Handle assembly for wall mount cabinet

Advertisement

Available languages

Available languages

H-4470, H-5697
HANDLE ASSEMBLY FOR
WALL MOUNT CABINET
1.
Insert handle (1) into door (2) and secure
with two Phillips head screws (3).
2. Slide keeper cam (4) onto handle shaft (5).
PAGE 1 OF 3
1-800-295-5510
uline.com
2
3
6
5
4
3
9

HANDLE ASSEMBLY INSTRUCTIONS

4
1
Assembled Front View
3. Check position of cam by rotating handle. Cam
should rotate behind side flange of cabinet.
4. Secure cam with lock screw (6).
Para Español, vea página 2.
Pour le français, consulter la page 3.
1
0421 IH-4470
