3308220 User's Manual
3.5" Embedded Controller
Version V1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3308220 and is the answer not in the manual?

Questions and answers

Related Manuals for Global American 3308220

Summary of Contents for Global American 3308220

  • Page 1 3308220 User’s Manual 3.5" Embedded Controller Version V1.1...
  • Page 2 Copyrights This document is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1 General Description ........1 1.1 Major Features ............... 2 1.2 Specifications ................ 3 1.3 Board Dimensions..............4 Chapter 2 Unpacking ..........5 2.1 Opening the Delivery Package..........5 2.2 Inspection................5 Chapter 3 Hardware Installation ......7 3.1 Before Installation ..............7 3.2 Board Layout .................
  • Page 4 Chapter 4 AMI BIOS Setup ........29 4.1 Starting Setup..............29 4.2 Using Setup ................. 30 4.3 Main Menu................31 4.4 Advanced Settings .............. 32 4.5 Advanced PCI/PnP Settings..........37 4.6 Boot Settings ............... 38 4.7 Security Settings ..............39 4.8 Advanced Chipset Settings..........
  • Page 5 Fasten the ALLIGATOR clip of the strap to the end of the shielded wire lead from a grounded object. Please wear and connect the strap before handle the 3308220 to ensure harmlessly discharge any static electricity through the strap.

  • Page 6: Chapter 1 General Description

    LAN, audio, SATA, 4 COM, USB2.0, and PC/104 Plus interfaces. Its onboard ATA/33/66/100 to IDE drive interface architecture allows the 3308220 to support data transfers of 33 or 66MB/sec. to one IDE drive connection. Designed with the VIA CX700, the board supports VIA C7 or ULV VIA V4 Eden 600MHz~2.0GHz CPU.

  • Page 7: Major Features

    Major Features The 3308220 comes with the following features: VIA C7 or ULV VIA V4 Eden processor 600MHz~2.0GHz One SO-DDRII socket with a max. capacity of 1GB VIA CX700 system chipset Winbond W83697UG super I/O chipset VIA CX700 graphics controller...

  • Page 8: Specifications

    VIA CX700 Serial ATA controller Fast PCI ATA/33/66/100 IDE controller CF, 8-bit I/O, 4 COM, 5 USB2.0, PC/104 Plus +10~+30V wide range single DC power in TV-Out, Hardware Monitor function Specifications CPU: ULV VIA V4 Eden processor 600MHz/800MHz/1.0GHz VIA C7 processor 1.0~2.0GHz Front Side Bus: Supports 400MHz FSB Memory: One SO-DDRII socket supports up to 1GB Chipset: VIA CX700...

  • Page 9: Board Dimensions

    Board Dimensions...

  • Page 10: Chapter 2 Unpacking

    Chapter 2 Unpacking 2.1 Opening the Delivery Package The 3308220 is packed in an anti-static bag. The board has components that are easily damaged by static electricity. Do not remove the anti-static wrapping until proper precautions have been taken. Safety Instructions in front of this manual describe anti-static precautions and procedures.
  • Page 11 Cables Package Description Audio cable x 1 4-pin power cable x 1 IDE flat cable x 1 SATA power cable x 1 (optional) SATA cable x 1 (optional) Keyboard/Mouse transfer cable x 1 2 USB cable with bracket x 1 (optional) Serial port flat cable x 1 It is recommended that you keep all the parts of the delivery package intact and store them in a safe/dry place for any unforeseen event...

  • Page 12: Chapter 3 Hardware Installation

    Chapter 3 Hardware Installation This chapter provides the information on how to install the hardware using the 3308220. This chapter also contains information related to jumper settings of switch, and watchdog timer selection etc. Before Installation After confirming your package contents, you are now ready to install your hardware.

  • Page 13: Board Layout

    Board Layout...

  • Page 14: Jumper List

    CompactFlash Connector CN29 External Power In Connector Fan Power In Connector Configuring the CPU The 3308220 embedded with ULV VIA V4 Eden 600MHz/800MHz/ 1GHz or VIA C7 1.0/1.5/2.0GHz CPU. User don’t need to adjust the frequently and check speed of CPU.

  • Page 15: System Memory

    System Memory The 3308220 provides one SO-DDRII socket at locations CN27. The maximum capacity of the onboard memory is 1GB. VGA Controller The 3308220 provides two connection methods of a VGA device. CN25 offers an internal 10-pin CRT connector and CN6/CN9 are the LVDS interface connectors onboard reserved for flat panel installation.
  • Page 16 If you want to use 48-bit dual channel LVDS panel, please use CN10 and CN12 combined. The 3308220 has an onboard jumper that selects the working voltage of the flat panel connected to the system. Jumper JP1 offers two voltage settings for the user.

  • Page 17: Ide Drive Connector

    IDE Drive Connector CN11 is a 2.0-pitch 44-pin connector daisy-chain driver connector serves the PCI E-IDE drive provisions onboard the 3308220. A maximum of two ATA/33/66/100 IDE drives can be connected to the 3308220 via CN11. CN11: IDE Connector Description...

  • Page 18: Serial Port Connectors

    SATATXP SATATXN SATARXN SATARXP 3.10 Serial Port Connectors The 3308220 offers NS16C550 compatible UARTs with Read/ Receive 16-byte FIFO serial ports and four internal 10-pin headers and one RS-422/485 connector. CN24/CN20/CN21/CN26: COM 1 ~ COM 4 Connector (5x2 Header) PIN Description PIN Description...

  • Page 19: Ethernet Connector

    4-wires point-to-point full duplex RS-422/485 Typical RS-485 2-wires Mutildrop Network 3.11 Ethernet Connector The 3308220 provides two RJ-45 connectors for 10/100 Based LAN. Please refer to the following for its pin information. When installs OS, this driver namely can automatically install. User does not need to renewal.

  • Page 20: Usb Port

    Before you turn on the power of your system, please IMPORTANT: set JP5 to Short 1-2 for normal operation. 3.14 Power and Fan Connectors 3308220 provides one 4-pin power in at CN15, one 3-pin power in at CN29. Connector FN2 onboard 3308220 is a 3-pin fan power output connector.

  • Page 21: Keyboard/Mouse Connectors

    The CN8 is a PS/2 6-pin Mini DIN connector for 3308220. CN8: PS/2 6-pin Mini DIN Keyboard/Mouse Connector Description Keyboard Data Mouse Data Keyboard Clock Mouse Clock 3.16 System Front Panel Control The 3308220 has front panel control at location CN23 that indicates the power-on status.

  • Page 22: Watchdog Timer

    A reset system signal will restart when such error happens. The following sample programs show how to enable, disable and refresh the watchdog timer: .286 .MODEL SMALL .DATA ;this is data area db '------------------------------------------------------',0ah,0dh,'$' copyright db '|Copyright by Global American, Inc. |',0ah,0dh,'$' db '------------------------------------------------------',0ah,0dh,'$'...
  • Page 23 port 04Eh ;W83697H Chipset port datao 04Fh ;data port .CODE print macro buff dx,offset buff; ah,09h endm begin proc near ax,@data ds,ax ; W83697H dx,port ; Unlock registor al,087H dx,al dx,al dx,port al,07H dx,al dx,datao ; set device 8 al,08H dx,al dx,port ;...

  • Page 24: Tv-Out Function

    User can also use AL, 00H’s defined time for reset purposes, e.g.00H for Disable, 01H = 1sec, 02H=2sec….FFH=255sec. 3.18 TV-Out Function The 3308220 can support TV-out function whose input could be up to 800 x 600 graphics resolutions. World Wide Video standards are supported including NTSC-M (North America, Taiwan), NTSC-J (Japan), PAL-b, D, G, H, I (Europe, Asia), PAL-M (Brazil), PAL-N (Uruguay, Paraguay) and PAL-NC (Argentina).

  • Page 25: Pc/104 Plus Connector

    3.19 PC/104 Plus Connector The 3308220 provides one PC/104 Plus connector, at location CN2. CN2: PC/104 Plus Connector Description Description CBE0# AD11 AD14 AD13 +3.3V CBE1# SERR# PERR# STOP# +3.3V +3.3V TRDY- FRAME# AD16 AD18 +3.3V AD21 AD20 +3.3V AD23...

  • Page 26: Audio Connectors

    INTR_B# INTR_C# INTR_C# 3.20 Audio Connectors The 3308220 has an onboard VIA VT1708A High Definition Audio CODEC. The following tables list the pin assignments of the Line In/Audio Out connector. 4 stereo DACs support 24-bit, 192KHz samples DAC with 100dB S/N Ratio...

  • Page 27: Compactflash Connector

    MIC IN L MIC IN R 3.21 CompactFlash Connector The 3308220 also offers a Type I/II CompactFlash connector is IDE interface located at the solder side of the board. The designated CN28 connector, once soldered with an adapter, can hold CompactFlash...

  • Page 28: 8-Bit I/O Function

    IORDY DACK IDE LED PDIAG DATA8 DATA9 DATA10 NOTE: When use CF card, IDE device function will be disabled. 3.22 8-bit I/O Function The 3308220 offers one 8-bit input/output port by parallel port. CN19: 8-bit Input/Output PIN Description PIN Description...
  • Page 29 .286 .MODEL SMALL .DATA ;this is data area port 0378h ;print port can be change to 278h .CODE print macro buff dx, offset buff; ah,09h endm delay : push cx,0155h push cx,0ffffh wait1: loop wait1 loop begin proc near ax,@data ds,ax dx, port al, 80h...
  • Page 30 cx, 08h al, 1 call delay dx, al loop ;;ROL push cx, 08h al, 1 dx, al call delay loop ;;-------------------- ;;-------------------- ;;ROR cx, 08h al, 1 call delay dx, al loop ;;ROL push cx, 08h al, 1 dx, al call delay loop ;;--------------------...
  • Page 31 al, 1 call delay dx, al loop ;;ROL push cx, 08h al, 1 dx, al call delay loop ;;-------------------- ;;-------------------- ;;ROR cx, 08h al, 1 call delay dx, al loop ;;ROL push cx, 08h al, 1 dx, al call delay loop ;;-------------------- ;;--------------------...
  • Page 32 al, 0ffh dx, al call delay al,0h dx, al call delay loop ah, 4ch ;go back to dos .stack begin endp end begin...

  • Page 33: Chapter 4 Ami Bios Setup

    Chapter 4 AMI BIOS Setup The 3308220 uses AMI BIOS for the system configuration. The AMI BIOS setup program is designed to provide the maximum flexibility in configuring the system by offering various options that could be selected for end-user requirements. This chapter is written to assist you in the proper usage of these features.

  • Page 34: Using Setup

    Using Setup In general, you use the arrow keys to highlight items, press <Enter> to select, use the <PageUp> and <PageDown> keys to change entries, and press <Esc> to quit. The following table provides more detail about how to navigate in the Setup program using the keyboard. Move to previous item ↑...

  • Page 35: Main Menu

    Main Menu Once you enter the AMI BIOS CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions and two exit choices. Use the arrow keys to select among the items and press <Enter>...

  • Page 36: Advanced Settings

    Advanced Settings This section allows you to configure your system for the basic operation. You have the opportunity to select the system’s default speed, boot-up sequence, keyboard operation, shadowing and security. BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit Advanced Settings WARNING: Setting wrong values in below sections...
  • Page 37 BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit IDE Configuration Parallel ATA IDE device Primary IDE Master : [Not Detected] Primary IDE Slave : [Not Detected] Secondary IDE Master : [Not Detected] Secondary IDE Slave : [Not Detected] Parallel ATA IDE Controller [Both] Hard Disk Write Protect...
  • Page 38 BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit ACPI Settings ACPI Aware O/S [No] Select Screen Select Item Change Field Select Field General Help Save and Exit Exit v02.59 (C)Copyright 1985-2005, American Megatrends, Inc.
  • Page 39 BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit Power Management/APM [Enabled] Power Button Mode [On/Off] Suspend Power Saving Type [C3] Restore on AC/Power Loss [Power On] Manual Throttle Ratio [50%-56.25%] System Thermal [Disabled] Thermal Active Temperature [65°C/149°F] THRM throttle Ratio [50%-56.25%] Standby Time Out [Disabled]...
  • Page 40 BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit USB Configuration Module Version – 2.24.0-11.4 USB Devices Enabled: None USB 1.1 Ports Configuration [USB 6 Ports] USB 2.0 Ports Enable [Enabled] Legacy USB Support [Enabled] Select Screen USB 2.0 Controller Mode [FullSpeed] Select Item Change Field...

  • Page 41: Advanced Pci/Pnp Settings

    Advanced PCI/PnP Settings This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system that allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its own special components. This section covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings.

  • Page 42: Boot Settings

    Boot Settings BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit Boot Settings Boot Settings Configuration Boot Device Priority Removable Drives Select Screen Select Item Change Field Select Field General Help Save and Exit Exit v02.59 (C)Copyright 1985-2005, American Megatrends, Inc. BIOS SETUP UTILITY Main Advanced...

  • Page 43: Security Settings

    BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit Boot Device Priority 1st Boot Device [1st FLOPPY DRIVE] Select Screen Select Item Change Field Select Field General Help Save and Exit Exit v02.59 (C)Copyright 1985-2005, American Megatrends, Inc. BIOS SETUP UTILITY Main Advanced PCIPnP...

  • Page 44: Advanced Chipset Settings

    Advanced Chipset Settings BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit Advanced Chipset Settings WARNING: Setting wrong values below sections cause system malfunction. NorthBridge VIA CX700 Configuration SouthBridge VIA CX700 Configuration Select Screen Select Item Change Field Select Field General Help Save and Exit Exit...
  • Page 45 BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit DRAM Frequency/Timing Configuration DRAM Frequency [Auto] DRAM Timing [Auto] DRAM Command Rate [2T Command] RDSAIT/RDSBIT mode [Auto] Memory Chip Driving [Normal] DDR2 Memory Chip ODT [Auto] DDR DQSBAR [Disabled] BA0 SEL [A13] BA1 SEL [A14]...
  • Page 46 BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit V-Link & PCI Bus Configuration PCI Master 0 WS Write [Enabled] V-Link mode selection [Auto] V-Link 8X Supported [Enabled] V-Link Data 2X Support [Disabled] DRDY Timing [Default] RCONV [Enabled] Select Screen Dynamic CKE select [Auto] Select Item...

  • Page 47: Exit Options

    Exit Options BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit Exit Options Save Changes and Exit Discard Changes and Exit Discard Changes Load Optimal Defaults Load Failsafe Defaults Select Screen Select Item - Change Field Select Field General Help Save and Exit Exit v02.59 (C)Copyright 1985-2005, American Megatrends, Inc.
  • Page 48 We will do our best to support your products, projects and business. Address: Global American, Inc. 17 Hampshire Drive Hudson, NH 03051 Telephone: Toll Free U.S. Only (800) 833-8999 (603) 886-3900 FAX: (603) 886-4545 Website: http://www.globalamericaninc.com Support: Technical Support at Global American...
