUKRA GSM / PSTN interface (note the angled corner) and connect the power supply adapter and the battery backup power alternately and check the LEDs to go on both times. The blue LED turns on and the green and yellow LEDs will flash.
- Page 4 SMS messages is SMS mail. It is working under Outlook and you can work with SMS as with normal e mails. It works in batches and allows programm communication interval (1 to 99 minutes) to RUKRA GSM/PSTN interface for sending and receiving SMS. Due this we avoid situation that the RUKRA GSM/PSTN interface is permanentlky blocked by data mode for voice communication.
- Page 5 The SIM card requires PIN, which is not preprogrammed or is preprogrammed wrongly. The LED „communication to GSM„ is flash shortly one for 2 sec. After calling to RUKRA GSM/PSTN interface you are hearing busy tone. RUKRA GSM/PSTN interface is not log into GSM network – bad signal.
- Page 6 Network / linetest :The RUKRA GSM interface can send periodic ( 1 to 30 days) a SMS message to one phone- number with information about the battery, last number called, temperature and signal strength.
