- Page 1 3308520 User’s Manual 5.25" Embedded Controller with Socket 479 for Intel Pentium M/ Celeron M Version 1.0...
- Page 2 Copyrights This document is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer.
-
Page 3: Table Of Contents
Table of Contents Chapter 1 General Description ........1 1.1 Major Features ............... 2 1.2 Specifications ................ 3 1.3 Board Dimensions..............5 Chapter 2 Unpacking ..........7 2.1 Opening the Delivery Package..........7 2.2 Inspection................7 Chapter 3 Hardware Installation ......9 3.1 Before Installation ..............9 3.2 Board Layout ............... - Page 5 Safety Instructions Integrated circuits on computer boards are sensitive to static electricity. To avoid damaging chips from electrostatic discharge, observe the following precautions: Do not remove boards or integrated circuits from their anti-static packaging until you are ready to install them. Before handling a board or integrated circuit, touch an unpainted portion of the system unit chassis for a few seconds.
-
Page 7: Chapter 1 General Description
1.3~2.0GHz, supports ULV Intel® Celeron® M processor 600MHz/512K. The Intel® 852GM(E) with 8MB shared main memory supports CRT display up to 1600 x 1200. It also supports LVDS interface, 3308520 provides 24-bit single channel/48-bit dual channel, provides 18-bit single channel/36-bit dual channel. -
Page 8: Major Features
24-bit/48-bit LVDS Panel display interface (3308520) 18-bit/36-bit LVDS Panel display interface () Intel® 82562ET fast Ethernet controller ALC203 3D audio controller Fast PCI ATA/33/66/100 IDE controller CF, GPIO, 4 COM, 6 USB2.0, PC/104 TV-Out (3308520 only), Capture (3308520 only), H/W Monitor function... -
Page 9: Specifications
Specifications System 3308520 provides Intel® Pentium® M processor 760 2.0GHz, Intel® Pentium® M processor 745 1.8GHz, Intel® Celeron® M processor 370 1.5GHz, Intel® Celeron® M processor 320 1.3GHz provides ULV Intel® Celeron® M processor 600MHz/512K Front Side Bus 3308520 supports 400/533MHz FSB... - Page 10 Display Chipset Intel® 82852GME LVDS 24-bit single channel/48-bit dual channel TV-Out Provides PAL or NTSC TV systems Capture SAA7134HL video broadcast decoder Audio Chipset ALC203 Audio Interface (w/header) MIC In, Line In, Line Out Ethernet Chipset Intel® 82562ET 10/100 Mbps LAN Ethernet Interface Internal 5x2 header Mechanical &...
-
Page 11: Board Dimensions
Board Dimensions... -
Page 13: Chapter 2 Unpacking
Chapter 2 Unpacking Opening the Delivery Package The 3308520 is packed with an anti-static bag. The board contains sensitive electrical components that are easily damaged by static (electricity). Do not remove the anti-static wrapping until proper grounding have been taken. Safety instruction has been described the anti-static precautions and procedures in the previous. - Page 14 Cables Package Description Qty. LAN 10-pin to RJ-45 cable ATX power cable 20-pin to 4-pin(12V+5V) and 5-pin(5V only) COM 40-pin to DB9*4 1-to-2 USB Y-cable w/bracket Floppy controller cable 34-pin UDMA5 40-pin IDE cable Printer cable DB26-25pin VGA cable DB10-15pin Speaker/MIC port w/8-pin header PS/2 Keyboard/Mouse 1-to-2 6-pin Mini DIN cable It is recommended that you keep all the parts of the delivery package...
-
Page 15: Chapter 3 Hardware Installation
Chapter 3 Hardware Installation This chapter illustrates how to install the hardware using the 3308520/. This chapter also contains information related to jumper settings of switch, and watchdog timer selection. Before Installation After checking your package contents, you are now ready to install your hardware. -
Page 16: Board Layout
Board Layout Top Side Solder Side... -
Page 17: Jumper List
RS-232 Short CN21 System & Memory Frequency Select: 400MHz Short CN22 Open CN23 Short NOTE: CN4/CN21/CN22/CN23 are for 3308520 only. Connector List Connector Definition Page S-Video Out Connector TV-Out Connector Inverter Power In Connector Capture In Connector CN8(1-2) HDD LED... -
Page 18: Configuring The Cpu
Internal USB2.0 Port 4-pin Power In Connector Configuring the CPU The 3308520 provides Intel® Pentium® M processor 760 2.0GHz, Pentium® M processor 745 1.8GHz, Celeron® M processor 370 1.5GHz, and Celeron® M processor 1.3GHz socket. The embedded with ULV Intel® Celeron® M processor 600MHz/512K. If you want to use 533MHz FSB processor, please set CN4, CN21, CN22, CN23 as below table. -
Page 19: Vga Controller
VGA Controller The 3308520/ provides two connection methods of a VGA device. CN14 offers an internal 10-pin CRT connector and PANEL1/PANEL2 are the LVDS interface connectors onboard reserved for flat panel installation. Please see the following chart for more detail:... - Page 20 The 3308520/ has an onboard jumper voltage select for flat panel. Jumper JP2 offers two voltage settings for the user. JP2: Panel Voltage Select Options Settings +3.3V (default) Short 1-2 Short 2-3 CN3: Inverter Power In Connector Description +12V +12V...
-
Page 21: Pci E-Ide Drive Connector
PCI E-IDE Drive Connector IDE1 is a standard 40-pin 2.54-pitch connector daisy-chain driver connector serves the PCI E-IDE drive provisions onboard the 3308520/ . A maximum of two ATA/33/66/100 IDE drives can be connected to the 3308520/ via IDE1. IDE1: IDE Connector... -
Page 22: Floppy Disk Drive Connector
Floppy disk Drive Connector The 3308520/ uses a standard 34-pin header connector, FDC1, for floppy disk drive connection. FDC1: Floppy Connector Description Description DRVDEN0 DRVDEN1 INDEX# MTR0# DS1# DS0# MTR1# DIR# STEP# WDATA# WGATE# TRAK00# WRTPRT# RDATA# HDSEL# DSKCHG#... -
Page 23: Parallel Connector
3.10 Parallel Connector LPT1 is a standard 26-pin connector designed to accommodate parallel port connection onboard for 3308520/. LPT1: Parallel Connector Description Description Strobe Auto Form Feed Data 0 ERROR# Data 1 Initialize Data 2 Printer Select LN# Data 3... -
Page 24: Serial Port Connectors
3.11 Serial Port Connectors 3308520/ offers NS16C550 compatible UARTs with Read/Receive 16-byte FIFO serial ports and internal 2x20 header and RS-422/485 connector. CN19: COM 1~COM 4 Connector (2x20 Header) PIN Description PIN Description DCD1 DSR1 RXD1 RTS1 TXD1 CTS1 DTR1... -
Page 25: Ethernet Connector
*2: 4-wires point-to-point full duplex function Typical RS-485 2-wires Mutildrop Network 4-wires point-to-point full duplex RS-422 3.12 Ethernet Connector The 3308520/ provides one internal 10-pin connector for 10/100 Based LAN. Please refer to the following for its pin information. CN16: Internal LAN Connector PIN Description... -
Page 26: Usb Port
The 3308520/ provides 6 USB2.0 ports at US1/US2/US3. US1/US2/US3: Internal USB2.0 Port Description Description USBD- USBD- USBD+ USBD+ 3.14 CMOS Data Clear The 3308520/ has a Clear CMOS jumper on JP1. JP1: Clear CMOS Options Settings Normal Operation (default) Short 1-2 Clear CMOS Short 2-3 IMPORTANT: Before you turn on the power of your system, please set JP1 to Short 1-2 for normal operation. - Page 27 FN1/FN2: Fan Power In Connector Description Fan Speed Connector FN1/FN2 onboard 3308520/ is a 3-pin fan power output connector. And 3308520/ supports +5V Fan only. CN11: AT Power In Connector PIN Description +12v CN12: 2-pin ATX Power On/Off Switch Description Pull 220Ω...
-
Page 28: Keyboard/Mouse Connectors
3.16 Keyboard/Mouse Connectors The 3308520/ offers CN17 for an internal 6-pin cable converter to keyboard/mouse. CN17: 6-pin Keyboard/Mouse Connector Description Keyboard Data Mouse Data Keyboard Clock Mouse Clock 3.17 System Front Panel Control The 3308520/ has system front panel control at location CN8. -
Page 29: Watchdog Timer
3.18 Watchdog Timer Once the Enable cycle is active a Refresh cycle is requested before the time-out period. This restarts counting of the WDT period. When the time counting goes over the period preset of WDT, it will assume that the program operation is abnormal. -
Page 30: Audio Connectors
3.19 Audio Connectors The 3308520/ has an onboard ALC203 3D audio controller. The following tables list the pin assignments for the MIC In/Line Out connector. J1: CD Line-In Connector PIN Description LINE_R LINE_L JP3: MIC In/Line Out Connector PIN Description PIN Description... -
Page 31: Pci Expansion Slot
IDE_PDD9 IDE_PDD10 The CompactFlash socket has a dummy protected design which prevents user insert CompactFlash card into wrong direction. 3.21 PCI Expansion Slot 3308520/ provides Mini slot. peripheral component with standard Type III Mini PCI card can be used. And also... -
Page 32: Gpio Function
3.22 GPIO Function The 3308520/ offers one 8-bit GPIO port. CN18: 8-bit Input/Output PIN Description PIN Description DX, 2EH AL, 87H DX, AL DX, AL AL, 07H DX, AL DX, AL AL, 2AH DX, AL AL, 0FCH DX, AL AL, 30H... -
Page 33: Capture Function
3.23 Capture Function 3308520 Capture Function Supports multi standard NTSC/PAL/SECAM video decoding CN6: Capture In Connector Description Description Capture In_1 Capture In_2 Capture In_3 3.24 TV-Out and S-Video Function 3308520 TV-Out Function CN1: S-Video Out Connector PIN Description Video-SVHSY Video-SVHSC... -
Page 34: Pc/104 Connectors
3.25 PC/104 Connectors The PC/104 expansion bus offers provisions to connect all types of PC/104 modules. With the PC/104 bus being known as the new generation of industrial embedded 16-bit PC standard bus, thousands of PC/104 modules from multiple venders can be easily installed onboard. - Page 35 CN9: PC/104 64-pin Connector Description PIN Description Connector diagram rotated 90 degrees -IOCHECK clockwise from RESETDRV original position IRQ9 IOCHRDY -SMEMW SA19 -SMEMR SA18 -IOW SA17 -IOR SA16 -DACK3 SA15 DRQ3 SA14 -DACK1 SA13 DRQ1 SA12 -REFRESH SA11 SYSCLK SA10 IRQ7 IRQ6 IRQ5...
- Page 36 We will do our best to support your products, projects and business. Address: Global American, Inc. 17 Hampshire Drive Hudson, NH 03051 Telephone: Toll Free U.S. Only (800) 833-8999 (603) 886-3900 FAX: (603) 886-4545 Website: http://www.globalamericaninc.com Support: Technical Support at Global American...
