- Page 1 INSTRUCTION MANUAL 6-Piece Wicker Sectional Set SKY5782 Ver. 1...
- Page 2 As shoppers, we’re always trying to find the perfect balance between quality & value. At BCP, we believe we’ve achieved that. Our diverse catalog of everyday essentials is tailored especially to our customers & guaranteed to hit that sweet spot of high quality & low price.
-
Page 3: Tools Required
NOTICE Please retain these instructions for future reference. • Please do not exceed the weight limitations of this item. • Do not stand on or use any part of this item as a step ladder. • Firmly secure all bolts, screws and knobs before use. •... - Page 4 PARTS SECTIONAL LEFT SECTIONAL RIGHT SECTIONAL MIDDLE PANEL PANEL PANEL 1 PC 1 PC 1 PC SECTIONAL BACK SECTIONAL BACK SECTIONAL SEAT PANEL LEFT PANEL RIGHT LEFT 2 PCS 1 PC 2 PCS SECTIONAL SEAT SEAT FRAME PANEL BENCH TOP RIGHT 1 PC 3 PCS...
- Page 5 PARTS OTTOMAN LEG SET TABLETOP TABLE BASE 2 PCS 1 PC 1 PC SECTIONAL SEAT SECTIONAL BACK BENCH CUSHION CUSHION CUSHION 3 PCS 7 PCS 1 PC OTTOMAN CUSHION FURNITURE COVER 1 PC 1 PC...
- Page 6 PRODUCT ASSEMBLY - LEFT SECTIONAL Attach one part D back left panel to the part A left panel with two part 4 screws and four part 5 washers, then secure with two part 6 end nuts. Then secure one part 1 screw and one part 5 washer as indicated below. Attach one part F left seat to the sectional assembly with seven part 4 screws and fourteen part 5 washers, then secure with seven part 6 end nuts.
- Page 7 PRODUCT ASSEMBLY - RIGHT SECTIONAL Attach one part E back right panel to the part B right panel with two part 4 screws and four part 5 washers, then secure with two part 6 end nuts. Then secure one part 1 screw and one part 5 washer. Attach one part G right seat to the sectional assembly with seven part 4 screws and fourteen part 5 washers, then secure with seven part 6 end nuts.
- Page 8 PRODUCT ASSEMBLY - MIDDLE SECTIONAL Attach one part D back left panel to the part C middle panel with two part 3 screws and two part 5 washers. Then secure one part 1 screw and one part 5 washer as indicated below. Attach one part F left seat to the sectional assembly with two part 3 screws and two part 5 washers.
- Page 9 PRODUCT ASSEMBLY - SOFA Interlock the three sectional assemblies with four part 7 clips. Place three part B seat cushions on the assembly and attach them by tying o the built in strings. Place seven part Q back cushions on the assembly.
- Page 10 PRODUCT ASSEMBLY - BENCH Attach two part J bench legs to the part I bench top with four part 2 screws and four part 5 washers. Attach two part K bench sides to the part J legs with eight part 2 screws and eight part 5 washers.
- Page 11 PRODUCT ASSEMBLY - OTTOMAN Attach one part M ottoman leg set to the part L ottoman top with two part 2 screws and two part 5 washers. Attach one part M ottoman leg set to the part L ottoman top with two part 2 screws and two part 5 washers.
-
Page 12: Height Adjustment
PRODUCT ASSEMBLY - TABLE Attach the part N tabletop to the part O table base with four part 3 screws and four part 5 washers. NOTE: Table must be raised to attach the tabletop See Height Adjustment section. HEIGHT ADJUSTMENT To raise the table, step on the metal foot pedal until To lower the table, step on the metal foot pedal the tabletop reaches your desired height. - Page 13 STORAGE Arrange the furniture as shown below, then cover with the part T furniture cover. NOTE: Cover this furniture set when not in use for an extended time, or during periods of inclement weather.
- Page 14 Check out more great products: bestchoiceproducts.com...
- Page 15 Earn points while you shop. Join today! Give your friends 15% o their first order! For each successful referral you’ll receive 100 points. bestchoiceproducts.com...
-
Page 16: Help Center
HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
