Race Result Chip2Go Quick Reference Manual

Quick Reference Guide
Chip2Go allows you to program RACE RESULT raw transponders ready to stick
directly to bibs.
Raw transponders are fed in to the Chip2Go from a roll, encoded to the required
number and fed out ready to easily remove and stick directly to a bib.
The unit features a chip check antenna on the front side to easily check a
transponder's code.
Number entry can be achieved through either:
•
Touchscreen keypad entry (with optional sequential count-up / count-down)
•
USB number pad
•
USB barcode scanner
The Chip2Go will only work with RACE RESULT raw transponders, these can be
purchased in either single or duo configuration. The machine will automatically
recognise these and will program either a single tags or two identical tags according
to the roll.

System Setup

Screw in the power cable to the rear of the unit and the Chip2Go will power on
automatically.
Chip2Go machines are shipped with a 15v power supply using the same connector
as Loop Boxes and Track Boxes. Note that a Loop Box power supply only provides
12v, the Chip2Go will still run but motor speed will be reduced.
To prepare transponders first raise the mounting arm by pulling the black quick
release latch and pulling the arm up until the latch clicks back in to lock the arm in
place, the roll then fits on the arm.
Push back the silver brake plate and feed the plastic liner through the upper section
of the unit until the first transponder is just visible below the red plate but ensure that
the transponder does not cover the white programming antenna. If the
programming antenna is already covered by a transponder then this
transponder will be fed past the antenna and cannot be used.
