Series 'C' Knifeholder
INSTALLATION MANUAL
Rigid Cartridge
Class I, II, III
Shear Slitting
Please read and understand all the
instructions before you install
the Tidland Series 'C' Knifeholder.
For information, contact:
Tidland Corporation
P.O. Box 1008
Camas, WA 98607
1-360-834-2345
1-800-426-1000 (USA)
PART NUMBER 520740B
1 of 3 sections of Part Number 517333B
1
Advertisement
Table of Contents
Related Manuals for Tidland C Series
Summary of Contents for Tidland C Series
- Page 1 Series 'C' Knifeholder INSTALLATION MANUAL Rigid Cartridge Class I, II, III Shear Slitting Please read and understand all the instructions before you install the Tidland Series 'C' Knifeholder. For information, contact: Tidland Corporation P.O. Box 1008 Camas, WA 98607 1-360-834-2345 1-800-426-1000 (USA)
-
Page 3: Table Of Contents
Table of Contents Knifeholder Safety…………………………………………………………………………………. 4 Receiving and Unpacking………………………………………………………………………… 4 Knifeholder Components……………………………………………….………………………….5 A. Determine Web Path………………………………………………………………... 6 1. Direction of Web………………………………………………………………… 6 2. Type of Slitting………………………………………………………………….. 6 3. Select Contact Side……………………………………………………………..7 4. Select Cant Angle Key………………………………………………………….7 B. Prepare to Mount Guidebar…………………………………………………………8 1. -
Page 4: Knifeholder Safety
§ The Tidland Series 'C' Knifeholder is intended to be used to produce a slit when operated with a driven anvil system, and there is no other intended purpose. -
Page 5: Knifeholder Components
Knifeholder Components Tidland Series 'C' Knifeholder Manual Position Lock Locking Gib Auto-Lock Brake Shoe Dovetail Mount Pinion Gear Rod Guide Bushing Cant Angle Key Strut Set Stop Pin Knife Blade Blade Guard Blade Lock Latch Pin Socket Head Capscrew Wedge Lock Screw... -
Page 6: Determine Web Path
A. Determine Web Path 1. Direction of Web: 2. Type of Slitting: 1/2 of wrap angle 90° Wrap Tangent Knifeholder axis Knifeholder axis should bisect should be 90° to the wrap angle. web path. -
Page 7: Select Contact Side
3. Select Contact Side: Left side Right side 4. Select Cant Angle Key: The cant angle creates a precise shear cut point with the driven anvil Contact Path Side Required See 'Changing the Cant Angle Key' in the Maintenance Manual. -
Page 8: Prepare To Mount Guidebar
B. Prepare to Mount Guidebar 1. Determine Space Requirements Tidland Series 'C' Knifeholder Geometry *Note: Reserve 1/2 of the total stroke for blade regrinding Inches Class I-25 2.43 1.08 5.90 6.59 0.63 1.00 0.07 0.16 0.03 11.21 Class I-33 2.43 1.08... -
Page 9: Determine Setback Distance (Tangent Shear Slitting Only)
2. Determine Setback Distance (for Tangent Shear Slitting only "A" Web Path Setback Typical Setback for Paper Based Products*: Class I-25: 1/8" (3.18mm) Class I-33: 1/8" (3.18mm) Class II: 1/4" (6.35mm) Class III: 3/8" (9.53mm) "B" Web Path * Other products may require different setbacks. Setback... -
Page 10: Determine Mounting Dimensions
3. Determine Mounting Dimensions (Horizontal Mounting Dimension) Guidebar mounting holes (Centerline) Support beam (Vertical Mounting Dimension) Parallel to web & tangent Anvil blade to anvil blade Vertical Mounting Dimension (VMD) Tangent and Wrap Slitting Class I-25 " 175.39mm 29/32 Class I-33 "... -
Page 11: Mount Guidebar
C. Mount Guidebar 1. Mark the mounting bolt center line on the support beam. 2. The guidebar must be straight within 0.010" (0.25mm) on a rigid and vibration free support. Guidebar Free Space Note: The guidebar mounting bolt holes are pre-drilled—if applicable. "A" = 12" (304.80mm). -
Page 12: Mount Knifeholder To Guidebar
D. Mount Knifeholder to Guidebar Manual Position Lock Knob Gib Adjustment Setscrews (2) Locking Gib Locking Gib Mounting Screws (2) Auto-Lock Brake Shoe Guidebar Guidebar Traverse Knob Pinion Gear Dovetail Mount Traverse Setscrew (1) 1. Turn the manual position lock knob counterclockwise to fully retract. 2. -
Page 13: Install Pneumatic System
E. Install Pneumatic System § Tidland Corporation recommends the use of a pneumatic system to prevent airborne oil or water from contaminating the knifeholders. The pneumatic system (Part Number: 520984) includes: A. 3/8" (9.52mm) supply air lines B. 5 micron air filter/pressure regulator with gauge (0-100 psi or 0-6.9 bar) - Page 16 Telefon: 02561-6880 Tokyo, Japan Tidland Corporation 1-360-834-2345 Fax: 161-320-4513 Fax: 02561-6495 Mumbai, India Fax: 1-360-834-5865 Email: sales_uk@maxcess.de Email: info@tidland.de Email: marketing@tidland.com Web Site: www.tidland.com © 2000 Tidland Corporation Rights reserved to amend technical details without notice 520740B of 517333B December 2000...
