- Page 1 Optical Network Tester User Manual...
- Page 2 PREFACE Thank you very much for buying and using S2108 series optical network tester. This manual mainly contains the commonly used operating safety instructions, basic interface and operation introduction, as well as common troubleshooting guidelines and other information. In order to facilitate your use, before operating this instrument, please read the contents of this manual carefully and follow the instructions in the book correctly.
- Page 3 WIFI, 4G LTE SIM and GPS (on developing), and test data can be uploaded to the cloud wirelessly. PDF reports can be generated on the device and transmit them to the mobile terminal via WiFi & Bluetooth. S2108 series supports multi-tasks simultaneous operation, and VFL, OPM, LS functions can run in the background.
- Page 4 OTDR Interface,function introduction...
- Page 5 OTDR Interface,function introduction Mini USB connection：Connect the computer for data export, or connect the power bank to charge the device USB connection：Accessing USB flash disk to export data, used as a power bank function to charge other devices DC charging port：Charging voltage range 12V~19V...
- Page 6 OTDR Interface,function introduction Wifi Bluetooth Background function open status display Fiber-iot Charge indicator Time and date Battery power display GPS positioning USB connection 2020/06/26 20:04:14 2020/06/26 dB/dBm/mW OTDR iONM Laser Source Fault-Location Multi-Fiber Endface Laster-ranging RJ45 Tracker Camera Inspector Fiber Identification Remote-Help Fast Repair...
- Page 7 OTDR Interface,function introduction Multi task simultaneous operation Curve thumbnail Multi task area One button auto test Curve full screen File operation Event map Preview / wireless upload to cloud File save OPM VFL LS Support Chinese and English input One click save Convenient and quick Advanced setting High end setting function...
- Page 8 iONM Interface,function introduction Through multi wavelength and multi pulse width combination test technology, the accurate analysis of various events is realized. Graphic display type More intuitive and accurate Observe event information Pass/Fail Link-loss Link ORL List display Type Position length loss Reflect Attenuation...
- Page 9 Multi core measurement The purpose of multi-core measurement to help customers manage and maintain multi-core optical cable data, Through the establishment of the project, to help customers more intuitive Manage and maintain fiber optic data. From the core matrix, the state of all the cores can be seen intuitively, Including whether it has been tested, does the test pass.
- Page 10 Optical fiber end face detection Save and view the optical fiber end face image The core diameter of single-mode fiber is about 9um, It's thinner than human hair, If the end face is polluted, it will cause great connection loss, this leads to unstable communi- cation state.
-
Page 11: Laser Source
Laser Source Background prompt of Laser Sourceon state LS port location Mode switching CW/270/330/1k/2kHz Auto wave recognition Increase power On/Off Reduce power Home Power adjustable stable laser source Output CW/270Hz/330Hz/1kHz/2kHz mode Support automatic wavelength recognition function, wavelength ID mode， Combined with optical power meter module of series equipment for automatic wavelength identification... -
Page 12: Optical Power Meter
Optical power meter OPM data acquisition interface OPM port location Measurement information Support frequency identification function User calibration Support pass / fail threshold setting Data acquisition Support Tone Detect function, Automatic wavelength recognition namely frequency identification function... - Page 13 Visual fault location Background prompt of VFL state VFL port location VFL always bright VFL 1Hz twinkle VFL 2Hz twinkle Close VFL Home Fault location and identification for short distance optical fiber...
- Page 14 Laster ranging Laser ranging interface： Please do not look directly at the laser emission port to avoid damage Single measurement Continuous measurement Measurement information Home Length measurement for optical cable laying and broadband installation...
- Page 15 RJ45 tracker RJ45 Digital tracking port Close Digital/simulation switch Whole RJ45 tracker Line pair search Measurement information Home RJ45 digital radar tracking function can be used for digital line finding of network line, telephone line and other cables...
- Page 16 Camera Photograph Picture library Photo display area Home Take pictures of the test site and link them to the OTDR test data...
- Page 17 File brows Create directory Back to shortcut key Search File information Open file Copy file Cut file File type Cancel Delete Rename Select all files File upload to cloud Bluetooth transmission Home Browse device files File add delete move rename Export files through USB flash disk File upload to cloud platform...
-
Page 18: System Settings
System settings... -
Page 19: Software Upgrade
Software upgrade Insert the U disk of storage upgrade software to upgrade the system Connect WiFi remote upgrade... - Page 20 Fiber-iot OTDR advanced simulation tools QR code Scan Sign in Fiber-iot You can log in directly fiber-iot code，Imagine the advanced simula- Scan tion tool of OTDR，view OTDR data and generate reports Fiber-iot web: www.fiber-iot.com/tools/index.action...
- Page 21 Fiber-iot OTDR advanced simulation tools OTDR data can be viewed through cloud analysis, and generate reports. Powerful OTDR data report gen- erator using smart cloud, add event map, annotation, on-site test photos, optical fiber end face photos and other detailed information in the report...
-
Page 22: Common Problems And Solutions
Common problems and Solutions...
