Quick Start Guide Chip2Go

Step 1

Insert power cable at the

rear of the machine and

secure.

The Chip2Go will boot

automatically.

Step 2

A Pull back the black quick release latch and push the

arm up. Put roll on the arm. The Chip2Go recognizes

automatically whether it has to program single or duo

transponders based on the transponders being used.

B Push down the brake and thread liner through

machine as shown.

C Pull the liner through until the first transponder is just

visible but not covering the programming antenna.

D Push "Feed" and put liner through the upper slit as

shown on the picture, until the liner is grabbed and a

transponder is positioned on the programming antenna.

Stop here.

Transponder must not cover

the progamming antenna.

Need help?

Do you have a question about the Chip2Go and is the answer not in the manual?

Page 1 A Pull back the black quick release latch and push the arm up. Put roll on the arm. The Chip2Go recognizes automatically whether it has to program single or duo transponders based on the transponders being used.
Page 2 Step 3 Program transponder using one of these modes: 1. Count Down/Count Up 2. USB list file (see Knowledge Base) 3. External Barcode Scanner 4. External Keypad 5. Touchscreen Keypad 1. Count Up/Down: To return to the main menu Enter number with the on-screen keypad and press press the “Keypad Button“, ...
Page 3 “Manual Feed Reverse” to release the liner. Take off the power cable. Cut the liner here! Don´t cut it in front of the first transponder because you need the empty liner next time to setup the Chip2Go. Cleaning instructions can be found in our Knowledge Base.
