- Page 1 GENERAL INFORMATION SECTION 06/2005...
-
Page 2: General Information
The V21 controller is a microprocessor which will permit pricing per selection from 0.00 to 99.99. This machine also has space-to-sales programming as well as energy savings modes. MODEL V21 721 V21 821 V21 621 SELECTIONS DIMENSIONS (HEIGHT X WIDTH X DEPTH) CURVED DOOR 72”... -
Page 3: Initial Setup
INITIAL SET-UP A. UNPACKING Remove all plastic film, cardboard and tape from the outside of the vendor. Loosen any shipping devices used to secure interior parts during shipment (backspacer, shims or spacers). To remove shipping boards from base, raise vendor on a well-stabilized lifting device. Remove the leveling bolts which hold the boards in place and remove the boards. - Page 4 APPROVED FOR OUTDOOR USE BASIC MODEL UNIT SERIAL NO. CHARGE OZ. R-134a AMPS REFRIGERATED VENDING MACHINE DESIGN PRESSURE - PSIg VOLTS LOW SIDE 90 HIGH SIDE 295 239L CYCLE PHASE MFD IN U.S.A. BY SANDENVENDO AMERICA, DALLAS, TX POWER REQUIREMENTS FIGURE 1 NOTE: The Model number of the vending machine is located on the top, left hand corner of the serial plate.
-
Page 5: Label Installation
FIGURE 2 FIGURE 3 LABEL INSTALLATION COIN INSTRUCTION LABEL & PRICE LABEL APPLICATION: Apply labels to a clean and dry surface. Peel backing from label and apply with firm, even pressure. INSTRUCTION LABEL (Refer to Figure 2 for the following information.) Coin insert “A”... -
Page 6: Alignment Checks
FIGURE 5 ALIGNMENT CHECKS REFRIGERATION AREA CHECK: Check the position of the condensation pan (see Figure 5). The correct position of the pan is on the right hand side of the vendor with the ramp of the pan just outside the right hand air dam. - Page 7 Side spacers ARE NOT required for 12 oz. can vending. Vend mechanism is self priming. No need to manually prime after initial load or reload. For questions regarding product settings, contact the Vendo Technical Services Department at 1-800-344-7216 ext.3368 (US/Canada) or 559-439-1770 ext.3368.
- Page 8 VEND MECHANISM PARTS DESCRIPTION The parts listed below are part of the vend motor mechanism (refer to Figure 7 on page G-9). One mechanism is required per column, except the drop sensor assembly, which is one assembly per machine. The parts are interchangeable. Setting will differ between single, double, triple, and quadruple depth.
- Page 9 FIGURE 7 06/2005...
- Page 10 VEND CYCLE Several operations take place during the vend cycle: When a selection is made, the coupler and bucket rotate, product is dispensed and the bucket is then reloaded. The sequence of these operations change slightly when the column’s depth setting is changed.
- Page 11 FIGURE 9 G-11 06/2005...
- Page 12 NOTES G-12 06/2005...
Need help?
Do you have a question about the V21 721 and is the answer not in the manual?
Questions and answers
How do I change the price on a V721
To change the price on a Vendo V21 721, follow these steps:
1. Open the vendor door.
2. Locate the service mode button on the control board.
3. Press and release the service mode button to enter service mode.
4. Use the selection buttons to scroll through the service mode options.
5. Navigate to the pricing setting mode.
6. Use the buttons to adjust the price as needed.
7. Save the new price setting.
8. Exit service mode.
All programming, including price changes, must be done in service mode using the control board and selection buttons.
