  • Page 1 Operator’s Manual TRIMAX MOWING SYSTEMS Australia • 1800 874 629 (Free Phone) • +61 (03) 8361 7868 • info@trimaxmowers.com.au New Zealand • +64 (07) 541 0411 • info@trimaxmowers.co.nz United Kingdom • +44 (0) 1933 652 235 • info@trimaxmowers.co.uk United States •...
  • Page 3 A sign-off form is included so you can keep a record of those employees who have been trained to operate the machine. Extra copies of this manual can be obtained from your dealer or direct from Trimax Mowing Systems if required. The part number is printed at the bottom of each page.

  • Page 4: Table Of Contents

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd TABLE OF CONTENTS 1. Commissioning & Warranty Registration Certificate ..................4 2. Notes About This Manual..........................5 3. Safety................................6 3a. Hazard Identification..........................7 3b. Safety Labels............................9 3c.
  • Page 5 TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 16d. Roller Scrapers........................... 50 16e. Wear Skids ............................51 16f. Greasing.............................. 52 16g. Gearbox Oil............................54 16h. Driveshaft Maintenance........................55 16i. Wheel & Tyres............................. 58 16j.

  • Page 6: Commissioning & Warranty Registration Certificate

    4. Where the papers go: a. The Warranty Registration document is a triplicate form. The pages are for different purposes: • the top layer is yellow and is to be returned to Trimax Mowing Systems at the address shown. •...

  • Page 7: Notes About This Manual

    On multi-spindled rotary mowers (including the Striker, ProCut, Stealth, Snake, Pegasus, X-WAM, and Topper ranges), Trimax convention is to identify the blade spindles as A, B, C, etc., starting from the left-hand side. On machines with more than one mowing deck, the left spindle on each deck starts with A.

  • Page 8: Safety

    Trimax machinery and at least annually thereafter or as required by local occupational safety and health regulations. d. The most important safety device on Trimax equipment is a safe operator. It is the operator's responsibility to read and understand all safety and operating instructions in the manual and to follow these.

  • Page 9: 3A. Hazard Identification

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 3a. Hazard Identification. HAZARD DESCRIPTION REMEDY Rotating blade The blades rotate at high speed. Hands & Do not approach or attempt to work hazard feet are well protected when the machine is on the machine while it is running.
  • Page 10 TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd Noise hazard Mowers are designed to operate outdoors. Always use ear protection when The operating position is seated in the operating the mower if noise driving seat of the tractor. Noise generated exceeds safe working limits.

  • Page 11: 3B. Safety Labels

    Any parts that are replaced must also show the same safety decals as before if removed. d. Safety labels are available from your dealer parts department or from Trimax Mowing Systems. They come in a single sheet which contains all the labels used on the machine.

  • Page 12: 3C. To The New Owner Or Operator

    Trimax machine. 3d. Safety Sign-off. 1. General: a. Anyone who will be operating and/or maintaining Trimax mowing, shredding and mulching equipment must read and clearly understand ALL safety, operating and maintenance Information presented in this manual.

  • Page 13: Label Identification

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 4. Label Identification. Types of labels and locations on the equipment are shown in the following illustrations. Familiarise yourself with the various pictorial safety signs, the type of warning, and the area or function related to that area that requires your SAFETY AWARENESS.
  • Page 14 TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd Label positions are shown on the drawings on the next page. E. P/N 424-000-030 Label E: Belt setup. Ensure the Rear Deck belts are run around the spindles as shown.
  • Page 15 TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd NOTE: Decal F is under the covers Snake S2 400 shown above. www.trimaxmowers.com 27 March 2019...

  • Page 16: Declaration Of Conformity

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 5. Declaration of Conformity. EC DECLARATION OF CONFORMITY Manufacturer Addresses: Trimax Mowing Systems (NZ) Ltd Trimax Mowing Systems Ltd 70 Maleme Street 40 Lower Farm Road, Moulton Park...

  • Page 17: Product Description

    The mower has a cutting width of 3.23 metres (127”) or 3.99 metres (157”). It consists of three separate roller mower decks attached to a central chassis and towed by a tractor. Trimax Snake mowers combine efficient wide-area mowing with excellent contour following and outstanding manoeuvrability.

  • Page 18: Specifications

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 7. Specifications. GENERAL MODEL Snake 320 Snake 400 3234mm (127”) 3994mm (157”) Cutting width 3372mm (133”) 4112mm (162”) Overall width 3500mm (138”) 3500mm (138”) Overall length (drawbar retracted) Transport width (standard 2100mm (82 1/2”)
  • Page 19 TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd MOWER DECKS MODEL Snake 320 Snake 400 1160/1160/1160mm (46/46/46”) 1540/1160/1540 (61/46/61”) Cutting width (left/centre/right) 10 – 90mm (3/8” - 3.5”) Cutting height range T40, 1-3/8” x 6-spline couplings...

  • Page 20: Machine Identification

    ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 8. Machine Identification. 1. Model Designation: a. This operator’s manual covers Trimax Snake mowers with model numbers 721-320-200, 721-400-200, 721-320-201, 721-400-201 722-320-200, 722-400-200, 722-320-201, 722-400-201 2. Serial numbers: a. The serial number ranges covered by this operator’s manual are:...

  • Page 21: Equipment Matching

    ©Trimax Mowing Systems (NZ) Ltd 9. Equipment Matching. Safe and reliable operation of Trimax Snake depends on partnering with a suitable tractor. 1. Tractor power: a. Minimum power requirement is a guide only. Requirement varies with the type of work and the terrain.

  • Page 22: Options

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 10. Options. 1. General: a. Several options can be specified at the time of ordering or added later as kits. b. Some affect the way the mower is operated.

  • Page 23: Instructional Videos & Other Support

    11. Instructional Videos & other Support Instruction videos and other support material that cover many of the following operations are available on the My Trimax section of the Trimax Mowing Systems website. See section 1a for details of how to access this.

  • Page 24: Setting Up

    France may have a “French piton”. 2. Mower tow hitch adapters: a. Parts for adapting the tow hitch may be supplied as options. Consult your dealer or Trimax Mowing Systems for advice. b. The mower tow hitch is configured to suit different tractor drawbars.
  • Page 25 TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd d. A plastic adapter is fitted for clevis drawbars. e. A bolt-on clevis converts the mower to suit single tongue tractor drawbars. NOTE: The clevis MUST be fitted when the mower is used with a single-tongue drawbar.
  • Page 26 TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd IMPORTANT! The mower drawbar must be the correct height from the ground. If the front of the mower is too low, movement of the mower decks will be affected and significant damage may result. This damage will not be covered by warranty.
  • Page 27 TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd WARNING! If the mower is attached to a tractor with a single-tongue drawbar the clevis plate MUST be used or the mower may disconnect itself from the tractor.
  • Page 28 TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd f. The chains should pass underneath the mower tow hitch and be adjusted for length to prevent the trailer’s drawbar hitting the ground if the mower is detached from the tractor.
  • Page 29 TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 10. Connect the mower to the tractor. NOTE: If the tractor is fitted with a powered hitch, see the tractor operator’s manual for instructions. a. The three-point linkage arms are not needed. Raise them to maximum height. Tie them together to prevent tyre contact.
  • Page 30 TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 12. Fit the primary driveshaft: a. The primary driveshaft transmits power from the tractor’s power take-off to the mower. b. It is fitted with a constant velocity joint at the tractor end which allows the driveshaft to operate at extreme angles.
  • Page 31 TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd k. Attach the driveshaft safety shield chain at the tractor end to a suitable point on the tractor to prevent the covers rotating. 90 ° The chain should be as close to 90 degrees as possible to the driveshaft.
  • Page 32 ©Trimax Mowing Systems (NZ) Ltd 13. Setting Mower Tow Hitch Length: There is a short instructional video that shows the following procedure. Go to the My Trimax section of the Trimax Mowing Systems website. See section 1a for details of how to do this.
  • Page 33 On some tractors the drawbar is adjustable. If so, adjust it to make it shorter. If not, it may be necessary to modify it. Contact Trimax Mowing Systems for advice.

  • Page 34: 12B. Purge The Hydraulic Lift Rams

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd A standard ½” BSP male quick-release coupling is fitted. This should suit most tractors. Consult your tractor dealer if the fittings are not compatible. a. With the tractor engine stopped, operate the auxiliary hydraulic valve control(s) in both directions to remove any residual hydraulic pressure.

  • Page 35: 12C. Other Checks

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd DANGER! The mower decks may drop suddenly if there is air in the system. Clear the area before proceeding. DANGER! The lift rams all share the same hydraulic circuit. The rear deck will always lift first but either the left or right deck may follow.

  • Page 36: 12D. Uncoupling The Mower From The Tractor

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 12d. Uncoupling The Mower From The Tractor. 1. To uncouple the mower: a. Manoeuvre the mower into the parking area. b. Either: i. Lower the wings to the ground, or ii.

  • Page 37: Before Operation

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 13. Before Operation. SAFETY! Before attempting to make any adjustments or carry out maintenance on your Snake review the hazard identification list and take all necessary precautions. 12a Daily Checks 1.

  • Page 38: Using The Machine For The First Time

    1. Running in. a. Although there are no operational restrictions on Trimax Snake mowers when used for the first time, the following mechanical items should be checked. 2. After operating for one hour or after mowing 2 hectares (5 acres): a.

  • Page 39: Operation & Adjustments

    (section 3a) and take all necessary precautions. Trimax Snake mowers are designed to operate well in many kinds of grass or terrain conditions, but the operator has the responsibility of being familiar with and following all operating and safety procedures.

  • Page 40: 15B. Raise & Lower The Mower Decks - Standard Pull Rope

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 2. Transport lock release mechanism: a. The release mechanism is the same for the standard pull rope or the optional electric operation. b. Pivoting arms unhook from the latch pins when the release is operated.
  • Page 41 TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 1. To lift the mower decks: a. Bring the tractor to a stop on level ground. b. Disengage the tractor’s PTO drive and wait for all rotating parts to stop.

  • Page 42: 15C. Raise & Lower The Mower Decks - Optional Remote Unlock

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 15c. Raise & Lower The Mower Decks - Optional Remote Unlock. WARNING! Drive to the mower MUST be disconnected before the mower decks are lifted. Disengage the tractor’s PTO and wait for all rotating parts to stop before operating the hydraulic lift control.

  • Page 43: 15E. Cutting Height

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd SAFETY! Do not use kerb jump while moving between jobs. Disengage drive to the mower decks and raise them into the transport position if moving more than a few metres (yards).

  • Page 44: 15F. Moving Between Jobs

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd Securely tighten the clamp bolts (a). To raise the cutting height: Loosen all the clamp bolts (a). b. Turn all the adjuster screws (c) clockwise by the required number of turns.

  • Page 45: 15H. Operating Hints

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 1. Start a mowing job: a. Check the site. Remove stones or objects that could be thrown by the mower blades. b. Ensure area is clear of bystanders, especially children.
  • Page 46 TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd a. Snake mowers work well in wet conditions, but mow when conditions are dry if possible. b. Terrain, grass length, moisture content, soil moisture and tractor power all affect the final job.

  • Page 47: Service & Maintenance

    Trimax mowers are designed with servicing in mind. Every effort is made to ensure parts can be removed and replaced as easily and quickly as possible. Despite this, simple jobs can escalate into much more difficult operations if other parts have been damaged.

  • Page 48: 16A. Transmission Covers

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 16a. Transmission Covers. 1. General: a. Transmission covers protect people from moving parts. b. They keep grass clippings and debris away from the transmission. c. The covers must be opened to check drive belt tensions or removed altogether to replace the drive belts.

  • Page 49: 16B. Drive Belts

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 16b. Drive Belts. Snake decks are fitted with Auto Belt Tension Systems (ABT). This removes the need for the operator to routinely check belt tensions and adjust. It is still recommended to routinely check that the ABT system is functioning correctly to ensure belt tension is maintained.

  • Page 50: 16C. Blades

    160 decks may require the operator to remove both belts to gain access for replacement. d. Replace the belt with a genuine Trimax part. Refit other belts if removed. Refer to the decal on the mower deck for correct belt placement.
  • Page 51 All parts should be stamped Trimax. c. Non-genuine or “pirate” blades may be available. Trimax owners who have tried them say they don’t last as long and that inaccurate dimensions have led to other failures. d. There have been instances where blades have broken free from Trimax mowers fitted with pirate blade bolts made from inferior materials.

  • Page 52: 16D. Roller Scrapers

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd f. Discard used blade bolts and nuts. Fit new bolts and nyloc nuts when fitting new blades. g. Fit the new blade and bolt to the blade beam. Ensure the bolt is orientated correctly.

  • Page 53: 16E. Wear Skids

    ©Trimax Mowing Systems (NZ) Ltd 16e. Wear Skids 1. General: a. Trimax Mowing Systems has produced ever more effective grass mowing machines. b. They began being used on high quality turf at cut heights so low they were previously considered impossible for rotary mowers.

  • Page 54: 16F. Greasing

    In particular, do not use greases containing graphite. c. If there are any doubts concerning the composition of any grease being considered for use in this Trimax product consult your lubricant supplier or purchase a suitable product from a multi -national company.
  • Page 55 TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 3. Grease outrigger hinge bushes: a. Lubricate every 150 hours or monthly. b. Each outrigger (left, rear and right) pivots about a large tubular hinge pin. c. Grease points are located at either end of the tube (6 in total).

  • Page 56: 16G. Gearbox Oil

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 5. Grease height adjusters: a. Grease only as required. If the cutting height is never changed the adjusters may never need greasing. b. Greaser nipples are fitted to each height adjustment block.

  • Page 57: 16H. Driveshaft Maintenance

    Driveshaft tubes must always be able to telescope freely, or serious damage will result. c. Driveshafts for Trimax mowers may be supplied by various manufacturers. d. Maintenance instructions may be attached to the driveshaft or included with this operator’s manual.
  • Page 58 TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd b. Every 40 hours or weekly, grease the universal joints at either end of the driveshaft (a). Pump until grease starts to exit the seals (b). NOTE: Instructions for greasing the constant velocity (CV) joint on the primary driveshaft follow below.
  • Page 59 TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 3. Grease the primary driveshaft CV joint: a. The CV joint has two universal joints coupled together with an enclosed disc between. The disc has two grease points.

  • Page 60: 16I. Wheel & Tyres

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 16i. Wheel & Tyres. DANGER! Tyre and rim parts can explode if tyres are over-inflated causing serious injury or death. Always maintain the correct tyre pressure. Do not inflate the tyres above the recommended pressure.

  • Page 61: 16J. Pitch & Roll Pivots

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd Replace the wheels: a. Ensure the wheel stud and nut threads are clean. b. Fit the wheel to the studs. c. Fit the stud nuts with the tapered side to the wheel. Lightly tighten each nut following a crossways pattern.

  • Page 62: 16K. Clearing Blockages

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 3. Check the side deck pitch pivots: a. The left and right decks have pitch pivots which are secured by the large nuts under each outrigger near the mower deck gearboxes.

  • Page 63: 16M. Roller Bearings

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 2. Clean the transmission chambers: a. Release the cover latches and lift the cover to inspect for debris in the transmission area. b. Dry debris under the covers can be blown out with a leaf blower or wet clippings hosed out with water.

  • Page 64: Service Schedule

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 17. Service Schedule. This service schedule is a record to be kept as maintenance is carried out. Copy the page to continue your record. IMPORTANT! If using the mower in arduous conditions (e.g. excessively dusty or wet etc.) moving parts and driveshafts may require greasing more frequently.
  • Page 65 TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd DATE HOURS SERVICED BY (Initials) Every 8 hours or daily Grease roller bearings (12) Check drive belt tension, adjust if reqd. (3-5) Check all fasteners and safety devices...

  • Page 66: Troubleshooting

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 18. Troubleshooting. FAULT POSSIBLE CAUSES REMEDY Mower vibrates Excessive PTO speed Run PTO at 540rpm excessively Blades missing or badly Replace blades damaged Primary driveshaft fitted Fit the constant velocity joint to the tractor...
  • Page 67 TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd Cutting too much at Run PTO at 540rpm, vary transmission to once travel more slowly Raise cutting height for first cut, lower cutting height & cut again in opposite direction...
  • Page 68 Left or right mower deck Outrigger bent Replace outrigger. Consult dealer or Trimax guide plates misaligned Mowing Systems. with rollers on chassis when deck in transport Pitch & roll pivots loose Inspect pitch & roll pivots, tighten or repair position.

  • Page 69: Lifting & Transporting

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 19. Lifting & Transporting. SAFETY! Only trained people should use lifting equipment and secure the mower for transport. SAFETY! Before lifting or transporting the mower, review the hazard identification table (section 3a) and take all necessary precautions.
  • Page 70 TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd DANGER! Keep well clear of the suspended mower. 1. Securing the mower onto a truck or trailer: a. Tie-down points are provided on the mower chassis underneath. b. Use these to connect approved chains or webbing.

  • Page 71: Storage

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 20. Storage. SAFETY! Before preparing the mower for storage, review the hazard identification table (section 3a) and take all necessary precautions. 1. General: a. After a season's use, the machine should be thoroughly inspected and prepared for storage.

  • Page 72: Tools

    ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 21. Tools. 1. General: a. Most repairs and adjustments on Trimax mowers can be carried out using standard engineering tools. b. Height adjustment is much simpler with the following: i. ½” drive power bar ii.

  • Page 73: Bolts & Nuts

    ©Trimax Mowing Systems (NZ) Ltd 22. Bolts & Nuts. 1. General: a. Most bolts used on Trimax machines except fling-tip blade bolts have metric threads and are of grade 8.8. Bolt heads should have the maker's symbol and "88" embossed on their heads.

  • Page 74: Spare Parts

    Identify the parts you want from the following list. b. Always quote the machine’s serial number when ordering parts. c. Full parts drawings and listings are available on the “My Trimax” section of the Trimax Mowing Systems website. See section 1a for more details.

  • Page 75: Supplement

    TRIMAX SNAKE S2 OPERATORS MANUAL ENGLISH EDITION ©Trimax Mowing Systems (NZ) Ltd 24. Supplement. 24a. Snake Lifting and Tiedown Instructions www.trimaxmowers.com 27 March 2019...
